JCLOUD P300 Smart Scent Air Machine Instruction Manual

Welcome to Your JCLOUD P300 Smart Scent Air Machine

The JCLOUD P300 Smart Scent Air Machine utilizes advanced Cold-Air Diffusion Technology to disperse high-quality fragrance oil micro-droplets throughout your space without heat or water. Designed for efficiency, it consumes less than 0.5ml/h at its highest setting, making it an economical choice for improving air quality and creating a pleasant ambiance. This waterless diffuser is suitable for large rooms, offices, spas, and homes, covering up to 2000 square feet.

Informació important de seguretat

• Use with caution around children and pets. Avoid direct skin contact with undiluted essential oils.
• Assegureu-vos que el dispositiu estigui col·locat en una superfície plana i estable.
• No bloquegeu l'entrada ni la sortida d'aire durant el funcionament.
• Only use pure essential oils or fragrance oils specifically designed for cold-air diffusers. Do not dilute with water or other substances.
• Mantingueu el dispositiu allunyat de la llum solar directa, de fonts de calor i de flames obertes.
• Desendolleu el dispositiu abans de netejar-lo o quan no l'utilitzeu durant períodes prolongats.

Contingut del paquet

Marqueu la casella per als elements següents:

• JCLOUD P300 Smart Scent Air Machine Unit
• Adaptador d'alimentació
• 300ml Essential Oil Bottle (empty)
• Keys for secure access
• HVAC Connection Hose (for optional HVAC integration)
• Manual d'usuari

Configuració

1. Omplir l'ampolla d'oli essencial

1. Desbloquegeu el dispositiu amb la clau proporcionada.
2. Traieu l'ampolla buida d'oli essencial del dispositiu.
3. Carefully unscrew the cap from the essential oil bottle.
4. Fill the bottle with your preferred waterless essential oil (up to 300ml capacity). Do not overfill.
5. Securely screw the cap back onto the essential oil bottle.

2. Installing the Oil Bottle

1. Insert the filled essential oil bottle back into its compartment within the device.
2. Ensure the bottle is seated correctly and the top mechanism is securely in place.
3. Lock the device using the key to secure the bottle compartment.

3. Connexió d'alimentació

Connect the power adapter to the device's power port and then plug it into a standard electrical outlet.

Instruccions de funcionament

Control manual

If you choose not to use the app, the machine will operate on a default cycle: work for 10 seconds, then pause for 110 seconds, and repeat. Use the physical buttons (BACK, ENT, Up/Down arrows) on the device to adjust basic settings like time and scent grade directly.

• Encès/apagat: Hold down the ENT button.
• Restabliment de fàbrica: Press the 1st and 4th buttons (BACK and Right Arrow) simultaneously, then select 'yes' to reset to factory mode. The APP default password is 1234.
• Establir hora: Tap the Up Arrow and Right Arrow buttons simultaneously.
• Toggle Fan: Hold down the BACK button.

App Control (Aroma-Link)

For advanced control and customization, download the 'Scent Marketing' app (or 'Aroma-Link' as mentioned in some reviews) from Google Play (Android) or the APP Store (iOS).

1. Download & Install: Cerca 'Scent Marketing' in your device's app store and install it.
2. Connectar el dispositiu: Open the app, ensure Bluetooth is enabled on your phone, and follow the on-screen prompts to add your JCLOUD P300 device. The default password for the app is 1234.
3. Set Working Schedule: Within the app, you can define specific working times (Power On/Off), days of the week, and scent concentration levels (Work Time in seconds, Suspend Time in seconds).
4. Adjust Concentration: Customize the scent intensity by setting the 'Work' and 'Suspend' times. For example, 5 seconds work and 180 seconds pause for a lighter scent.
5. Control del ventilador: The app allows you to toggle the booster fan, which helps disperse fragrance more forcefully.

HVAC Connection (Optional)

The JCLOUD P300 can be integrated with your HVAC system to distribute scent throughout your entire home or commercial space more effectively.

1. Locate HVAC Duct: Identify an appropriate location on your HVAC system's outflow ductwork.
2. Forat: Carefully drill a small hole (e.g., 5/16 inch) into the duct.
3. Connecteu la mànega: Insert one end of the provided HVAC connection hose into the diffuser's designated port and the other end into the drilled hole in the HVAC duct. Ensure a secure seal (e.g., using plumber's putty).
4. Col·locació òptima: For best results, connect the hose to the outflow side of your furnace to prevent the filter from catching the fine mist.

Manteniment

Refilling Essential Oil

When the essential oil level is low, the device may indicate this on its display or via the app. Follow the steps in the 'Filling the Essential Oil Bottle' section to refill and reinsert the bottle.

Neteja

Periodically clean the exterior of the device with a soft, dry cloth. Do not use harsh chemicals or abrasive materials. Ensure no liquid enters the internal components.

Guia de resolució de problemes

Especificacions del producte

Garantia i assistència al client

Your satisfaction is our top priority. We are committed to providing exceptional customer service. If you encounter any issues or have questions regarding installation, operation, or maintenance of your JCLOUD P300 Smart Scent Air Machine, please contact us.

• Contacte: Refer to the service card included in your package or contact us via Amazon mail.
• Garantia: Information regarding product warranty and return policy is available through your purchase platform.
