1. Introducció
Welcome to the world of personal electric transportation with your new Hover-1 Origin Electric Self Balancing Scooter. This manual provides essential information for the safe operation, maintenance, and optimal performance of your device. Please read it thoroughly before your first ride.
The Hover-1 Origin is designed for fun and efficient travel, featuring a self-balancing system, integrated Bluetooth speaker, and vibrant LED lights. It offers a top speed of 7 mph and a range of up to 6 miles on a single charge.
Figure 1.1: Hover-1 Origin Electric Self Balancing Scooter. This image shows the top view of the black Hover-1 Origin, highlighting its sleek design and illuminated green LED lights on the wheels and footpads.
2. Informació de seguretat
Your safety is paramount. Operating the Hover-1 Origin requires attention and adherence to safety guidelines. Failure to follow these instructions may result in serious injury or property damage.
2.1 Precaucions generals de seguretat
- Porteu sempre casc i l'equip de seguretat adequat (genolleres, colzeres, canelleres) quan aneu en bicicleta.
- No conduïu sota els efectes de les drogues o l'alcohol.
- Assegureu-vos que la bateria estigui completament carregada abans de cada ús.
- Do not exceed the maximum weight limit of the scooter.
- Eviteu circular per superfícies irregulars, pendents pronunciades o a prop del trànsit.
- Be aware of your surroundings and pedestrians.
- The scooter is designed for single-rider use only.
- Do not make sudden turns or stops at high speeds.
- The scooter sends alerts if you are speeding or riding on unsafe surfaces; heed these warnings.
Figure 2.1: Emphasizing Safety. This image shows a person riding a Hover-1 scooter while wearing a helmet, with various safety gear accessories like knee pads and elbow pads displayed at the bottom, reinforcing the importance of protective equipment.
3. Què hi ha a la caixa
Upon opening your Hover-1 Origin package, please verify that all components are present and in good condition:
- Hover-1 Origin Electric Self Balancing Scooter
- Adaptador de càrrega
- Manual d'usuari (aquest document)
4. Configuració
4.1 Càrrec inicial
- Before first use, fully charge your Hover-1 Origin. Connect the charging adapter to the scooter's charging port and then to a power outlet.
- The charging indicator light on the charger will change (e.g., from red to green) when charging is complete. A full charge takes approximately 5 hours.
- No sobrecarregueu la bateria. Desconnecteu el carregador un cop finalitzada la càrrega.
4.2 Encès/Apagat
- To power on, press and hold the power button located on the scooter. The indicator lights will illuminate.
- Per apagar l'aparell, premeu i manteniu premut el botó d'engegada de nou fins que els llums s'apaguin.
5. Instruccions de funcionament
5.1 Riding Your Hover-1 Origin
- Place the Hover-1 Origin on a flat, level surface.
- Step onto one side of the footpad with one foot. The self-balancing system will stabilize the scooter.
- Quickly step onto the other footpad with your second foot. Maintain a relaxed posture and look straight ahead.
- To move forward, gently lean your body forward. To slow down or move backward, gently lean backward.
- To turn, apply slight pressure with the foot on the side you wish to turn towards. For example, to turn left, press down slightly with your right foot.
- To dismount, step off one foot at a time, ensuring the scooter remains balanced.
Figure 5.1: Front Fender, Top & Wheel LED Lights. This image displays the Hover-1 Origin scooter from a front-top perspective, showcasing its illuminated front fender, top, and wheel LED lights, which enhance visibility and style.
5.2 Funcionalitat de l'altaveu Bluetooth
Your Hover-1 Origin is equipped with a built-in Bluetooth 4.0 speaker, allowing you to enjoy music while riding.
- Ensure the scooter is powered on.
- Activa el Bluetooth al teu dispositiu mòbil (telèfon intel·ligent, tauleta, etc.).
- Cerca "Hover-1 Origin" in your device's Bluetooth settings and pair.
- Once paired, you can play music through the scooter's speaker.
Figure 5.2: Bluetooth Speaker Integration. This image highlights the Hover-1 Origin's built-in Bluetooth speaker, with a speaker icon and text indicating "FULL CONTROL FROM YOUR PHONE," suggesting seamless audio playback and control via a mobile device.
5.3 Rider Modes and App Control
The Hover-1 Origin features different skill modes (Beginner to Expert) and can be controlled via a compatible Android/iOS Bluetooth App. The app allows you to switch modes, enable GPS tracking, play/pause music, and customize LED lights.
6. Manteniment
6.1 Neteja
- Apagueu el patinet abans de netejar-lo.
- Netegeu l'exterior amb anunciamp tela. No utilitzeu netejadors abrasius ni dissolvents.
- Avoid getting water into any openings. The scooter is IPX-4 water-resistant, meaning it can withstand splashes, but not submersion.
6.2 Cura de la bateria
- Guardeu el patinet en un lloc fresc i sec quan no l'utilitzeu.
- Charge the battery at least once every three months, even if not in use, to maintain battery health.
- No exposeu la bateria a temperatures extremes.
7. Solució De Problemes
| Problema | Causa possible | Solució |
|---|---|---|
| El patinet no s'encén. | Bateria baixa; botó d'engegada no premut correctament. | Charge the battery fully. Press and hold the power button firmly. |
| Scooter not balancing. | Incorrect foot placement; sensor calibration issue. | Ensure feet are centered on footpads. Refer to the app for calibration options if available. |
| L'altaveu Bluetooth no es connecta. | Bluetooth not enabled on device; scooter not in pairing mode. | Ensure scooter is on. Check device's Bluetooth settings. Restart both devices. |
| Velocitat o autonomia reduïdes. | Low battery; riding on inclines or rough surfaces; rider weight. | Fully charge the battery. Ride on flat, smooth surfaces. Ensure rider weight is within limits. |
8. Especificacions
| Característica | Detall |
|---|---|
| Nom del model | ORIGIN (H1-ORGN-BLK) |
| Velocitat màxima | Fins a 7 mph |
| Interval màxim | Fins a 6 milles |
| Potència del motor | 400 W (200 W x 2) |
| Inclinació màxima | Fins a 10° |
| Mida de la roda | 6.5 polzades |
| Tipus de bateria | 25.2V/4.0Ah Lithium-ion |
| Temps de càrrega complet | 5 hores |
| Resistència a l'aigua | IPX-4 |
| Versió Bluetooth | 4.0 |
| Pes de l'article | 18.7 lliures |
| Dimensions (LxWxH) | 26 x 9 x 10 polzades |
| Material | Alumini, plàstic |
Figure 8.1: Performance Capabilities. This image illustrates the Hover-1 Origin's ability to climb inclines of up to 10 degrees and highlights its powerful 400W brushless motor, emphasizing its performance features.
Figure 8.2: Speed and Range. This image visually represents the Hover-1 Origin's maximum speed of 7 mph and its impressive range of up to 6 miles on a single charge, showcasing its efficiency for personal transport.
9. Garantia i Suport
9.1 Informació de la garantia
The Hover-1 Origin Electric Self Balancing Scooter comes with a 90 dies de garantia des de la data de compra. Aquesta garantia cobreix els defectes de fabricació en condicions d'ús normal. Si us plau, conserveu el comprovant de compra per a reclamacions de garantia.
9.2 Atenció al client
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Hover-1 customer support. Refer to the official Hover-1 weblloc web o la documentació de la compra per obtenir les dades de contacte.
