Manual d'usuari de l'aspiradora sense fil INSE S10

Introducció

Thank you for choosing the INSE S10 Cordless Stick Vacuum Cleaner. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new appliance. Please read this manual thoroughly before first use and keep it for future reference.

Instruccions importants de seguretat

Seguiu sempre les precaucions de seguretat bàsiques quan utilitzeu aparells elèctrics per reduir el risc d'incendi, descàrrega elèctrica o lesions.

• No l'utilitzeu a l'aire lliure ni sobre superfícies humides.
• No permetre que s'utilitzi com a joguina. Cal prestar molta atenció quan l'utilitzen nens o a prop dels nens.
• Feu servir només tal com es descriu en aquest manual. Utilitzeu només els accessoris recomanats pel fabricant.
• No l'utilitzeu amb un cable o un endoll danyats. Si l'aparell no funciona com hauria, s'ha caigut, s'ha fet malbé, s'ha deixat a l'exterior o ha caigut a l'aigua, torneu-lo a un centre de servei.
• No estireu ni porteu el cable, no utilitzeu el cable com a nansa, no tanqueu una porta al cable ni estireu el cable per vores o cantonades afilades. No feu passar l'aparell per sobre del cable. Mantingueu el cable lluny de les superfícies escalfades.
• No desconnecteu estirant del cable. Per desconnectar, agafa l'endoll, no el cable.
• No manipuleu l'endoll o l'aparell amb les mans mullades.
• No introduïu cap objecte a les obertures. No utilitzar amb cap obertura bloquejada; mantenir lliure de pols, pelusses, cabells i qualsevol cosa que pugui reduir el flux d'aire.
• Mantingueu els cabells, la roba solta, els dits i totes les parts del cos lluny de les obertures i les parts mòbils.
• No agafeu res que estigui cremant o fumant, com ara cigarrets, llumins o cendres calentes.
• No l'utilitzeu sense el got de pols i/o els filtres al seu lloc.
• Apagueu tots els controls abans de desconnectar.
• Tingueu molta cura quan netegeu les escales.
• No l'utilitzeu per recollir líquids inflamables o combustibles, com ara la gasolina, ni l'utilitzeu en zones on puguin estar presents.
• Guardeu l'aparell a l'interior en un lloc fresc i sec.

Components del producte

Familiarize yourself with the various parts of your INSE S10 vacuum cleaner.

This image displays the INSE S10 cordless vacuum cleaner along with its various attachments, including the main motor, extension wand, floor brush, crevice tools, and wall mount. It shows the vacuum in different configurations, highlighting its versatility.

This image details the contents of the INSE S10 package, including the main motor with HEPA filter, LED-motorized cleaning head, retractable metal tube, wall mount, 2-in-1 dust brush, two crevice nozzles (one with LED light), hair cleaning tool, two pre-filters, user manual, and adapter.

• Main Motor (with HEPA Filter): The core unit containing the motor and dust collection system.
• LED-Motorized Cleaning Head: For effective cleaning of various floor types, equipped with LED lights to illuminate dark areas.
• Tub metàl·lic retràctil: Allows for adjustable length and flexible cleaning.
• Muntatge en paret: Per a un emmagatzematge i una càrrega convenients.
• 2-in-1 Dust Brush: Versatile tool for dusting and upholstery.
• Crevice Nozzles (2x, one with LED Light): For reaching tight spaces and corners, with an illuminated option for dark areas.
• Hair Cleaning Tool: For removing tangled hair from the brush roll.
• Pre-filters (2x): Essential for the multi-stage sistema de filtració.
• Adaptador: Per carregar la bateria.

Muntatge i muntatge

Follow these steps to assemble your INSE S10 vacuum cleaner.

1. Carregueu la bateria: Before first use, fully charge the battery. Connect the adapter to the battery and plug it into a power outlet. The indicator lights will show charging status.
2. Attach the Main Motor: Connect the main motor unit to the retractable metal tube. Ensure it clicks securely into place.
3. Connecteu el capçal de neteja: Connect the LED-motorized cleaning head to the other end of the retractable metal tube.
4. Install Dust Cup and Filters: Ensure the dust cup and all filters (HEPA and pre-filters) are correctly installed in the main motor unit. Refer to the "Maintenance" section for filter installation details.
5. Instal·lació a la paret (opcional): Choose a suitable location for the wall mount. Secure it to the wall using appropriate hardware (not included). This allows for convenient storage and charging.

This image illustrates the assembly process of the INSE S10, showing how the main motor connects to the extension tube and the floor brush, indicating a straightforward click-in mechanism.

Instruccions de funcionament

Learn how to effectively use your INSE S10 vacuum cleaner for various cleaning tasks.

Modes d'encesa/apagada i succió

• Instant Cleaning: Press and hold the trigger to start cleaning. Release the trigger to stop.
• Continuous Cleaning: For extended cleaning, press the lock button (usually near the trigger) to engage continuous operation without holding the trigger. Press it again to disengage.
• Ajust de potència d'aspiració: The INSE S10 features multiple suction modes (e.g., Standard, Max). Use the mode button on the main unit to cycle through the available power settings. The vacuum remembers your last used mode.

This image demonstrates the one-hand operation feature of the INSE S10, showing how to engage instant cleaning by holding the trigger and how to activate continuous cleaning by pressing a lock button, eliminating the need to constantly hold the trigger.

This image highlights the three-gear suction power adjustment feature of the INSE S10, showing the control panel with indicator lights for different power levels.

Ús d'arxius adjunts

The INSE S10 comes with various attachments for different cleaning needs:

• LED-Motorized Cleaning Head: Ideal for hard floors, carpets, and rugs. The built-in LED lights illuminate dust and debris in dark areas.
• 2-in-1 Dust Brush: Use the brush for delicate surfaces like keyboards or curtains, and the wider nozzle for upholstery or car seats.
• Crevice Nozzles: Perfect for narrow gaps, corners, and edges. The LED crevice nozzle helps clean dark, hard-to-reach spots like under furniture or car interiors.

This image showcases the versatility of the INSE S10 with its multi-purpose accessories, including a transparent crevice nozzle with LED for dark spaces, a 2-in-1 brush for upholstery, and a black crevice tool for car interiors.

This image highlights the flexible design of the INSE S10's cleaning head, showing its ability to swivel 90 degrees vertically and 150 degrees horizontally, along with the integrated LED headlights for improved visibility during cleaning.

Neteja flexible

The INSE S10 features a foldable design for easy cleaning under furniture and hard-to-reach areas without bending.

This image demonstrates the foldable design of the INSE S10, allowing the user to clean under low furniture like sofas and beds without needing to bend down, protecting the user's back.

Manteniment i cura

Regular maintenance ensures optimal performance and extends the lifespan of your INSE S10 vacuum cleaner.

Buidant el got de pols

Empty the dust cup after each use or when the MAX fill line is reached to maintain suction power.

1. Assegureu-vos que l'aspiradora estigui apagada.
2. Press the dust cup release button and remove the dust cup from the main motor unit.
3. Hold the dust cup over a trash bin and press the bottom release latch to open the lid and empty contents.
4. Close the dust cup lid securely.
5. Reattach the dust cup to the main motor unit.

Neteja de filtres

The INSE S10 features a 6-layer filtration system. Clean filters regularly to prevent clogging and maintain strong suction.

This image illustrates the innovative 6-stage HEPA filtration system of the INSE S10, showing how it captures 0.3-micron dust, processes fabrics, releases fresh air, blocks fine visible dust, traps dust particles, and separates large particles, leading to less suction loss.

• Prefiltres: These can be washed with water. Remove them from the dust cup, rinse under running water until clean, and allow them to air dry completely for at least 24 hours before reinstallation.
• Filtre HEPA: Tap the HEPA filter gently to remove loose dust. Do not wash the HEPA filter with water unless specified by the manufacturer. Replace the HEPA filter periodically (e.g., every 3-6 months, depending on usage).

This image shows the washable filter and pre-filter components of the INSE S10, submerged in water, indicating they can be cleaned by rinsing.

Neteja del rotllo del raspall

Periodically check the brush roll for tangled hair or debris. Use the provided hair cleaning tool to cut and remove any obstructions.

1. Turn off the vacuum and disconnect the cleaning head.
2. Locate the brush roll access latch on the bottom of the cleaning head.
3. Open the latch and remove the brush roll.
4. Use scissors or the hair cleaning tool to cut and remove any tangled hair or fibers.
5. Reinsert the brush roll and secure the latch.

Resolució de problemes

Consulteu aquesta secció per conèixer els problemes comuns i les seves solucions.

Especificacions

This image highlights the INSE S10's powerful suction of up to 30,000Pa / 140AW, driven by a 350W brushless motor, emphasizing its strong performance and durability.

This image compares the INSE S10's battery capacity and runtime (up to 50 minutes) with other batteries, showing it uses 7 cells compared to 4 cells in typical batteries, leading to longer operation.

Garantia i Suport

For warranty information and customer support, please refer to the warranty card included in your product packaging or contact INSE customer service directly.

Conserveu el rebut de compra com a comprovant de compra per a qualsevol reclamació de garantia.

For further assistance, visit the official INSE website or contact their support team through the contact information provided in your product documentation.
