STEELPLAY Wireless Controller User Manual

Introducció

This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your STEELPLAY Wireless Controller, model LA-0HNY-U4YG. Please read this manual carefully before using the product to ensure proper functionality and to prevent damage.

Configuració

Contingut del paquet

Verifiqueu que tots els elements siguin presents al paquet:

• STEELPLAY Wireless Controller (LA-0HNY-U4YG)
• Cable de càrrega USB
• Manual d'usuari (aquest document)

Carregant el controlador

Before first use, fully charge the controller. Connect the USB charging cable to the controller's charging port and the other end to a powered USB port (e.g., gaming console, PC, USB wall adapter).

Image: The STEELPLAY Wireless Controller with a charging cable connected. This image illustrates the controller's design and potential charging port location.

Vinculació amb un dispositiu

Follow these steps to pair your wireless controller with your gaming console or PC:

1. Assegureu-vos que el controlador estigui carregat.
2. Turn on your gaming console or PC.
3. Al controlador, premeu i manteniu premut COMPARTIR botó i el PS button simultaneously until the light bar begins to flash.
4. On your device, navigate to Bluetooth settings and select the "STEELPLAY Wireless Controller" from the list of available devices.
5. Once paired, the light bar will stop flashing and remain lit, indicating a successful connection.

Instruccions de funcionament

Controls bàsics

The STEELPLAY Wireless Controller features standard gamepad controls. Familiarize yourself with the button layout:

• Coixinet direccional (D-Pad): Per a una entrada direccional precisa.
• Manets analògics esquerre/dret: Per al moviment i el control de la càmera.
• Botons d'acció (Triangle, Cercle, Creu, Quadrat): Per a accions dins del joc.
• Botons d'espatlla (L1, R1) i gallets (L2, R2): Per a diverses funcions del joc.
• Botó COMPARTIR: To share gameplay content.
• Botó OPCIONS: To access in-game menus or pause.
• Botó PS: To access the console's home menu or power on/off the controller.
• Touch Pad: For additional input, often used for navigation or specific game mechanics.

Imatge: Una imatge detallada view of the STEELPLAY Wireless Controller, highlighting the layout of its 14 buttons, D-pad, and analog sticks.

Encès/Apagat

• Per encendre: premeu el botó PS botó.
• Per apagar: premeu i manteniu premut el botó PS button for approximately 10 seconds until the controller powers down.

Tornant a connectar

Once paired, the controller should automatically reconnect to the last paired device when powered on. If it does not, press the PS button to initiate reconnection.

Manteniment

Neteja

Per netejar el controlador, utilitzeu un drap suau i sec. Per a la brutícia resistent, netegeu lleugerament.ampen the cloth with water. Do not use harsh chemicals, solvents, or abrasive cleaners, as these can damage the controller's finish and internal components.

Emmagatzematge

Store the controller in a cool, dry place away from direct sunlight and extreme temperatures. Avoid placing heavy objects on the controller.

Cura de la bateria

The controller contains a rechargeable battery. To prolong battery life:

• Eviteu descarregar completament la bateria amb freqüència.
• Charge the controller regularly, even if not in use for extended periods.
• Do not expose the controller to temperatures above 60°C (140°F).

Resolució de problemes

El controlador no s'encén:

Ensure the controller is fully charged. Connect it to a power source using the USB cable and allow it to charge for at least 30 minutes before attempting to power it on again.

Controller does not connect or pair:

• Ensure the controller is in pairing mode (light bar flashing).
• Verify that the device you are trying to connect to has Bluetooth enabled.
• Remove any previous pairings of the controller from your device's Bluetooth settings and attempt to pair again.
• Move the controller closer to the device to ensure a strong signal.
• Restart both the controller and the device.

Input lag or unresponsive buttons:

• Ensure the controller is fully charged. Low battery can affect performance.
• Reduce interference by moving away from other wireless devices (Wi-Fi routers, other Bluetooth devices).
• If possible, try connecting the controller via a USB cable to see if the issue persists (if wired mode is supported).

Especificacions

Garantia i Suport

Specific warranty information is not provided in this manual. Please refer to the retailer's purchase terms or the manufacturer's official website for detailed warranty policies and support contact information.

For further assistance, please contact STEELPLAY customer support through their official channels.
