EMKE LED Round Bathroom Mirror 60 cm

1. Introducció

Thank you for choosing the EMKE LED Round Bathroom Mirror. This manual provides essential information for the safe installation, operation, and maintenance of your new mirror. Please read it thoroughly before installation and keep it for future reference.

A round LED bathroom mirror, 60 cm in diameter, featuring an illuminated edge and integrated touch controls for power and light settings.

2. Advertències de seguretat

Caution: This is a fragile item. Handle with extreme care during unpacking, installation, and use.

• Always use appropriate safety measures, such as protective gloves and eyewear, when installing wall-mounted items.
• Ensure the installation surface is structurally sound and capable of supporting the mirror's weight.
• Keep the mirror and its components out of reach of children and pets.
• Tot el treball elèctric ha de ser realitzat per un electricista qualificat i complir amb les normes elèctriques locals.
• Do not attempt to modify or repair the mirror yourself. Contact customer support for assistance.
• Disconnect power at the circuit breaker before any installation or maintenance.

3. Contingut del paquet

Verifiqueu que tots els components siguin presents i no estiguin danyats abans de continuar amb la instal·lació:

• EMKE LED Round Bathroom Mirror (Model 2, 60 cm)
• Material de muntatge (cargols, ancoratges de paret)
• Manual d'instruccions (aquest document)

Note: The product does not include a power plug or an external wall switch. Professional installation is recommended.

4. Configuració i instal·lació

4.1 Preinstal·lació

1. Measure Installation Space: Before installation, carefully measure the available space to ensure the 60 cm diameter mirror fits correctly.
2. Desconnexió d'alimentació: Desconnecteu l'alimentació principal de la zona d'instal·lació al disjuntor.
3. Identificar el cablejat: Locate the electrical wires (Live, Neutral, Ground) in the wall where the mirror will be mounted.

4.2 Muntatge del mirall

1. Marcatge: Hold the mirror against the wall at the desired height and use a pencil to mark the positions for the mounting brackets. Refer to the diagram for bracket spacing.
2. Perforació: Drill holes at the marked positions. Insert appropriate wall anchors if necessary.
3. Suports segurs: Attach the mounting brackets securely to the wall using the provided screws.
4. Cablejat: Connect the mirror's electrical wires to your household wiring. Ensure correct connections: Live to Live, Neutral to Neutral, and Ground to Ground. Use appropriate wire connectors.
5. Muntanya del mirall: Carefully hang the mirror onto the secured wall brackets. Ensure it is stable and level.

This diagram provides the physical dimensions of the mirror (600mm diameter, 30mm thickness) and details the electrical wiring connections required for installation, including live, neutral, and ground wires. It also notes that the product does not include a plug or wall switch.

4.3 Postinstal·lació

1. Restaura l'alimentació: Once the mirror is securely mounted and wired, restore power at the circuit breaker.
2. Funcionalitat de prova: Test the mirror's touch controls and light functions.

5. Instruccions de funcionament

The EMKE LED mirror features intuitive touch controls for easy operation.

Detail of the mirror's touch controls: a square button for power (on/off) and a circular 'M' button for cycling through 3 light colors and adjusting brightness. The buttons glow milky white when active and blue when off.

5.1 Encès/Apagat

• Toqueu square touch button to turn the LED illumination on or off.
• When the mirror is off, the button will glow blue. When on, it will glow milky white.

5.2 Adjusting Light Color

• With the mirror on, tap the circular 'M' touch button to cycle through the three available light color temperatures:
• Blanc fred (6500K): Bright, crisp light for detailed tasks.
• Blanc neutre (4000K): Balanced illumination for general use.
• Blanc càlid (3000K): Soft, ambient light for relaxation.

This graphic demonstrates the mirror's ability to switch between three color temperatures (cool white 6500K, neutral white 4000K, warm white 3000K) with a single tap, and its stepless dimming capability from 10% to 100% brightness by long-pressing the 'M' button.

5.3 Ajust de la brillantor (reducció de la llum)

• Per ajustar la brillantor, long-press the circular 'M' touch button. The brightness will gradually increase or decrease. Release the button when the desired brightness level is reached.
• The mirror features stepless dimming from 10% to 100%.

5.4 Funció de memòria

• The mirror includes a memory function that retains the last used brightness and color temperature settings when turned off and on again.

5.5 Apagada automàtica

• For energy saving, the LED illumination will automatically turn off after 3 hours of continuous operation.

This image illustrates the mirror's energy-saving feature, which automatically turns off the LED illumination after 3 hours of continuous operation.

5.6 External Wall Switch Compatibility

• If an external wall switch is used to control the mirror's power, ensure the wall switch remains in the 'on' position for the mirror's integrated touch controls to function.

This image clarifies that if an external wall switch is used, it must remain in the 'on' position for the mirror's integrated touch controls to function.

6. Manteniment

To ensure the longevity and optimal performance of your EMKE LED mirror, follow these maintenance guidelines:

• Neteja: Utilitzeu un suau, damp cloth and a mild, non-abrasive glass cleaner to clean the mirror surface. Avoid harsh chemicals or abrasive materials that could damage the mirror or its finish.
• Seguretat elèctrica: Before cleaning or performing any maintenance, always disconnect power to the mirror at the circuit breaker.
• Inspecció: Periodically inspect the mirror and its wiring for any signs of damage or wear. If any issues are found, discontinue use and contact customer support.
• Exposició a l'aigua: While the mirror has an IP44 rating for water resistance, avoid direct water spray or prolonged exposure to excessive moisture.

7. Solució De Problemes

If you encounter any issues with your EMKE LED mirror, refer to the following troubleshooting guide:

If the problem persists after attempting these solutions, please contact EMKE customer support.

8. Especificacions

Un acabatview of the mirror's functionalities, including adjustable brightness, three distinct light color options, a memory function that recalls the last setting, an automatic shut-off after 3 hours, and an IP44 rating for water resistance.

The official EU energy label for the EMKE LED mirror, indicating an energy efficiency class of F and a consumption of 6 kWh per 1000 hours. For more details, visit the Base de dades EPREL.

9. Informació de la garantia

EMKE products are manufactured to high-quality standards. For specific warranty terms and conditions applicable to your region, please refer to the warranty card included with your purchase or visit the official EMKE weblloc web. Conserveu el comprovant de compra per a reclamacions de garantia.

10. Suport i contacte

If you have any questions, require technical assistance, or need to report an issue, please contact EMKE customer support through the following channels:

• Weblloc: Visit the official EMKE weblloc web per a preguntes freqüents i informació de contacte d'assistència.
• Correu electrònic: Refer to your purchase documentation for customer service email addresses.
• Distribuïdor: Contact the retailer from whom you purchased the mirror.

Please have your model number (Model 2 60cm) and purchase date ready when contacting support.
