Informació important de seguretat
Please read this instruction manual carefully before installation and use. Keep this manual for future reference.
Avís: This mirror can break and has sharp edges. Handle and mount with extreme caution to prevent injury.
Assegureu-vos que el subministrament elèctric estigui desconnectat abans de qualsevol treball d'instal·lació o manteniment.
The mirror has an IP44 waterproof rating, making it suitable for bathroom environments. However, avoid direct water spray onto electrical components.
Configuració i instal·lació
The EMKE LED Bathroom Mirror is designed for wall mounting. All necessary mounting hardware, including screws and anchors, is supplied with the mirror.
Eines necessàries (no incloses):
- Cinta mètrica
- Trepant de martell
- Tornavís
- Martell
Passos d'instal·lació:
- Carefully unpack the mirror and inspect it for any damage.
- Choose a suitable location on the wall, ensuring it is structurally sound and has access to an electrical connection.
- Measure and mark the drilling points for the mounting brackets on the wall.
- Drill holes at the marked points and insert the provided anchors.
- Secure the mounting brackets to the wall using the supplied screws.
- Connect the mirror's electrical wiring to your household electrical system. This step should be performed by a qualified electrician to ensure safety and compliance with local regulations.
- Carefully hang the mirror onto the secured mounting brackets. Ensure it is stable and level.
Image: Installation diagram illustrating the steps for mounting the mirror and connecting power.
Image: Back of the mirror with mounting brackets and wiring details.
Adjustable Hanging Strap:
The mirror features an adjustable leather strap for flexible hanging options. The strap has 4 holes for length adjustment and is removable if not desired.
Image: Detail of the adjustable leather hanging strap.
Image: Illustration of the strap's adjustability and removable feature.
Instruccions de funcionament
The EMKE LED Bathroom Mirror is equipped with a touch-sensitive switch for easy control of the integrated LED lighting.
Activació/desactivació:
Locate the touch button on the mirror surface. A single short press will turn the LED light on or off. The button illuminates milky white when the light is on and blue when the light is off, providing clear visual feedback.
Image: Operating the touch switch to turn the light on or off.
Ajust de brillantor:
To adjust the brightness of the LED light, press and hold the touch button. The brightness will progressively increase or decrease. Release the button when the desired brightness level is reached. The mirror supports brightness levels from 10% to 100%.
Image: Visual representation of brightness adjustment from 10% to 100%.
Funció d'estalvi d'energia:
The mirror is designed with an energy-saving feature that automatically turns off the LED light after 3 hours of no interaction. This helps conserve energy and extends the lifespan of the LEDs.
Image: Automatic power cut-off after 3 hours of inactivity.
Manteniment
Regular maintenance will ensure the longevity and optimal performance of your EMKE LED Bathroom Mirror.
Neteja de la superfície del mirall:
- Use a soft, lint-free cloth and a non-abrasive glass cleaner.
- Spray the cleaner onto the cloth, not directly onto the mirror, to prevent liquid from seeping into the electrical components.
- Wipe the mirror surface gently until clean and streak-free.
- Avoid using harsh chemicals, abrasive cleaners, or sharp objects that could scratch the mirror or damage the frame.
Manteniment de la llum LED:
The integrated LED lights have a lifespan of approximately 50,000 hours and are not user-replaceable. If the LED lights malfunction, please contact customer support.
Frame and Strap Maintenance:
Wipe the black aluminum frame and leather strap with a damp cloth to remove dust and dirt. Ensure the strap remains securely attached.
Resolució de problemes
If you encounter any issues with your EMKE LED Bathroom Mirror, please refer to the following troubleshooting guide:
| Problema | Causa possible | Solució |
|---|---|---|
| El llum LED no s'encén. | Sense font d'alimentació. Connexió elèctrica defectuosa. Touch switch malfunction. | Check if the main power supply to the mirror is active. Verify electrical connections (consult a qualified electrician). Try pressing the touch switch multiple times. If unresponsive, contact support. |
| LED light flickers or is dim. | Font d'alimentació inestable. Partial LED failure. | Assegureu-vos d'una font d'alimentació estable. If flickering persists or dimness is uneven, contact customer support. |
| L'interruptor tàctil no respon. | Dirt or moisture on the switch. Problema elèctric. | Clean the touch switch area with a dry, soft cloth. Disconnect and reconnect power to reset. If the issue persists, contact support. |
| Mirror automatically turns off. | Energy-saving feature activated. | This is a normal function. The mirror will turn off after 3 hours of inactivity. Simply press the touch switch to turn it back on. |
If the problem persists after attempting these solutions, please contact EMKE customer support.
Especificacions
| Característica | Detall |
|---|---|
| Número de model | TOLM04BT-EMKE-FR |
| Dimensions del producte | 70L x 70W centimeters (Diameter 70 cm) |
| Temperatura de color clar | 6500K (Cool White Light) |
| Característica especial | Illuminated, Touch Switch, Adjustable Brightness, Energy Saving (Auto-off after 3 hours) |
| Material del marc | Alumini (Negre) |
| Material del mirall | Vidre |
| Tipus de muntatge | Muntatge de paret |
| Classificació IP | IP44 |
| Vida útil del LED | 50,000 hores |
| Pes de l'article | 6.3 quilos |
| Components inclosos | Bathroom mirror, Mounting accessories, Assembly instructions |
Informació sobre l'etiqueta energètica:
Per obtenir informació detallada sobre l'eficiència energètica, consulteu la base de dades EPREL:
Fitxa informativa del producte EPREL
Image: Energy label for the EMKE LED Bathroom Mirror.
Image: Detailed product data sheet.
Garantia i Suport
Specific warranty details are not provided in this manual. For warranty information, please refer to your purchase documentation or contact the retailer where you purchased the product.
Atenció al client:
If you have any questions, require technical assistance, or need to report a problem with your EMKE LED Bathroom Mirror, please contact EMKE customer service through the retailer's platform or the official EMKE weblloc.
