Introducció
Thank you for choosing the Okaysou Apollo 630 Air Purifier. This manual provides important information regarding the setup, operation, maintenance, and troubleshooting of your new air purifier. Please read it thoroughly before use and keep it for future reference.
The Okaysou Apollo 630 is engineered to provide superior air purification for large spaces, effectively capturing airborne particles and odors to create a healthier indoor environment.
Image: The Okaysou Apollo 630 Air Purifier, a sleek white unit with a control panel on top and air intake vents on the sides.
Característiques clau
- Filtració HEPA veritable H13: Captures 99.97% of airborne particles as small as 0.3 microns, including dust, pollen, pet dander, and mold spores.
- Sistema de filtració 5 en 1: Features a washable pre-filter, True HEPA filter, Novel Blue filter, Honeycomb Activated Carbon filter, and Cold Catalyst filter for comprehensive air purification.
- Àmplia Àrea de Cobertura: Designed to refresh air in rooms up to 1008 sq ft in one hour (1 ACH) or 504 sq ft in 30 minutes (2 ACH).
- Funcionament ultra silenciós: Operates as quietly as 23dB in Sleep Mode, ensuring undisturbed rest.
- Sense ozó: Produces no harmful ozone, ensuring safe operation for your family.
- Certified Performance: Energy Star, CARB, ETL, and FCC certified for safety and efficiency.
Image: Diagram illustrating the Okaysou Apollo 630's ability to remove various pollutants such as smoke, fumes, fiber, wildfire particles, pollen, dander & hair, cooking odors, dust, and VOCs, emphasizing its 100% ozone-free operation.
Imatge: Una explosió view of the Okaysou Apollo 630's powerful 5-layer filtration system, showing the washable pre-filter, True HEPA filter, Novel Blue filter, Honeycomb Activated Carbon filter, and Cold Catalyst filter, designed to keep pollutants out.
Image: Illustration demonstrating the Okaysou Apollo 630's wider coverage, capable of refreshing air in a 1008 sq ft room in one hour (1 ACH) or a 504 sq ft room in 30 minutes (2 ACH), depicted in a living room setting.
Guia de configuració
Follow these steps to set up your Okaysou Apollo 630 Air Purifier:
- Desempaquetar la unitat: Carefully remove the air purifier from its packaging. Retain all packaging materials for future transport or storage.
- Eliminar l'embalatge del filtre: Before first use, open the filter compartment and remove all protective plastic packaging from the filters. The filters are typically stacked inside the unit.
- Instal·lar filtres: Place the filters back into the unit in the correct order. Ensure the washable pre-filter is on the outside, followed by the G-Defence Blue True HEPA Filter, and then the Toxin/Odor Remover Filter. Refer to the diagram below for proper orientation.
- Compartiment tancat: Tanqueu bé la tapa del compartiment del filtre.
- Col·locació del purificador: Place the air purifier on a firm, level surface at least 15 inches (38 cm) away from walls or furniture to allow for optimal airflow.
- Connectar l'alimentació: Connecteu el cable d'alimentació a una presa de corrent estàndard de 120 V CA.
Image: A diagram showing the contents of the box, including the product manual, warranty card, 3-stage filter, and the air purifier itself, with an exploded view illustrating how the filters (washable pre-filter, G-Defence Blue True HEPA Filter, Toxin/Odor Remover Filter) are installed into the unit.
Instruccions de funcionament
Familiarize yourself with the control panel and functions:
- Encès/apagat: Premeu el botó d'encesa per encendre o apagar la unitat.
- Velocitat del ventilador: Cycle through different fan speeds (Low, Medium, High, Turbo) by pressing the fan speed button. Higher speeds provide faster air purification.
- Mode de repòs: Activate Sleep Mode for ultra-quiet operation. In this mode, the fan speed is set to the lowest setting, and display lights may dim or turn off.
- Funció de temporitzador: Set a timer for the purifier to operate for a specific duration (e.g., 2, 4, 8 hours) before automatically shutting off.
- Indicador de reinici del filtre: A light will illuminate when it's time to check or replace the filters. After replacing filters, press and hold the filter reset button to reset the indicator.
Image: An illustration depicting the Okaysou Apollo 630 operating in a bedroom at night, highlighting its ultra-silent operation at 23dB in Sleep Mode, significantly quieter than typical breathing (10dB) or a whisper (30dB).
Manteniment
Un manteniment regular garanteix un rendiment òptim i allarga la vida útil del purificador d'aire.
Manteniment del filtre
- Prefiltre rentable: The pre-filter can be washed with water to remove larger particles like dust and pet hair. Allow it to air dry completely before re-installing. Clean every 2-4 weeks depending on air quality.
- HEPA and Carbon Filters: These filters are not washable and should be replaced every 6-8 months, or sooner depending on usage and air quality. Refer to the filter reset indicator.
Neteja de la unitat
- Desconnecteu sempre el purificador d'aire abans de netejar-lo.
- Netegeu l'exterior de la unitat amb un drap suau i sec. No utilitzeu productes de neteja abrasius ni dissolvents.
- Gently vacuum the air intake and outlet vents to remove any accumulated dust.
Resolució de problemes
Si teniu problemes amb el purificador d'aire, consulteu els següents problemes i solucions habituals:
| Problema | Causa possible | Solució |
|---|---|---|
| La unitat no s'encén | Power cord not securely plugged in; No power from outlet; Filters not installed correctly or packaging not removed. | Ensure power cord is firmly plugged into a working outlet. Check circuit breaker. Open filter compartment and ensure all filters are correctly installed and plastic packaging is removed. |
| El flux d'aire és feble | Filters are dirty or clogged; Air intake/outlet blocked. | Clean or replace filters. Ensure there are no obstructions around the air intake or outlet vents. |
| Soroll inusual | Foreign object inside unit; Filters not seated properly. | Unplug the unit and check for any foreign objects. Re-seat the filters to ensure they are properly installed. |
| Odor coming from unit | New filter odor; Filters need replacement. | A slight odor may be present with new filters, which will dissipate. If odor persists, replace the carbon filter. |
| El llum indicador del filtre roman encès després de la substitució | No s'ha premut el botó de restabliment del filtre. | After replacing filters, press and hold the filter reset button for 3-5 seconds until the light turns off. |
Especificacions
| Especificació | Valor |
|---|---|
| Número de model | Apollo 630 Air Purifier |
| Dimensions (L x A x A) | 35 x 21.51 x 43.99 cm (13.78 x 8.47 x 17.32 polzades) |
| Pes | 3.3 quilograms (7.28 lliures) |
| Poder | 55 watts |
| Voltage | 120 volts (CA) |
| Nivell de soroll | 23 dB (mínim) |
| Àrea de cobertura | Up to 1008 sq ft (1 ACH) |
| Color | White (Jiaju42) |
| UPC | 609832853787, 609832853923 |
Image: A graphic displaying the Okaysou Apollo 630's performance data, including Clean Air Delivery Rate (CADR) for smoke (125 CFM), dust (134 CFM), and pollen (127 CFM), alongside logos for Energy Star, CARB, ETL, and FCC certifications, indicating trusted performance and safety.
Garantia i Suport
Okaysou products are manufactured to the highest quality standards. This product comes with a standard manufacturer's warranty. Please refer to the warranty card included in your product packaging for specific terms and conditions.
For technical support, troubleshooting assistance, or warranty claims, please contact Okaysou customer service. Contact information can typically be found on the official Okaysou weblloc web o a la targeta de garantia.
Recursos en línia: For the most up-to-date information, FAQs, and support, visit the official Okaysou weblloc.
