DONGERDI 135W AC Power Adapter User Manual

1. Introducció

This manual provides essential instructions for the safe and effective use of your DONGERDI 135W AC Power Adapter, Model DED190071M. This adapter is designed to provide power to compatible Acer Nitro V15, V14, V16, ANV15, ANV14, ANV16, and Nitro 5 series gaming laptops requiring a 135W power supply.

2. Pautes de seguretat

Please read and follow these safety instructions carefully to prevent damage to the product or injury to yourself.

• Use the adapter only with compatible devices as specified in this manual.
• No exposeu l'adaptador a l'aigua, la humitat ni a temperatures extremes.
• Eviteu deixar caure l'adaptador ni sotmetre'l a impactes forts.
• No intenteu desmuntar ni modificar l'adaptador.
• Ensure proper ventilation around the adapter during use to prevent overheating.
• Keep the adapter and cables away from pets and children.
• Desendolleu l'adaptador de la presa de corrent quan no l'utilitzeu durant períodes prolongats.
• If the adapter or cable is damaged, discontinue use immediately and seek a replacement.

Figure 1: Multi-Security Protection Features

The adapter incorporates multiple safety features including short-circuit protection, over-current protection, and over-voltage protecció per garantir un funcionament segur.

3. Contingut del paquet

Verifiqueu que tots els elements siguin presents al paquet:

• 135W AC Power Adapter (Main Unit)
• Power Cord (for connecting to wall outlet)

Figura 2: Contingut del paquet

The package includes the main adapter unit and the detachable power cord. The power cord specifications may vary by region.

4. Producte acabatview

The DONGERDI 135W AC Power Adapter consists of the main adapter brick, a detachable power cord, and an output cable with a 5.5x1.7mm purple tip connector.

Figure 3: DONGERDI 135W AC Power Adapter Components

This image displays the complete power adapter assembly, including the main unit, the AC input cable, and the DC output cable with its distinctive purple tip.

Figure 4: Connector Tip and Power Rating

The adapter features a 5.5x1.7mm round purple tip, delivering 19V at 7.1A for a maximum output of 135W.

Figure 5: Cable Lengths

The total cable length is approximately 10 feet, comprising a 4-foot power cord and a 6-foot charger cord, providing flexibility for placement.

5. Instal·lació i configuració

Follow these steps to connect your power adapter to your laptop:

1. Connect the detachable power cord to the AC input port on the main adapter unit.
2. Plug the other end of the power cord into a standard wall outlet (100-240V AC).
3. Insert the purple-tipped DC connector firmly into the charging port of your compatible Acer laptop.
4. Ensure all connections are secure before operating your laptop.

6. Funcionament

Once connected, the adapter will automatically begin charging your laptop's battery and/or powering the laptop. The adapter is designed for continuous use with compatible devices.

• The adapter supports universal voltage input (100-240V, 50-60Hz), making it suitable for international travel with the appropriate power cord.
• Monitor your laptop's charging indicator to confirm proper power delivery.

7. Compatibilitat

This 135W power adapter with a 5.5x1.7mm purple tip is compatible with the following Acer laptop series and models:

• Acer Nitro V15 Series: ANV15-51 (e.g., ANV15-51-723D, 53CS, 789J, 77DQ, 717H, 99DR, 92XK, 532J, 57C8, 58A4, 54UL, 73B9, 75HE, 51H9, 57ZV, 59MT, 515P, 98N0), ANV15-41 (e.g., ANV15-41-R2Y3, R5N6, R2MS)
• Acer Nitro V14 Series: ANV14-61 (e.g., ANV14-61-R49G)
• Acer Nitro V16 Series: ANV16-41 (e.g., ANV16-41-R2R4, R5J0, R5K2)
• Acer Nitro 5 Series: AN515-31, AN515-41, AN515-42, AN515-43, AN515-51, AN515-52, AN515-53, AN515-54, AN515-56 series
• Also compatible with models N18C3, N18C4, N20C1, N20C2 Gaming Laptops that require a 135W power supply.

Important: Verify your laptop's power requirements (voltage i amperage) and connector tip size (5.5x1.7mm) before use. This adapter is specifically for 135W models.

8. Cura i Manteniment

Proper care extends the life of your power adapter:

• Emmagatzematge: Store the adapter in a cool, dry place when not in use. Avoid wrapping cables too tightly to prevent damage.
• Neteja: Disconnect from power before cleaning. Use a soft, dry cloth to wipe the adapter. Do not use liquid cleaners.
• Gestió de cables: Avoid sharp bends or kinks in the cables. Do not place heavy objects on the cables.
• Temperatura: Do not operate the adapter in environments with extreme heat or cold.

9. Solució De Problemes

If you encounter issues with your power adapter, refer to the following common problems and solutions:

Si el problema persisteix després d'intentar aquestes solucions, poseu-vos en contacte amb l'atenció al client.

10. Especificacions tècniques

11. Certificacions

This product complies with various international safety and quality standards.

Figura 6: Certificacions de producte

The adapter is certified with FC, CE, UKCA, and RoHS, ensuring adherence to safety and environmental regulations.

12. Atenció al client

For technical assistance, warranty information, or any questions regarding your DONGERDI 135W AC Power Adapter, please contact DONGERDI customer support through the retailer where the product was purchased or visit the official DONGERDI store page on Amazon.

DONGERDI Store Link: DONGERDI Official Store
