Introducció
Thank you for choosing the Xiaomi Massage Gun. This device is designed to provide deep tissue massage, aiding in muscle recovery, reducing soreness, and improving circulation. Please read this manual thoroughly before use to ensure safe and effective operation. Keep this manual for future reference.
Informació de seguretat
no safety warning
Contingut del paquet
- Pistola de massatge Xiaomi
- Capçal de massatge rodó
- Capçal de massatge pla
- Cap de massatge de bala
- Cable de càrrega
- Maleta de transport
The Xiaomi Massage Gun comes with a convenient carrying case and three interchangeable massage heads.
Característiques del producte
- Professional brushless motor with max force of 570mN and frequency up to 3200 rpm.
- Percussion depth of 10mm for effective deep tissue massage.
- Intelligent power control detects applied pressure 25 times per second for stable output.
- Pressure indicator provides real-time feedback to prevent excessive pressure.
- Low-noise operation (as low as 45dB) for a quiet experience.
- Three replaceable massage heads: Round, Flat, and Bullet.
- Three speed modes: 1800, 2400, and 3200 rpm.
- Up to 5-hour battery life at Level 1 intensity.
- Lightweight and portable design (870g) with an easy-carry storage case.
Components i controls
Davant view of the Xiaomi Massage Gun, showcasing el seu disseny ergonòmic.
lateral view highlighting the control panel with power button and speed indicators.
Detailed top-down view of the control panel, showing the power button and three speed indicator lights.
The massage gun features a simple control panel located at the top of the handle. It includes a power button and LED indicators for speed settings and battery level.
Configuració
- Desembalar: Remove the massager from its packaging and inspect for any damage.
- Càrrec: Fully charge the device before first use. Connect the charging cable to the port on the device and plug it into a power source. The indicator lights will show charging status.
- Connecteu el capçal de massatge: Select the desired massage head (Round, Flat, or Bullet) and firmly insert it into the front opening of the massage gun. Ensure it is securely attached.
Instruccions de funcionament
- Encès: Press and hold the power button on the control panel to turn on the device. It will typically start at the lowest speed setting.
- Seleccioneu la velocitat: Briefly press the power button to cycle through the three speed modes (1800 rpm, 2400 rpm, 3200 rpm). The LED indicators will illuminate to show the selected speed.
- Aplicar al cos: Gently apply the massager to the desired body part. Move the device slowly over the muscle groups, applying appropriate pressure. The pressure indicator will provide real-time feedback.
- Durada d'ús: Use for the desired duration, typically 1-2 minutes per muscle group. Avoid excessive use on any single area.
- Apagar: Press and hold the power button again to turn off the device.
Demonstration of using the Xiaomi Massage Gun on the shoulder area.
Manteniment
- Neteja: Netegeu el dispositiu amb un suau, damp drap després de cada ús. No utilitzeu productes de neteja abrasius ni submergiu el dispositiu en aigua.
- Emmagatzematge: Store the device in its carrying case in a cool, dry place away from direct sunlight and extreme temperatures.
- Càrrega: Recharge the battery when the battery indicator shows low power. Avoid completely draining the battery for extended periods to prolong its lifespan.
- Head Care: Ensure massage heads are clean and free of debris before and after use.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| El dispositiu no s’encén. | La bateria està esgotada. | Carregueu el dispositiu completament. |
| El dispositiu s'atura durant l'ús. | Sobreescalfament o bateria baixa. | Allow device to cool down. Recharge if battery is low. |
| Weak percussion. | Bateria baixa o configuració de velocitat incorrecta. | Recharge the device. Increase the speed setting. |
| Sorolls o vibracions inusuals. | Capçal de massatge no ben fixat o problema intern. | Ensure massage head is securely attached. If problem persists, contact customer support. |
Especificacions
| Atribut | Valor |
|---|---|
| Marca | Xiaomi |
| Número de model | MJJMQ04-ZJ |
| Pes de l'article | 870 grams |
| Dimensions del producte | 24.64 x 16.91 x 2.7 cm |
| Material | Silicona |
| Font d'alimentació | Funciona amb bateria |
| Freqüència nominal | Fins a 3200 rpm |
| Percussion Depth | 10 mm |
| Battery Life (Level 1) | 5 hores |
Garantia i Suport
The Xiaomi Massage Gun comes with a standard manufacturer's warranty. Please refer to the warranty card included in your package for specific terms and conditions. For technical support, troubleshooting assistance, or warranty claims, please contact Xiaomi customer service through their official weblloc web o el venedor on es va comprar el producte.
For more information, visit the official Xiaomi weblloc: www.mi.com
