Introducció
The Quad Lock Suction Windshield/Dashboard Car Phone Holder (Model: QLM-CAR-5) provides a secure and convenient mounting solution for your smartphone in your vehicle. Designed for use with all Quad Lock Cases and Universal Adaptors, this mount features a super rigid body and an industrial-strength suction cup, allowing for reliable attachment to your car's windscreen or dashboard. Its adjustable gimbal head enables optimal viewing angles, and it supports both portrait and landscape phone orientations for easy navigation and access to your device.
Image: The Quad Lock Suction Windshield/Dashboard Car Phone Holder, showcasing its robust design and suction cup base.
Instruccions de configuració
- Trieu una ubicació de muntatge: Select a clean, flat, and smooth surface on your car's windscreen or dashboard. If mounting on the dashboard, use the included dash pad for optimal adhesion. Ensure the chosen location does not obstruct your view of the road or interfere with airbags.
- Netegeu la superfície: Thoroughly clean the chosen mounting surface with an alcohol wipe or a clean, damp cloth. Allow the surface to dry completely before proceeding.
- Col·loqueu la ventosa:
Image: The Quad Lock Suction Mount securely placed on a car dashboard.
Press the suction cup firmly against the cleaned surface. While pressing, push down the lever on the suction cup base to create a vacuum seal. Ensure the mount is securely attached and does not wobble.
- Ajusteu l'angle: Loosen the adjustment knob on the gimbal head. Position the mount to your desired viewing angle. Tighten the knob firmly to lock the angle in place.
Instruccions de funcionament
- Adjuntant el teu telèfon:
Image: A hand demonstrating the attachment of a phone with a Quad Lock case to the car mount.
Align your Quad Lock-compatible phone case or universal adaptor with the mounting head. Press down and twist your phone clockwise until you hear a click, indicating it is securely locked into place. The dual-stage locking mechanism ensures your device remains firmly attached.
- Desconnectar el telèfon: To remove your phone, press down on the blue lever (or similar release mechanism) on the mounting head and twist your phone counter-clockwise. Lift the phone away from the mount.
- Adjusting Phone Orientation: The mount allows for both portrait and landscape orientation. Simply twist your phone on the mount to switch between orientations as needed for navigation or media viewing.
Image: A smartphone mounted in portrait orientation on the Quad Lock holder, displaying a navigation map.
- Using with Optional Wireless Charging Head: If you have the optional Quad Lock Wireless Charging Head (not included), attach it to the mount according to its instructions. Ensure your phone case is compatible with wireless charging.
Image: The Quad Lock mount with a smartphone attached, showing a charging cable connected to the phone.
Manteniment
- Neteja: Regularly wipe down the mount and suction cup with a soft, damp cloth to remove dust and grime. For the suction cup, occasional cleaning with mild soap and water can help maintain its adhesive properties. Ensure all parts are dry before re-mounting.
- Suction Cup Rejuvenation: If the suction cup loses its grip over time, wash it with warm, soapy water and let it air dry. This can help restore its stickiness. Avoid touching the adhesive surface with your fingers.
- Emmagatzematge: When not in use for extended periods, detach the mount from the surface and store it in a cool, dry place away from direct sunlight.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| Mount does not stick to surface. | Surface is dirty, oily, or not smooth; suction cup is dirty or dry; lever not fully engaged. | Clean the surface and suction cup thoroughly. Ensure the surface is flat and smooth. Press the suction cup firmly and fully engage the lever. Try a different mounting location. |
| Phone wobbles on the mount. | Gimbal head adjustment knob is loose; phone not fully locked into place. | Tighten the adjustment knob firmly. Ensure your phone is twisted clockwise until it clicks securely into the dual-stage pany. |
| Difficulty attaching/detaching phone. | Incorrect alignment; release lever not pressed. | Ensure the phone case is correctly aligned with the mounting head. For detachment, firmly press the blue release lever before twisting counter-clockwise. |
| Mount falls off in extreme temperatures. | Temperature fluctuations can affect suction. | Re-attach the mount when the car interior temperature is stable. Consider using the dash pad for more permanent dashboard mounting in areas with significant temperature swings. |
Especificacions
- Número de model: QLM-CAR-5
- Dimensions del producte: 2.76 x 5.12 x 5.12 polzades
- Pes de l'article: 7.4 unces
- Tipus de muntatge: Suction Cup (Windshield/Dashboard)
- Compatibilitat: All Quad Lock Cases & Universal Adaptors
- Ajustabilitat: Adjustable gimbal head for optimal viewing angle; supports portrait and landscape orientation.
- Material: Super rigid body, industrial strength suction cup.
Garantia i Suport
For warranty information, product support, or to purchase additional accessories, please visit the official Quad Lock website or contact their customer service directly. Details can typically be found on the product packaging or the manufacturer's weblloc.
Note: This manual provides general instructions. Specific details may vary slightly based on product revisions. Always refer to the latest information provided by the manufacturer.
