1. Introducció
Thank you for choosing the BOBLOV M6 Body Camera. This manual provides essential information for the proper setup, operation, and maintenance of your device. The M6 is a high-definition body-worn camera designed for various applications, featuring 1440P video recording, GPS functionality, and robust construction.
The BOBLOV M6 Body Camera is suitable for diverse environments, including law enforcement, security, and personal use.
2. Producte acabatview
Característiques clau
- Resolució de vídeo: Up to 1440P (2K) at 30 frames per second.
- Resolució fotogràfica: Fins a 36 megapíxels.
- Lent gran angular: camp de 170° view.
- Funció GPS: Records location data (requires external software for viewing).
- Visió nocturna: Automatic/Manual IR for clear footage amb poca llum.
- Funció d'alarma: Red-blue flashing lights and alarm sound.
- Durabilitat: IP65 water-resistance and 3-meter drop resistance.
- Durada de la bateria: Approximately 7 hours of recording, 24 hours standby.
- Emmagatzematge: Built-in 64GB or 128GB internal memory.
Acabatview of the BOBLOV M6 Body Camera's main features.
Contingut del paquet
Verifiqueu que tots els elements siguin presents al vostre paquet:
The BOBLOV M6 Body Camera package includes the camera unit, two types of clips, a Type-C charging cable, and a user manual.
- BOBLOV M6 Body Camera
- Short 360° Rotatable Clip
- Long 180° Rotatable Clip
- Cable USB tipus C
- Manual d'usuari
3. Configuració
Càrrega del dispositiu
Before first use, fully charge the body camera. Connect the Type-C cable to the camera and a power source. The charging indicator will show the charging status.
The camera charges via a Type-C cable and charging base. A full charge takes approximately 3 hours, providing about 7 hours of recording or 24 hours of standby time.
Adjuntant el clip
Select the appropriate rotatable clip (180° long clip or 360° short clip) and attach it to the back of the camera. Ensure it is securely fastened before wearing.
The camera comes with two types of rotatable clips for flexible mounting options.
4. Instruccions de funcionament
Encès/Apagat
- Per encendre: Press and hold the Power button until the device starts.
- Per apagar: Premeu i manteniu premut el botó d'engegada fins que el dispositiu s'apagui.
Gravació de vídeo
The M6 records video at 1440P resolution with a 170° wide-angle lens.
The camera records high-definition video with a wide field of view.
Captura de fotografies
Captura imatges fixes de fins a 36 megapíxels.
Visió nocturna
The camera features automatic and manual infrared night vision, allowing clear recording up to 49 feet (15 meters) in dark conditions.
Night vision allows for clear recording in low-light conditions.
Funció d'alarma
The M6 is equipped with red-blue flashing lights and an alarm sound for emergency situations.
- Per activar: Long press the "Alarm" button after booting.
- Per desactivar: Press the "Alarm" button again.
The alarm function provides visual and audible alerts.
Funció GPS
The camera supports GPS functionality to record location data with your footage. A view detailed location information, download and use DATAKAM PLAYER or RegistratorViewer programari al vostre ordinador.
- GPS On/Off: This option can be toggled in the camera's settings menu.
GPS data can be reviewed using dedicated software on a computer.
Access GPS settings through the camera's menu.
Opcions del menú
Navigate the camera's menu using the control buttons to adjust various settings.
The camera offers various configurable functions and options.
Els paràmetres clau inclouen:
- GPS: On/Off
- Llum blanca: On/Off
- Secret Record: On/Off
- Pre-enregistrament: On/Off
- Data St.amp: On/Off
- Posicionament làser: Llum vermella
- Contrasenya de la càmera: On/Off
- Detecció de moviment: On/Off
- Delay Records: 3s, 1min, 5mins
- So del vídeo: On/Off (Turning off video sound can save storage space.)
Option to disable video sound to optimize storage.
5. Manteniment
Neteja
Feu servir un drap suau i sec per netejar el cos de la càmera. Per a l'objectiu, feu servir un drap i una solució especials per netejar objectius per evitar ratllades. No utilitzeu productes químics agressius ni materials abrasius.
Water Resistance and Drop Resistance
The BOBLOV M6 is rated IP65 for water resistance and can withstand drops from up to 3 meters. While durable, avoid intentional submersion or severe impacts to prevent damage.
The camera is designed to be resistant to water splashes and drops.
Emmagatzematge
Store the camera in a cool, dry place away from direct sunlight and extreme temperatures. Ensure the battery is partially charged if storing for extended periods.
6. Solució De Problemes
- La càmera no s'encén: Ensure the battery is fully charged. Connect to a power source and try again. If the issue persists, contact support.
- Recording issues (e.g., freezing, corrupted files): Ensure the internal memory is not full. Try resetting the camera to factory settings (refer to the menu options).
- GPS data not showing: Verify that the GPS function is enabled in the camera settings. Ensure you are using the correct viewing software (DATAKAM PLAYER or RegistratorViewer) on your computer.
- Mala qualitat de visió nocturna: Ensure the lens is clean and there are no obstructions. Check if the IR lights are functioning correctly.
7. Especificacions
| Característica | Especificació |
|---|---|
| Marca | BOBLOV |
| Model | M6 |
| Resolució de captura de vídeo | 1440p |
| Tipus de memòria flash | Internal (64GB/128GB options) |
| Format de captura de vídeo | MPEG 4 |
| Mida de la pantalla | 2.7 polzades |
| Tecnologia de connectivitat | infrarojos |
| Característica especial | Portable, Lightweight, GPS, Red-Blue Alarm |
| Tipus de lent | Zoom (Wide Angle 170°) |
| Estabilització d'imatge | No (Features Anti-shaking technology) |
| Factor de forma | Compacte |
| Compatibilitat de sistemes operatius | Android, iOS (for data transfer/management, not direct camera operation) |
| Tipus d'enfocament | Enfocament automàtic |
| Recompte d'unitats | 1 recompte |
| Modes de tir | Nit |
| Capacitat de la bateria | 2600 mAh |
| Temps de càrrega | Aprox. 3 hores |
| Temps de gravació | Aprox. 7 hores |
| Temps d'espera | Aprox. 24 hores |
| Resistència a l'aigua | IP65 |
| Resistència a les caigudes | 3 metres |
Visual summary of key specifications and dimensions.
The M6 Body Camera is available with 64GB or 128GB built-in memory.
8. Garantia i Suport
BOBLOV products are designed for reliability and performance. For warranty information, please refer to the specific warranty card included with your product or visit the official BOBLOV website. For technical support, troubleshooting assistance, or any inquiries, please contact BOBLOV customer service through the contact information provided in your product packaging or on the official BOBLOV brand store.
