Introducció
The Bioby Electric Baby Swing is designed to provide a safe, comfortable, and engaging environment for infants. Featuring multiple swing speeds, built-in music, Bluetooth connectivity, and a remote control, this portable baby swing aims to offer hands-free parenting convenience while ensuring your baby's well-being. It includes a 5-point harness for security and a removable mosquito net for protection.
Informació important de seguretat
Please read all instructions before assembly and use of the baby swing. Keep this manual for future reference. Failure to follow these warnings and instructions could result in serious injury or death.
- ADVERTIMENT: No deixeu mai el nen sense vigilància.
- ADVERTIMENT: Do not use this product once your child can sit up unaided or weighs more than 20 lbs (9 kg).
- ADVERTIMENT: Aquest producte no està pensat per a períodes prolongats de son.
- ADVERTIMENT: Always use the restraint system. Ensure the harness is properly adjusted and secured.
- ADVERTIMENT: No moveu ni aixequeu el producte amb el nen dins.
- ADVERTIMENT: Mantingueu les peces petites allunyades dels nens.
- Ensure the swing is placed on a flat, stable surface.
- No l'utilitzeu a prop d'escales o graons.
- Regularly inspect the product for loose parts, damaged components, or torn materials. Discontinue use if any damage is found.
Contingut del paquet
Verifiqueu que tots els components siguin presents abans del muntatge:
- Main Swing Unit (Base and Seat Frame)
- Seat Cover & Pillow
- Dosser amb mosquitera
- Hanging Toys (Star and Moon)
- Control remot
- Power Adapter (USB cable and wall adapter)
- Manual d'usuari (aquest document)
Muntatge i muntatge
Follow these steps to assemble your Bioby Electric Baby Swing:
- Assemble the Base Bracket:
Insert the two curved base pieces into the central motor unit until they click securely into place. Ensure they are fully seated and stable.
Image: Step-by-step visual guide for assembling the base bracket.
- Attach the Seat Frame:
Align the seat frame with the top of the assembled base. Push down firmly until it locks into position. You should hear a click indicating it's secure.
- Install Seat Cover & Pillow:
Slide the fabric seat cover over the seat frame, ensuring it fits snugly. Secure the cover using the zippers and Velcro straps located on the underside and back of the seat. Attach the head pillow to the top ring of the seat with its Velcro.
Image: Detailed steps for attaching the seat cover and head pillow.
- Attach the Canopy with Toys:
Fasten the canopy clasps to the designated points on the seat frame pipe. The canopy includes a removable mosquito net. To attach the mosquito net, tie the small Velcro strap around the swivel part of the swing, ensuring it covers the opening completely. You can also hang the two included toys (star and moon) from the canopy bar.
Image: The fully assembled swing, demonstrating the canopy and hanging toys.
- Connectar l'alimentació:
Plug the power adapter into the swing's power port and then into a standard electrical outlet. The swing can also be powered by a power bank for portable use.
Instruccions de funcionament
The Bioby Electric Baby Swing can be operated via the touch screen panel on the base or the included remote control.
Funcions del tauler de control:
- Botó d'encesa: Turns the swing on/off.
- Swing Speed Buttons: Adjusts between 5 gentle swing speeds.
- Botons del temporitzador: Sets the swing timer for 8, 15, or 30 minutes.
- Music/Sound Buttons: Selects from 8 preset melodies or natural sounds.
- Botó Bluetooth: Activates Bluetooth for playing custom music from your device.
- Control de volum: Ajusta el volum d'àudio.
Funcions de control remot:
The remote control duplicates most functions of the touch panel for convenient operation from a distance.
Image: Layout and functions of the remote control.
- Engegada (botó vermell): Turns the swing on/off.
- Music (Blue Button): Commuta la reproducció de música.
- Timer (Green Button): Cycles through timer settings (8, 15, 30 minutes).
- Pujar/baixar el volum: Adjusts music volume.
- Cançó següent/anterior: Skips between preset melodies.
- Swing Speed (1-5 Buttons): Directly selects swing speed.
- AUTO (Yellow Button): Activates automatic swing mode.
- STOP (Orange Button): Stops the swing motion.
Connectivitat Bluetooth:
To connect your device via Bluetooth, press the Bluetooth button on the control panel or remote. Cerca "Bioby Swing" on your device's Bluetooth settings and pair. Once connected, you can play your baby's favorite lullabies or sounds directly through the swing's speaker.
Manteniment
Proper maintenance ensures the longevity and safety of your Bioby Electric Baby Swing.
- Neteja del teixit: The seat cushion is removable and machine-washable. Use a gentle cycle with cold water and mild detergent. Air dry or tumble dry on low heat. Do not bleach.
- Neteja del marc: Netegeu les parts de plàstic i metall del marc amb anuncisamp cloth and mild soap. Do not immerse the base unit in water.
- Emmagatzematge: When not in use, the swing can be easily detached and folded for compact storage. Store in a cool, dry place away from direct sunlight.
Image: Demonstrating the ease of removing the seat cover for cleaning.
Resolució de problemes
If you encounter issues with your Bioby Electric Baby Swing, refer to the following common problems and solutions:
| Problema | Causa possible | Solució |
|---|---|---|
| Swing does not turn on. | Not plugged in; power adapter issue. | Ensure power adapter is securely plugged into the swing and a working outlet. Try a different outlet. |
| Swing motion is weak or inconsistent. | Low power; weight exceeds limit; obstruction. | Ensure the swing is properly powered. Verify child's weight is within the 20 lbs limit. Check for any obstructions around the swing mechanism. |
| El Bluetooth no es connecta. | Device too far; swing not in pairing mode. | Ensure your device is within range. Press the Bluetooth button on the swing or remote to activate pairing mode. Restart both devices. |
| El comandament a distància no funciona. | Battery depleted; obstruction. | Replace the CR2032 battery in the remote control. Ensure no objects are blocking the signal between the remote and the swing. |
Especificacions
- Dimensions del producte: 27.6 "P x 24.4" W x 27.6" H
- Número de model de l'article: POA8202219
- Pes màxim recomanat: 20 lliures
- Tipus de material: Aluminum (frame), Polycotton (fabric)
- Font d'alimentació: Battery Powered (CR2032 for remote, included) / AC Adapter (5V/1A output)
- Pes de l'article: 7.27 lliures
- Característiques: 5 Swing Speeds, 3 Timer Options (8/15/30 mins), 8 Preset Music/Sounds, Bluetooth, Touch Screen/Remote Control, 5-Point Harness, Removable Mosquito Net, Portable.
Garantia i Suport
Bioby products are manufactured with high-quality materials and craftsmanship. For warranty information, technical support, or to purchase replacement parts, please contact Bioby customer service. Refer to the official Bioby website or the original product packaging for the most current contact details.
You can also find additional support and resources by visiting the Bioby Store on Amazon.
A digital version of the user guide is available at: Guia de l'usuari (PDF)
