XTRONS Android Car Overhead Player

Introducció

This manual provides comprehensive instructions for the installation, operation, and maintenance of your XTRONS Android Car Overhead Player, model CM179A. Please read this manual thoroughly before using the product to ensure proper function and safety.

Característiques clau

• Sistema operatiu Android: Equipped with Android 9.0 Pie OS, Octa Core CPU, 2GB RAM, and 32GB ROM for app compatibility and performance.
• 17.3-inch FHD IPS Screen: Large digital display with HDR10+ Technology for immersive viewing, sharp images, and wide viewangles d'ajust.
• Compatibilitat amb vídeo 8K: Smooth playback of 8K, 4K, 2K, and 1080P video formats. Compatible with MP4, AVI, MKV, WMV, MPG, MPEG, MOV, RM, RMVB, DAT, FLV, MP3, WMA, WAV, AAC, APE, FLAC, JPG, JPEG, BMP, PNG.
• Connectivitat versàtil: Includes Screen Mirroring (Android 8.0+ and iOS 9.0+), HDMI input, USB port, and AV input for connecting various external devices.
• Opcions de sortida d'àudio: Features built-in stereo speakers, Bluetooth audio transmission, and IR headphone support (2 Black IR Headphones included).
• WiFi integrat: Enables quick data speeds for downloading apps, streaming videos, and more.

Components inclosos

The following items are included with your XTRONS Android Car Overhead Player CM179A:

• 1 x XTRONS Android Car Overhead Player (CM179A)
• 2 x Black IR Headphones (DWH005)
• 1 x comandament a distància
• 1 x cable d'alimentació
• 6 femelles de muntatge
• 1 x Manual d'usuari

This image displays the main unit, remote control, power cable, mounting nuts, and user manual. It also illustrates the general installation steps.

Configuració i instal·lació

Professional installation is recommended for this product. Ensure the vehicle's battery is disconnected before beginning installation.

1. Instal·leu el suport de muntatge: Securely install the provided mounting bracket to the car roof. Ensure it is centered and stable.
2. Fix Car Roof Player: Attach the car roof player to the installed bracket using the provided screws.
3. Connecteu el cable d'alimentació: Connect the power cable to the unit and the vehicle's power supply. Refer to the wiring diagram for correct connections.

The diagram shows how to install the mounting bracket to the car roof, fix the player to the bracket, and connect the power cable.

This diagram illustrates the connections for B+, ACC, GND, Door Control (+/-), Audio Left/Right Input, Video Input 1/2.

Funcionament

Power On/Off and Screen Adjustment

The unit powers on when the vehicle's ignition is on. The screen can be manually adjusted for optimal viewing angles. Virtual touch buttons are located on the unit for direct control.

The unit features automatic lighting control that activates when the car door opens and colorful aura lighting for ambient effects.

Android System and Apps

The CM179A runs on Android 9.0 Pie, offering access to a wide range of applications from the Play Store. Connect to Wi-Fi or a mobile hotspot to stream content from platforms like Netflix, YouTube, Prime Video, and Hulu.

This image displays the Android home screen with icons for music, video, YouTube, settings, file manager, and other applications.

Reproducció multimèdia

The unit supports 8K video playback, ensuring smooth and high-quality viewing for various media formats including MP4, AVI, MKV, WMV, MPG, MPEG, MOV, RM, RMVB, DAT, FLV, MP3, WMA, WAV, AAC, APE, FLAC, JPG, JPEG, BMP, and PNG.

Mirall de pantalla

Wirelessly mirror content from your Android (8.0 and above) or iOS (9.0 and above) smartphone directly to the overhead player. This allows for sharing photos, videos, and games without downloading additional apps.

This image shows a smartphone mirroring its display to the XTRONS overhead monitor, highlighting compatibility with both iOS and Android devices.

External Device Connectivity

Utilize the HDMI, USB, and AV inputs to connect external devices such as game consoles, cameras, video recorders, or other car entertainment systems. The USB port supports flash drives for local media playback.

This image details the various input and output ports available on the unit for connecting external devices and transmitting audio.

Sortida d'àudio

Sound can be output through the built-in stereo speakers, via Bluetooth to compatible headphones, or through IR headphones (included). An FM transmitter function is also available to send audio to your car's FM radio.

Manteniment

To ensure the longevity and optimal performance of your XTRONS Android Car Overhead Player, follow these general maintenance guidelines:

• Neteja: Feu servir un drap suau i sec per netejar la pantalla i les superfícies exteriors. Eviteu productes de neteja o dissolvents abrasius.
• Temperatura: Eviteu exposar la unitat a temperatures extremes, tant altes com baixes, durant períodes prolongats.
• Potència: Ensure the unit is properly powered off when the vehicle is not in use to prevent battery drain.
• Actualitzacions de programari: Periodically check for and install any available software updates to improve performance and add new features.

Resolució de problemes

• La unitat no s'encén: Check all power connections (B+, ACC, GND) and ensure they are secure. Verify the vehicle's battery is charged.
• No display/blank screen: Confirm the correct video input source is selected. Check HDMI/AV connections.
• Sense so o àudio distorsionat: Verify audio output settings. Check speaker connections, Bluetooth pairing, or IR headphone functionality. Ensure FM transmitter is correctly tuned if in use.
• Lagging or choppy video playback: Assegurar els mitjans de comunicació file is not corrupted. For streaming, check Wi-Fi signal strength.
• Apps not working correctly (e.g., YouTube): Ensure the unit is connected to the internet. Check for app updates or reinstall the app.
• El comandament a distància no respon: Check battery in the remote. Ensure no obstructions between the remote and the unit's IR receiver.

Especificacions

Garantia i Suport

For warranty information or technical support, please contact XTRONS directly. You can typically find contact details on the XTRONS official website or through your purchase platform. Ensure you have your product model number (CM179A) and proof of purchase available when contacting support.

This image shows a prompt to contact XTRONS for questions, indicating the seller's name and a link to ask a question.
