Introducció
This manual provides detailed instructions for the assembly, operation, and maintenance of your Sauder Briarbrook Tall Narrow Bookcase. Designed for compact display and storage, this unit features adjustable shelves and file drawers, making it suitable for various home environments. Please read all instructions carefully before beginning assembly or use.
Image: The Sauder Briarbrook Tall Narrow Bookcase, showcasing its design with open shelving and two lower drawers, finished in Barrel Oak.
Informació de seguretat
Per a la vostra seguretat i per evitar danys al producte, tingueu en compte el següent:
- Seguiu sempre les instruccions de muntatge proporcionades amb el producte.
- Assegureu-vos que tots els elements de fixació estiguin ben ajustats abans d'utilitzar-los.
- Do not overload shelves or drawers. The maximum weight limit for shelves is 50 pounds.
- This unit features an interlocking safety mechanism for drawers, allowing only one drawer to open at a time to prevent tipping. Do not attempt to force multiple drawers open simultaneously.
- Place the bookcase on a level surface to ensure stability.
- Mantingueu les peces petites allunyades dels nens durant el muntatge.
Llista de peces
Refer to the separate assembly guide included with your product for a complete and detailed list of all components and hardware. Ensure all parts are present before beginning assembly.
Instruccions de muntatge
Follow the step-by-step instructions in the included assembly manual. The following videos provide additional guidance for specific assembly components.
Cam and Dowel Assembly
This video demonstrates the correct method for assembling components using cam and dowel fasteners, a common connection type in Sauder furniture.
Video: Instructions on how to properly assemble parts using cam and dowel connectors.
Drawer Slide Separation and Installation
Learn how to separate the drawer slides from their extension rails, and how to correctly insert and remove drawers from the unit. This is essential for both assembly and future maintenance.
Video: Guide on separating drawer slides from extension rails, and inserting/removing drawers.
Instruccions de funcionament
Prestatges ajustables
The bookcase features adjustable shelves to customize your storage and display needs. To adjust a shelf:
- Traieu tots els articles de la prestatgeria.
- Aixequeu amb cura el prestatge i traieu els passadors del prestatge dels seus forats actuals.
- Torneu a inserir els passadors de la prestatgeria als nous forats desitjats, assegurant-vos que estiguin anivellats.
- Torneu a col·locar el prestatge sobre els passadors, assegurant-vos que estigui estable abans de col·locar-hi objectes.
Funcionament del calaix
Els dos file drawers are designed to hold letter or legal-size hanging files. They are equipped with full extension slides for easy access to contents. An interlocking safety mechanism prevents more than one drawer from opening at a time to maintain stability.
- Per obrir un calaix, estireu suaument la maneta.
- Per tancar, premeu el calaix amb fermesa fins que quedi completament encaixat.
- Do not force drawers open if another drawer is already extended.
Image: An open drawer of the bookcase, illustrating its capacity for letter or legal-size hanging files.
Manteniment
To ensure the longevity and appearance of your Sauder Briarbrook Bookcase:
- Neteja: Netegeu les superfícies amb un suau, damp drap. Eviteu productes químics agressius o netejadors abrasius.
- Pols: Netegeu la pols regularment amb un drap sec i suau.
- Elements de fixació: Reviseu periòdicament tots els cargols i elements de fixació per assegurar-vos que romanen ajustats. Torneu a apretar-los si cal.
- Vessaments: Clean spills immediately to prevent staining or damage to the finish.
Imatge: Un primer pla view of the Barrel Oak finish, highlighting the texture and color of the bookcase surface.
Resolució de problemes
If you encounter issues with your bookcase, consider the following common solutions:
- Unitat inestable: Ensure the bookcase is on a level surface. Check and tighten all assembly fasteners.
- Els calaixos no llisquen suaument: Verify that the drawer slides are correctly installed and free of obstructions. Refer to the "Drawer Slide Separation and Installation" video if needed.
- Drawer Interlock Issue: Confirm that only one drawer is being opened at a time. The safety mechanism is designed to prevent simultaneous opening.
- Peces que falten: If any parts are missing or damaged, contact Sauder customer support for assistance.
Especificacions
| Característica | Detall |
|---|---|
| Marca | Sauder |
| Número de model | 430268 |
| Color | Barrel Oak Finish |
| Material | Fusta dissenyada, estructura metàl·lica |
| Dimensions del producte | 18.5 "P x 18.35" W x 71.97" H |
| Pes de l'article | 77 lliures |
| Nombre de prestatgeries | 4 (including fixed top/bottom, 2 adjustable) |
| Límit de pes (per prestatge) | 50 lliures |
| Muntatge obligatori | Sí |
| Característica especial | Adjustable Shelf, File Drawers with Interlocking Safety Mechanism |
Image: A technical diagram illustrating the overall dimensions and internal drawer dimensions of the bookcase.
Garantia i Suport
For warranty information, replacement parts, or further assistance, please contact Sauder customer support. You can find contact details on the Sauder weblloc web o a la documentació inclosa amb el producte.
- Xat en directe: On-demand support may be available.
- Assembly Tip Videos: Additional helpful videos are available online.
- Peces de recanvi: Quick shipping for necessary replacement parts.
- Domestic Call Center: Ready to assist with your inquiries.
