1. Introducció
Thank you for choosing the ZAQE MP3 Player with Spotify, Model M505. This device is designed to provide a comprehensive portable entertainment experience, featuring an 8-core processor, a smooth Android 9.0 operating system, 2GB RAM, and 16GB of internal storage. It comes equipped with a 64GB SD card, offering a total of 80GB of memory, expandable up to 512GB. This manual provides essential information for setting up, operating, and maintaining your device.
Image 1.1: The ZAQE MP3 Player M505, showcasing el seu disseny elegant i el seu factor de forma compacte.
2. Què hi ha a la caixa
Si us plau, verifiqueu que tots els elements siguin presents al paquet:
- 1 x ZAQE MP3 Player (Model M505)
- 1 cable USB (tipus C)
- 1 pel·lícula protectora
- 1 x funda protectora
- 1 x Auricular
3. Configuració
3.1 Càrrega inicial
Before first use, fully charge the device using the provided USB Type-C cable and a compatible power adapter (not included). The charging indicator will show the charging status.
3.2 Encès/Apagat
- Per encendre: Premeu i manteniu premut el botó d'engegada fins que la pantalla s'il·lumini.
- Per apagar: Mantingueu premut el botó d'engegada i, a continuació, seleccioneu "Apagar" de les opcions que apareixen a la pantalla.
3.3 Connexió Wi-Fi
To access online features and download applications, connect your device to a Wi-Fi network:
- Vés a Configuració > Xarxa i Internet > Wi-Fi.
- Activa/desactiva el Wi-Fi On.
- Seleccioneu la xarxa Wi-Fi que vulgueu de la llista.
- Introduïu la contrasenya si us demana i toqueu Connecta't.
4. Instruccions de funcionament
4.1 Gestió de la memòria
The device includes 16GB of internal ROM and a pre-installed 64GB SD card, totaling 80GB of storage. The memory can be expanded further up to 512GB using a compatible Micro SD card (sold separately).
4.2 Reproducció de música
The M505 supports various music playback methods:
- Música local: Use the built-in music player app to play files stored on the device or SD card. Supported formats include MP3, OGG, FLAC, AAC, WAV, WMA, APE, and more. Music can be organized by title, folder, artist, album, and genre.
- Serveis de streaming: Connect to Wi-Fi to use pre-installed apps like Spotify, Audible, and Deezer. Additional apps such as YouTube, Facebook, Kindle, and Twitter can be downloaded from the Play Store.
4.3 Reproducció de vídeo
The device features a 4.0-inch (1280x720) high-resolution touchscreen for smooth 1080P HD video playback. It is compatible with most video formats, including RM, AVI, RMVB, FLV, MP4, DAT, MKV, MPG, MOV, and TS, without requiring format conversion.
4.4 Connectivitat Bluetooth
The M505 supports two-way Bluetooth connections:
- Connecting to Audio Devices: Pair with Bluetooth headphones or speakers for wireless audio playback.
- Connexió a telèfons mòbils: Transferència files between your MP3 player and a mobile phone via Bluetooth.
- The device will automatically reconnect to previously paired Bluetooth devices after restarting.
5. Durada i càrrega de la bateria
The ZAQE MP3 Player is equipped with a 2000mAh lithium-polymer battery and supports USB-C fast charging. Expected battery performance is as follows:
- Up to 20 hours with Bluetooth headphones.
- Up to 35 hours with wired headphones.
- 5 to 6 hours of video playback.
- Standby time of 3 to 5 months.
6. Especificacions
| Característica | Especificació |
|---|---|
| Marca | ZAQE |
| Nom del model | M505 |
| Número de model | J1-CB |
| Color | Gris |
| Mida de la pantalla | 4 polzades |
| Tecnologia de connectivitat | Wi-Fi, Bluetooth |
| Capacitat d'emmagatzematge de memòria | 80 GB (16GB internal + 64GB SD card) |
| Memòria ampliable | Up to 512 GB (Micro SD) |
| Dispositius compatibles | Smartphone (for file transferència) |
| Característica especial | Pantalla tàctil |
| Tipus de bateria | Polímer de liti |
| Bateria recarregable | Sí |
| Interfície USB | USB tipus C |
7. Solució De Problemes
If you encounter issues with your ZAQE MP3 Player, please refer to the following common solutions:
- El dispositiu no s'encén: Ensure the device is fully charged. Connect it to a power source using the provided USB cable and allow it to charge for at least 30 minutes before attempting to power it on again.
- Applications Not Functioning Correctly (e.g., Deezer, Spotify): Ensure you have a stable Wi-Fi connection. Try clearing the app's cache and data (Settings > Apps > [App Name] > Storage > Clear Cache/Clear Data). If the issue persists, uninstall and reinstall the application from the Play Store.
- Device Freezing or Unresponsive: Perform a soft reset by pressing and holding the Power button for approximately 10-15 seconds until the device restarts. If this does not work, a factory reset may be necessary (see below).
- Google Account Issues After Reset: If you perform a factory reset, you may be prompted to log in with the Google account previously synced with the device for security reasons. Ensure you have access to this account's credentials. If you do not, contact ZAQE customer support.
- Poca durada de la bateria: Ensure background apps are closed. Reduce screen brightness. Disable Wi-Fi and Bluetooth when not in use.
7.1 Factory Reset (Caution)
A factory reset will erase all data on your device and restore it to its original settings. Back up any important files abans de continuar.
- Vés a Configuració > Sistema > Restablir opcions.
- Seleccioneu Esborra totes les dades (restabliment de fàbrica).
- Confirm your choice. The device will restart and begin the reset process.
8. Garantia i Suport
Your ZAQE MP3 Player (Model M505) comes with a manufacturer's warranty of 2 anys. Spare parts are also available for 2 anys des de la data de compra.
For technical assistance, warranty claims, or further inquiries, please contact ZAQE customer support through the retailer where you purchased the product or visit the official ZAQE weblloc per obtenir informació de contacte.
