Introducció
The Fenix CL28R is a high-performance, rechargeable work and outdoor lantern designed for versatile lighting needs. With a maximum output of 2000 lumens, it offers stepless brightness adjustment and color temperature control, making it suitable for industrial, automotive, camping, and home use. Its robust design includes a magnetic handle, tripod compatibility, and an IP66 rating for water resistance, ensuring reliable performance in various environments. The integrated 10,000mAh battery also functions as a power bank for charging other devices.
Figure 1: Fenix CL28R Rechargeable Work and Outdoor Lantern
Producte acabatview i Components
The CL28R lantern features a durable aircraft-grade aluminum body and intuitive controls. Key components include the main light source, control knobs for brightness and color temperature, a magnetic handle, and USB-A/USB-C ports for charging and power bank functionality.
Figura 2: Mésview of Fenix CL28R and its primary features including stepless brightness, stepless color temperature, magnetic handle, 45-day ultra-long runtime, and USB Type-C charging.
Figure 3: Included components: Fenix CL28R outdoor lantern, USB Type-C charging cable, key chain, user manual, and warranty card.
Figura 4: superior view of the Fenix CL28R, highlighting the control knobs for light adjustment and the USB-A and USB-C output ports, protected by a rubber cover.
Configuració
Carregant la Llanterna
The Fenix CL28R is equipped with a built-in 10,000mAh rechargeable battery. Before first use, it is recommended to fully charge the device.
- Locate the USB-C charging port on the top of the lantern, typically under a protective rubber flap.
- Connect the provided USB Type-C charging cable to the lantern's USB-C port.
- Connect the other end of the USB cable to a compatible USB power adapter (not included) or a power source.
- The charging indicator lights will illuminate to show the charging status. A full charge typically takes approximately 4 hours.
Figure 5: The Fenix CL28R can be fast charged in 4 hours, providing an ultra-long runtime of up to 45 days (based on 10-lumen mode, 8-hour use per day).
Instruccions de funcionament
Ajust d'encesa/apagada i brillantor
The CL28R features stepless brightness regulation for precise control over illumination.
- Encès: Press and hold the main power button (usually located near the charging ports) for approximately 0.5 seconds to turn the lantern on.
- Ajust de brillantor: Rotate the brightness control knob (one of the two large knobs on top) clockwise to increase brightness and counter-clockwise to decrease it. The brightness can be adjusted steplessly from low to high.
- Apagar: Press and hold the main power button for approximately 0.5 seconds to turn the lantern off.
Control de temperatura de color
Adjust the light's color temperature to suit your needs, from cool white to warm white.
- Rotate the color temperature control knob (the other large knob on top) to adjust the light from cool white to warm white, or vice versa. This adjustment is also stepless.
Modes de llum vermella
The CL28R includes red light modes for preserving night vision or signaling.
- To activate red light, with the lantern off, press and hold the main power button for approximately 1.2 seconds.
- To switch between Red Constant-On and Red Flash, short press the main power button while in red light mode.
Funció Power Bank
The CL28R can serve as a power bank to charge external devices.
- Open the protective rubber flap covering the USB-A and USB-C output ports.
- Connect your device's charging cable to either the USB-A or USB-C output port on the lantern.
- El fanal començarà a carregar el dispositiu.
Figure 6: The Fenix CL28R features both USB-C and USB-A discharging ports, allowing it to function as a power bank for charging portable digital devices.
Opcions de muntatge
The CL28R offers flexible mounting for hands-free operation.
- Magnetic Handle: The built-in magnetic handle allows the lantern to be affixed to most metal surfaces, providing hands-free lighting.
- Presa de trípode: A standard tripod socket is integrated for attaching the lantern to a tripod, enabling precise light positioning and a 160-degree wide beam angle.
Figure 7: The lantern's built-in magnetic handle allows it to be affixed to metal surfaces, providing hands-free lighting for various tasks.
Figure 8: The standard tripod socket allows for flexible mounting on tripods (purchased separately), directing the 160-degree wide beam angle where needed.
Manteniment
Proper maintenance ensures the longevity and optimal performance of your Fenix CL28R lantern.
- Neteja: Clean the lantern's body with a soft cloth. For stubborn dirt, use a slightly damp tela. No utilitzeu netejadors abrasius ni dissolvents.
- Protecció del port: Always ensure the rubber flap covering the USB ports is securely closed when not in use to maintain the IP66 water resistance rating.
- Emmagatzematge: Store the lantern in a cool, dry place away from direct sunlight and extreme temperatures. For long-term storage, it is recommended to charge the battery every three months to maintain battery health.
- Cura de la bateria: Avoid fully depleting the battery frequently. Recharge the lantern when the battery indicator shows low power.
Resolució de problemes
If you encounter issues with your Fenix CL28R, refer to the following common troubleshooting steps:
- La llanterna no s'encén:
- Ensure the battery is charged. Connect the lantern to a power source using the USB-C cable and check the charging indicator.
- Verify that the power button is being pressed and held for the correct duration (approx. 0.5 seconds).
- Light output is dim or flickering:
- The battery level might be low. Recharge the lantern.
- Ensure the brightness control knob is rotated to the desired level.
- Power bank function not working:
- Ensure the lantern has sufficient battery charge.
- Check the connection of the charging cable to both the lantern and the external device. Try a different cable if necessary.
- Alguns dispositius poden requerir protocols de càrrega específics; assegureu-vos de ser compatibles.
- Water ingress despite IP66 rating:
- Ensure all protective rubber flaps and covers are securely closed before exposure to water.
- The IP66 rating protects against strong jets of water and dust, but not prolonged submersion.
If problems persist, please refer to the warranty information or contact Fenix customer support.
Especificacions
The Fenix CL28R lantern is built with high-quality materials and designed for durability and performance.
| Característica | Especificació |
|---|---|
| Model | CL28R |
| Sortida màxima | 2000 lúmens |
| Distància màxima del feix | 58 metres |
| Temps d'execució màxim | 360 Hours (Low mode) |
| Bateria | Polímer de liti de 10,000 mAh integrat |
| Port de càrrega | USB tipus C |
| Ports de sortida | USB-A, USB-C (for power bank function) |
| Material | Aircraft Grade Aluminum |
| Dimensions (L x A x A) | 3.94" x 3.82" x 1.61" (100 x 97 x 41 mm) |
| Pes | 13.3 unces (376 grams) |
| Resistència a l'aigua | IP66 (Dustproof, protected against strong water jets) |
| Resistència a l'impacte | 1.5 metres |
| Característiques especials | Stepless Brightness Control, Stepless Color Temperature Adjustment, Magnetic Handle, Tripod Mountable |
Figure 9: Detailed technical parameters including output, runtime, distance, intensity, impact resistance, and IP rating for white and red light modes.
Figure 10: The Fenix CL28R is designed with a sturdy body capable of withstanding a 1.5-meter drop test on all 6 sides, ensuring ruggedness for challenging activities.
Figure 11: The Fenix CL28R boasts an IP66 rating, providing full protection against dust and foreign object intrusion, and ensuring no damage from heavy rain or splashing water.
Garantia i Suport
The Fenix CL28R comes with a limited warranty. For specific details regarding the warranty period and coverage, please refer to the warranty card included in your product packaging or visit the official Fenix weblloc.
For technical support, service, or inquiries, please contact Fenix customer service through their official channels. Keep your purchase receipt as proof of purchase for warranty claims.
Fenix Official Weblloc: www.fenixlight.com
