Producte acabatview
The MEIKEE 25W RGBW LED Wall Washer Light is a versatile lighting solution designed for both indoor and outdoor applications. It features a powerful 25W RGBW LED, offering a wide spectrum of colors and adjustable brightness. With its IP66 waterproof rating, it is suitable for various environments, including parties, stages, landscapes, gardens, and building illumination. The included RF remote controller provides convenient 360° control, allowing for easy selection of 10 single colors, 6 brightness levels, and 12 working modes with adjustable speed. Smart timing and memory functions enhance user experience.
Image: Four MEIKEE 25W RGBW LED Wall Washer Lights, showing the lights, power cord, and two RF remote controllers.
Què hi ha a la caixa
- 4 x 25W RGB LED Wall Washer Lights
- 2 x RF Remote Controllers
- Suports de muntatge (preinstal·lats o inclosos)
- Installation Hardware (screws, expansion nails, M5 hex screw key)
Configuració i instal·lació
The MEIKEE Wall Washer Light is designed for fast and easy installation with its 120V standard American plug. No complex wiring is required; simply plug and play.
Opcions de muntatge
Each unit comes with two sturdy mounting brackets, allowing for flexible installation on various flat surfaces.
- Muntat a la paret: Secure the light to a vertical surface to illuminate walls or facades.
- Ground Inserted/Mounted: Position the light on the ground to uplight features or create ambient lighting.
Imatge: Examples of wall-mounted and ground-inserted installation for the LED wall washer light.
Passos d'instal·lació
- Col·loca els suports: Use the long screws to securely fix the brackets to both sides of the wall washer light.
- Choose Location & Drill: Select a suitable installation location. Based on the size of the bracket, drill four small holes.
- Ajust d'angle: Adjust the angle of the light according to your environment and desired lighting effect. Tighten the screws to secure the angle.
- Connectar l'alimentació: Connect the socket. Pull out the insulating piece from the remote control's battery compartment before first use. Plug the light into a standard 120V electrical outlet.
Image: Detailed diagram illustrating the installation process, dimensions, and components.
Instruccions de funcionament
Your MEIKEE LED Wall Washer Light comes with a 29-key RF remote controller for comprehensive and convenient operation. The RF technology allows for 360° control within an effective distance of up to 39.3 feet (12 meters), without needing to aim directly at the light.
Funcions de control remot
- Selecció de color: Choose from 10 single colors (Red, Green, Blue, White, Warm White, Orange, Yellow, Cyan, Purple, Pink).
- Ajust de brillantor: Ajusta la intensitat de la llum amb 6 nivells de brillantor.
- Modes de treball: Select from 12 dynamic working modes, including Flash, Smooth, Strobe, and various color cycling speeds.
- Ajust de velocitat: Controla la velocitat dels modes dinàmics.
- Funció de cronometratge: Set the light to automatically turn off after 2, 4, or 6 hours.
- Funció de memòria: The light will remember your last setting (color, mode, brightness) when turned on again via the remote control, eliminating the need for re-adjustment.
Image: RF Remote Control with 360° sensing distance and various color/mode options.
Image: Visual representation of 10 single color options.
Image: Visual representation of 10 color changing modes with adjustable speed.
Image: Illustration of Timing and Memory functions.
Manteniment
The MEIKEE LED Wall Washer Light is designed for durability and minimal maintenance.
- Impermeable IP66: This rating ensures the light fixture can operate reliably in various weather conditions, including rain and snow. Note: Do not immerse the light in water.
- Resistència a la temperatura: The robust design provides both heat and frost resistance, making it suitable for extreme temperatures.
- Neteja: To clean the light, ensure it is unplugged and use a soft, damp tela. Eviteu els netejadors abrasius.
Image: Features highlighting IP66 Waterproof, Heat Resistance, and Frost Resistance.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| La llum no s'encén | No power; Remote battery dead; Insulating tab not removed | Check power connection; Replace remote battery; Remove insulating tab from remote |
| El comandament a distància no respon | Remote battery dead; Out of range; Interference | Replace remote battery; Move closer to the light (within 39.3ft/12m); Reduce interference |
| Colors are incorrect or flickering | Power fluctuation; Internal issue | Unplug and replug the light; Contact customer support if problem persists |
Especificacions
- Model: RFLB025
- Wattage: 25W
- Tipus de font de llum: LED (RGBW)
- Voltage: 120 Volts
- Nivell de resistència a l'aigua: Impermeable IP66
- Mètode de control: Comandament a distància RF
- Característiques especials: Dimmable, IP66 Waterproof, Timing & Memory Function
- Material: Acrylonitrile Butadiene Styrene, Aluminum, Glass
- Pes de l'article: 4.42 pounds (per light, approximate)
- Dimensions del paquet: 16.81 x 4.29 x 4.13 polzades
- Components inclosos: 2 RF Remote Controllers (for 4-pack)
Garantia i Suport
MEIKEE products are covered by a 2-year warranty from the date of purchase.
For any service inquiries or support, please contact MEIKEE customer service via Amazon or the email address provided in your product packaging. We aim to provide a timely response within 24 hours.
