Instruccions importants de seguretat
Please read all instructions carefully before using your Krups GN9101 3 Mix 9000 Hand Mixer. Keep this manual for future reference.
- Desendolleu sempre l'aparell de la xarxa elèctrica abans del muntatge, desmuntatge o neteja.
- No submergiu la unitat del motor en aigua ni en cap altre líquid. Netegeu-la amb un adhesiu.amp només tela.
- Mantingueu les mans, els cabells, la roba, així com les espàtules i altres estris allunyats dels batedors durant el funcionament per evitar lesions i danys a l'aparell.
- Aquest aparell no està pensat per ser utilitzat per persones (inclosos nens) amb capacitats físiques, sensorials o mentals reduïdes, o amb manca d'experiència i coneixements, tret que hagin rebut la supervisió o instruccions sobre l'ús de l'aparell per una persona responsable de la seva seguretat.
- Els nens han de ser supervisats per assegurar-se que no juguin amb l'aparell.
- Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions, or has been dropped or damaged in any manner.
- Utilitzeu només els accessoris recomanats o venuts pel fabricant.
- No utilitzar a l'aire lliure.
Producte acabatview
Familiarize yourself with the components of your Krups GN9101 3 Mix 9000 Hand Mixer.
The Krups GN9101 3 Mix 9000 Hand Mixer, shown with both whisk and kneading hook attachments. This powerful 750W mixer is designed for versatile kitchen tasks.
Un detallat view of the speed selector and Turbo button on the top of the mixer. The red indicator shows the current speed setting.
Components:
- Unitat motora: The main body containing the motor, controls, and attachment ports.
- Whisks (Beaters): Used for whipping cream, egg whites, and light batters. Made of stainless steel.
- Kneading Hooks: Used for mixing and kneading heavier doughs. Made of stainless steel.
- Selector de velocitat: Slide control to adjust mixing speed (7 speeds).
- Botó Turbo: Provides an instant burst of maximum power.
- Botó d'expulsió: Releases the attachments.
Configuració
Before first use, ensure all packaging materials are removed and clean the attachments as described in the "Maintenance & Cleaning" section.
Accessoris de fixació:
- Ensure the mixer is unplugged from the power outlet.
- Identify the correct slots for each attachment. The whisk and kneading hook shafts are designed to fit into specific ports on the underside of the mixer.
- Insert the desired attachments (whisks or kneading hooks) into the corresponding holes on the underside of the mixer until they click into place. Ensure they are securely fastened.
The underside of the mixer, illustrating the two distinct ports for inserting the whisk or kneading hook attachments. Note the different shapes for correct insertion.
Instruccions de funcionament
The Krups GN9101 offers 7 speed settings, a Turbo mode, and a Pulse function for optimal control over your mixing tasks.
Funcionament general:
- Attach the appropriate accessories (whisks for light mixtures, kneading hooks for dough).
- Plug the mixer into a suitable power outlet (220V).
- Place the attachments into the ingredients before turning on the mixer to prevent splashing.
- Slide the speed selector to your desired speed setting (1-7). Start with a lower speed and gradually increase as needed.
- For an immediate burst of maximum power, press and hold the Turbo button. Release to return to the selected speed.
- To use the Pulse function, quickly slide the speed selector to the highest setting and back. This provides short bursts of power.
- When finished, slide the speed selector to the "0" (off) position and unplug the mixer.
- Press the eject button to release the attachments.
The hand mixer in action, demonstrating its use with whisks to mix ingredients in a bowl. The ergonomic handle provides a comfortable grip during operation.
A user's hand demonstrating the comfortable and secure grip provided by the ergonomic design of the Krups hand mixer, essential for prolonged use.
Ús recomanat:
| Tasca | Adjunts | Configuració de velocitat | Notes |
|---|---|---|---|
| Crema per muntar | Batedors | 5-7 (Turbo for stiff peaks) | Ensure cream is very cold. |
| Beating Egg Whites | Batedors | 4-7 (Turbo for stiff peaks) | Use a clean, dry bowl. |
| Mixing Cake Batters | Batedors | 3-5 | Mix until just combined. |
| Kneading Dough | Kneading Hooks | 1-3 | No sobrecarregueu la batedora. |
Manteniment i Neteja
Una neteja i un manteniment adequats garantiran la longevitat i el rendiment òptim de la batedora de mà.
- Desconnecteu sempre l’aparell abans de netejar.
- Unitat motora: Netegeu la unitat del motor amb l'anunciamp cloth. Do not immerse it in water or any other liquid. Do not use abrasive cleaners or scouring pads.
- Attachments (Whisks and Kneading Hooks): The stainless steel whisks and kneading hooks are dishwasher safe. Alternatively, they can be washed by hand in warm, soapy water, then rinsed and dried thoroughly.
- Emmagatzematge: Store the mixer and its attachments in a dry place. The compact design allows for easy storage in cabinets.
The compact design of the Krups hand mixer allows for convenient storage in a kitchen cabinet, saving counter space.
Resolució de problemes
Si teniu algun problema amb la batedora de mà, consulteu els següents problemes i solucions habituals:
| Problema | Causa possible | Solució |
|---|---|---|
| La batedora no s'encén. | Not plugged in; Power outlet issue; Overheating. | Ensure the mixer is securely plugged into a working outlet. Check your circuit breaker. If the mixer has been used continuously for a long period, allow it to cool down for 15-20 minutes. |
| Els fitxers adjunts són difícils d'inserir/expulsar. | Incorrect alignment; Debris in ports. | Ensure attachments are aligned correctly with their respective ports. Check for any food debris or obstructions in the ports and clean if necessary. |
| El motor sona esforçat o alenteix. | Mixture is too thick; Overloaded. | Reduce the quantity of ingredients or add more liquid to thin the mixture. Use a lower speed setting for very thick mixtures or dough. Do not exceed recommended capacities. |
| Soroll o olor inusuals. | Internal issue; Overheating. | Immediately unplug the mixer. Allow it to cool down. If the problem persists after cooling, contact customer support. Do not attempt to repair the appliance yourself. |
Especificacions
- Model: GN9101
- Marca: Krups
- Potència: 750 watts
- Voltage: 220 Volts
- Nombre de velocitats: 7
- Característiques especials: Turbo boost, Pulse function
- Material: Acer inoxidable (accessoris)
- Dimensions (L x A x A): 9.5 x 25 x 30.5 cm (aproximadament 3.7 x 9.8 x 12 polzades)
- Pes: 1.56 quilograms (aproximadament 3.44 lliures)
- País d'origen: Xina
Garantia i Suport
Krups products are designed for durability and performance. While specific warranty details may vary by region, Krups generally offers a limited warranty against defects in materials and workmanship.
For warranty claims, technical support, or to inquire about spare parts, please visit the official Krups website or contact their customer service department in your region. Please have your model number (GN9101) and proof of purchase ready when contacting support.
You can find more information and contact details on the official Krups weblloc: www.krups.com
