Introducció
This manual provides detailed instructions for the Armitron Sport Men's Digital Chronograph Resin Strap Watch, Model 40/8284BGN. Designed for durability and functionality, this watch features a digital display with multiple functions including chronograph, lap time, alarm, dual time, military time, and backlight. It is water resistant up to 330 feet (100M).
Característiques clau
- Military green resin case with black top ring.
- LCD display showing time, seconds, day, and date.
- Functions include: chronograph, lap time, alarm, dual time, military time, and backlight.
- Military green resin strap with a secure buckle closure.
- Water resistance up to 330 feet (100M).
Figura 1: Frontal view of the Armitron Sport Digital Chronograph Watch, highlighting its digital display and robust design.
Components del rellotge
Familiaritzeu-vos amb els botons i els elements de la pantalla del rellotge:
- Botó MODE (a baix a l'esquerra): Used to cycle through different modes (Time, Chronograph, Alarm, Dual Time).
- Botó RESET (a dalt a l'esquerra): Used to reset the chronograph, adjust settings, or stop the alarm.
- Botó ST/STP (a dalt a la dreta): Used to start/stop the chronograph or select settings.
- Botó EL (a baix a la dreta): Activates the backlight for illumination in low-light conditions.
Figura 2: lateral view of the watch, illustrating the placement of the control buttons.
Instruccions de configuració
Configuració de l'hora i la data:
- Des de la pantalla de l'hora normal, premeu la tecla MODE button repeatedly until the time setting mode is indicated (usually by flashing digits).
- Premeu el botó RESET button to select the digit or setting you wish to adjust (e.g., seconds, hour, minute, month, date, day of week).
- Utilitza el ST / STP button to increase the selected value. Hold to rapidly advance.
- Un cop tots els paràmetres siguin correctes, premeu el botó MODE per sortir del mode de configuració i tornar a la visualització normal de l'hora.
Format 12/24 hores:
While in the time setting mode, pressing the ST / STP button when the hour digits are flashing will toggle between 12-hour (AM/PM) and 24-hour (military) time formats.
Instruccions de funcionament
Ús del cronògraf:
- Premeu el botó MODE fins que aparegui "CHRONO" o "STW" (cronòmetre) a la pantalla.
- Premeu ST / STP per iniciar el cronògraf.
- Premeu ST / STP de nou per aturar el cronògraf.
- Premeu RESET per posar el cronògraf a zero.
- Per registrar temps de volta, premeu RESET while the chronograph is running. The lap time will display briefly, and the chronograph will continue running in the background. Press ST / STP to stop, then RESET aclarir.
Configuració de l'alarma:
- Premeu el botó MODE button until "ALARM" is displayed.
- Premeu RESET to select the hour or minute digits to adjust.
- Ús ST / STP per configurar l'hora de l'alarma desitjada.
- Premeu MODE per confirmar i sortir.
- Per activar/desactivar l'alarma, premeu ST / STP while in the ALARM mode. An alarm icon will appear/disappear.
Dual Time Function:
The dual time function allows you to track a second time zone. Press the MODE button until "DUAL TIME" is displayed. Use the RESET i ST / STP buttons to set the second time zone, similar to setting the main time.
Figure 3: The watch displayed on a wrist, demonstrating its size and fit.
Manteniment
Neteja:
Netegeu el rellotge regularment amb un drap suauamp cloth. Avoid using harsh chemicals, solvents, or abrasive cleaners, as these can damage the resin case and strap. If the watch comes into contact with saltwater, rinse it thoroughly with fresh water and dry it with a soft cloth.
Resistència a l'aigua:
This watch is water resistant to 330 feet (100M). This means it is suitable for showering, swimming, and snorkeling. However, it is not recommended for diving or high-impact water sports. Do not operate the buttons while the watch is submerged in water, as this can compromise the water resistance seal.
Substitució de la bateria:
The watch uses 1 Product Specific battery (included). When the display dims or functions become erratic, the battery may need replacement. It is recommended to have the battery replaced by a qualified watch technician to ensure the water resistance seal is properly maintained.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| La pantalla està en blanc o tènue. | Bateria baixa. | Canvieu la bateria (es recomana un servei professional). |
| Els botons no responen. | Pot ser que el rellotge estigui en mode bloquejat o que hi hagi un problema intern. | Try pressing all buttons to see if any function. If not, a reset may be needed (consult professional). |
| Aigua dins del rellotge. | Segell compromès o botons premuts sota l'aigua. | Immediately take to a watch repair specialist to prevent further damage. |
| Hora/data incorrectes. | Needs to be reset or adjusted. | Seguiu les instruccions de "Configuració de la data i l'hora". |
Especificacions
- Número de model: 40/8284BGN
- Material de la caixa: Resina
- Material de la corretja: Resina
- Tipus de visualització: LCD digital
- Resistència a l'aigua: 330 peus (100 m)
- Font d'alimentació: 1 bateria específica del producte (inclosa)
- Dimensions del paquet: 3.98 x 3.43 x 2.76 polzades
- Pes de l'article: 2 unces
- Fabricant: Armitron Sport
- País d'origen: Xina
Garantia i Suport
For warranty information, product support, or service inquiries, please refer to the official Armitron weblloc web o poseu-vos en contacte amb el seu departament d'atenció al client. Conserveu el comprovant de compra per a reclamacions de garantia.
