Introducció
Thank you for choosing the Ocean STONE 60cm Island Hood. This manual provides essential information for the safe installation, operation, and maintenance of your new appliance. Please read it thoroughly before use and keep it for future reference.
Image: The Ocean STONE 60cm Island Hood, a stainless steel kitchen appliance designed for island installation.
Informació de seguretat
Important: Read all instructions before installing or using this appliance. Failure to follow these instructions may result in electric shock, fire, or personal injury.
- Assegureu-vos que el subministrament elèctric coincideixi amb la placa de característiques de l'aparell.
- La instal·lació ha de ser realitzada per un tècnic qualificat d'acord amb la normativa local.
- Do not operate the hood without filters properly installed.
- Netegeu regularment els filtres de greixos per evitar riscs d'incendi.
- Aquest aparell només és per a ús domèstic.
- No flamejar sota la campana extractora.
Contingut del paquet
Verify that all components are present and undamaged before installation.
- Ocean STONE Island Hood unit
- Filtres de greix d'alumini
- Carbon filters (for recirculation mode)
- Maquinari de muntatge
- Manual d'usuari
Configuració i instal·lació
This island hood is designed for ceiling mounting above a cooking island. Professional installation is recommended.
Comprovacions prèvies a la instal·lació:
- Ensure adequate ceiling support for the hood's weight (15 kg).
- Confirm proper electrical wiring is available at the installation point (220V).
- Determine if the hood will operate in extraction (ducted) or recirculation (ductless) mode. Carbon filters are required for recirculation.
Passos de muntatge:
- Mark the drilling points on the ceiling according to the provided template.
- Perforeu forats i inseriu els ancoratges adequats.
- Fixeu el suport de muntatge al sostre.
- Attach the hood body to the mounting bracket.
- Connecteu el subministrament elèctric.
- Install the ducting (if using extraction mode) or carbon filters (if using recirculation mode).
- Attach the decorative chimney sections.
Instruccions de funcionament
The Ocean STONE hood features push-button controls for fan speed and lighting.
Tauler de control:
The control panel is located on the front of the hood and consists of push buttons.
- Botó d'encesa: Press to turn the hood on or off.
- Botons de velocitat (1, 2, 3): Select desired fan speed. Speed 1 is for light cooking, Speed 3 for heavy cooking or strong odors.
- Botó de llum: Premeu per encendre o apagar els llums LED.
For optimal performance, turn on the hood a few minutes before cooking and leave it running for a few minutes after cooking to clear residual fumes.
Manteniment
Regular maintenance ensures efficient operation and extends the life of your hood.
Cleaning Aluminum Grease Filters:
- Grease filters should be cleaned approximately every 2 months, or more frequently depending on usage.
- To remove, locate the release latches and pull down.
- Filters are dishwasher safe. Use a mild detergent and a low-temperature cycle.
- Alternatively, wash by hand in hot water with a degreasinagent g.
- Assegureu-vos que els filtres estiguin completament secs abans de tornar-los a instal·lar.
Replacing Carbon Filters (Recirculation Mode Only):
- Carbon filters cannot be washed and must be replaced every 3-6 months, depending on usage.
- To replace, remove the aluminum grease filters first.
- Twist or unclip the old carbon filters and install new ones.
- Refer to the specific carbon filter instructions for detailed replacement steps.
Cleaning the Hood Exterior:
- Clean the stainless steel exterior with a soft cloth and a non-abrasive stainless steel cleaner.
- Do not use abrasive cleaners, scouring pads, or corrosive detergents.
Resolució de problemes
Abans de contactar amb el servei d'atenció al client, review els següents problemes i solucions habituals.
| Problema | Causa possible | Solució |
|---|---|---|
| La campana no s'encén. | Sense font d'alimentació. | Check power cord connection and circuit breaker. |
| Mal rendiment d'extracció. | Clogged grease filters or saturated carbon filters. | Clean aluminum filters or replace carbon filters. |
| Soroll excessiu. | Loose components or improper installation. | Check all mounting screws and ensure ducting is secure. |
| Els llums no funcionen. | Faulty LED bulb or electrical connection. | Contact a qualified technician for LED replacement. |
Especificacions
| Marca | Oceà |
| Model | PEDRA |
| Tipus d'instal·lació | Instal·lació d'illa |
| Dimensions (L x P x A) | 60 x 90 x 60 cm |
| Pes | 15 kg |
| Material | Alumini, acer inoxidable |
| Color | Acer inoxidable |
| Capacitat de flux d'aire | 800 m³/h |
| Nombre de velocitats | 3 |
| Tipus de control | Pulsador |
| Il·luminació | LED |
| Tipus de filtre | Aluminum Mesh, Carbon (optional) |
| Voltage | 220 V |
| Consum anual d'energia | 190 watts |
| Nivell de soroll | 65 dB |
| Eficiència | A+, B, 85% |
| Fet a | Itàlia |
Garantia i Suport
For warranty information and customer support, please refer to the warranty card included with your product or contact Ocean customer service. Keep your proof of purchase for any warranty claims.
