Yealink BH76 Wireless Headset Instruction Manual

1. Introducció

This manual provides detailed instructions for the setup, operation, and maintenance of your Yealink BH76 Wireless Headset. Designed for professional communication and high-fidelity audio, the BH76 features Active Noise Canceling (ANC), a retractable microphone arm, and versatile connectivity options.

2. Què hi ha a la caixa

• Auriculars Bluetooth Yealink BH76
• USB-A Dongle (BT51-A) or USB-C Dongle (BT51-C)
• 1.2m USB2.0 USB-A to Type-C Cable
• Maleta de transport
• Guia d'inici ràpid
• Optional: BH76 Wireless Charging Stand and Power Adapter

Image: Yealink BH76 Headset with its included accessories, including the headset, USB dongle, charging cable, and carrying case.

3. Producte acabatview

Botons i indicadors LED

Image: Close-up of the Yealink BH76 headset showing the various buttons and LED indicators on the earcup.

• Botó d'encesa: Located on the right earcup.
• Botons de pujar / baixar de volum: Ajusta el volum de l'àudio.
• Botó multifunció (MFB): Controls calls and media playback.
• Botó ANC: Toggles Active Noise Canceling modes.
• Busylight Indicator: Located on the side of the earcups.
• Indicador LED: Mostra l'estat d'energia, emparellament i càrrega.
• Retractable Microphone Arm: Pull out to use, push in to hide.

4. Configuració

4.1. Encendre/apagar

• Per encendre: Press and hold the Power button for 2 seconds. The LED indicator will glow green.
• Per apagar: Press and hold the Power button for 2 seconds. The LED indicator will glow red.

4.2. Connexió Bluetooth

The BH76 headset can connect to mobile devices and PCs via Bluetooth.

Connecta't al dispositiu mòbil:

1. Assegureu-vos que els auriculars estan apagats.
2. Press and hold the Power button for 5 seconds until the LED flashes red and green alternately, indicating pairing mode.
3. On your mobile device, enable Bluetooth and select "Yealink BH76" from the list of available devices.
4. Once paired, the LED will glow green, and you will hear "Mobile1 Connected" from the headset.

Connect to PC (via USB Dongle):

1. Plug the USB dongle (BT51-A or BT51-C) into an available USB port on your PC.
2. The dongle and headset are pre-paired and will automatically connect after insertion. The LED on the dongle will turn solid blue when connected.

4.3. USB Connection (Wired Mode)

You can also use the headset in wired mode by connecting it directly to your PC using the provided USB-A to Type-C cable. This mode also charges the headset.

5. Instruccions de funcionament

5.1. Call Controls

• Respon a la trucada: Press the MFB or pull out the microphone arm.
• Rebutja la trucada: Premeu el MFB dues vegades.
• Finalitzar la trucada: Premeu el MFB.
• Hold Current Call & Answer New Call: Manteniu premut el MFB durant 1.5 segons.
• End Current Call & Answer New Call (UC Edition only): Premeu el MFB.
• Reject New Call & Keep Current Call: Premeu el MFB dues vegades.
• Torna a marcar la darrera trucada: Press the MFB twice (device must support Redial Function).
• Silenciar/activar el micròfon: Press the Mute button or push in/pull out the microphone arm.
• Ajustar el volum: Feu servir els botons de pujar/baixar el volum.

5.2. Controls de música

• Reprodueix/Pausa contingut multimèdia: Premeu el MFB.
• Pista següent: Premeu i manteniu premut el botó de pujar el volum durant 1.5 segons.
• Pista anterior: Premeu i manteniu premut el botó per baixar el volum durant 1.5 segons.

5.3. Sensor intel·ligent

The headset features a smart sensor that can automatically pause media when removed and resume when put back on. It can also answer calls automatically when you put on the headset during an incoming call.

5.4. Cancel·lació activa de soroll (ANC)

The BH76 offers Intelligent Dynamic ANC with four modes:

• ANC Medium: Provides moderate noise cancellation.
• ANC alt: Provides maximum noise cancellation.
• Ambient Sound (Talk Mode): Allows you to hear your surroundings while wearing the headset.
• Apagat: Disables ANC.

Premeu el botó ANC per anar ciclant entre aquests modes.

Image: Illustration of the Intelligent Dynamic ANC feature, showing different levels of noise cancellation: Fully Transparent, Talk Transparent, ANC Level Medium, and ANC Level High.

5.5. Llum d'ocupació

The ultra-wide angle visible busylight automatically activates during calls to signal your availability. You can also manually activate it by pressing the Volume Up and Volume Down buttons simultaneously when not in a call.

Image: The Yealink BH76 headset displaying its ultra-wide angle visible busylight, designed to indicate user availability.

5.6. Ús del micròfon

The BH76 features a retractable hidden microphone arm with five noise-cancellation microphones and Yealink Acoustic Shield Technology for clear voice transmission in noisy environments.

Image: The Yealink BH76 headset with its retractable microphone arm extended, ready for use.

Image: An illustration demonstrating the retractable hidden microphone arm of the Yealink BH76, allowing for a quick switch between communication and casual listening.

6. Càrrega

6.1. Wireless Charging (Optional)

If you have the optional BH76 Wireless Charging Stand, align the middle of the headset's charging area with the charging icon on the stand. It takes approximately 3 hours to fully charge, providing up to 35 hours of talk time.

Image: The Yealink BH76 headset on its wireless charging stand, illustrating its easy charging and long battery life capabilities.

6.2. Càrrega USB

Connect the headset to a power source (e.g., PC, USB wall adapter) using the provided USB-A to Type-C cable. It takes approximately 2 hours to fully charge, providing up to 35 hours of talk time.

7. Gestió de dispositius

7.1. Yealink USB Connect Software

Use the Yealink USB Connect software on your PC to personalize and manage your headset. This software allows you to check device status, update firmware, and configure settings. Download it from the official Yealink weblloc: www.yealink.com/product/yuc.

7.2. Yealink Connect App

Manage your Yealink headset from your mobile device using the Yealink Connect App. It provides features like adjusting headset status, updating firmware, finding your headset, and accessing technical support. Download the app from the iOS App Store or Android App Store.

8. Especificacions

9. Solució De Problemes

If you encounter any issues with your Yealink BH76 headset, please refer to the following general troubleshooting steps:

• Sense energia: Ensure the headset is fully charged. Connect it to a power source using the USB cable or place it on the wireless charging stand.
• No es pot emparellar: Ensure the headset is in pairing mode (LED flashing red and green). Check that Bluetooth is enabled on your device and that the headset is within range. Try restarting both the headset and your device.
• Mala qualitat d'àudio: Check the connection stability. Ensure the microphone arm is properly extended if you are speaking. Adjust ANC settings to suit your environment.
• El micròfon no funciona: Ensure the microphone arm is pulled out and not muted. Check your device's audio input settings to confirm the headset is selected.
• Connectivitat intermitent: Ensure there are no obstructions between the headset and your device/dongle. Move closer to your connected device. Avoid environments with high electromagnetic interference.

For more detailed troubleshooting or persistent issues, please consult the Yealink support weblloc o contacteu amb el servei d'atenció al client.

10. Informació de seguretat

Please read and follow all safety instructions to prevent injury or damage to your device:

• No exposeu els auriculars a temperatures extremes, humitat ni líquids.
• Eviteu deixar caure els auriculars ni sotmetre'ls a impactes forts.
• Feu servir només carregadors i accessoris aprovats.
• No intenteu desmuntar ni modificar els auriculars.
• Mantenir fora de l'abast dels nens.
• Dispose of the headset and its components responsibly according to local regulations.

11. Suport

For further assistance, technical support, or warranty information, please visit the official Yealink support weblloc web o poseu-vos en contacte amb el vostre distribuïdor local.

Yealink Official Weblloc: www.yealink.com
