1. Introducció
Thank you for choosing the ARG Arogya Leg & Thigh Massager. This device is designed to provide comprehensive massage therapy for your legs, thighs, calves, soles, and feet, incorporating air compression, heat, kneading, and shiatsu functions to promote relaxation and relieve discomfort. Please read this manual thoroughly before use to ensure safe and effective operation.
Image 1.1: The ARG Arogya Leg & Thigh Massager, showcasing el seu disseny ergonòmic.
2. Informació de seguretat
WARNING: Please read the entire user manual before operating this product.
- Always disconnect the massager from the power outlet immediately after use and before cleaning.
- No l'utilitzeu durant el bany o la dutxa.
- No col·loqueu ni guardeu el massatjador on pugui caure o ser arrossegat a la banyera o a la pica.
- No introduïu ni deixeu caure dins l'aigua o cap altre líquid.
- No utilitzeu mai agulles ni altres elements de fixació metàl·lics amb aquest aparell.
- És necessària una supervisió estreta quan aquest aparell és utilitzat per, sobre o a prop de nens, invàlids o persones amb discapacitat.
- Utilitzeu aquest aparell només per a l'ús previst tal com es descriu en aquest manual. No utilitzeu accessoris no recomanats pel fabricant.
- No feu servir mai aquest aparell si té un cable o un endoll danyats, si no funciona correctament, si s'ha caigut o s'ha fet malbé, o si ha caigut a l'aigua.
- Mantingueu el cable allunyat de superfícies escalfades.
- No utilitzar a l'aire lliure.
- No opereu on s'utilitzen productes en aerosol (esprai) o on s'administra oxigen.
- Per desconnectar, gireu tots els controls a la posició OFF i, a continuació, traieu el tap de la presa de corrent.
- Aquest aparell està dissenyat només per a ús domèstic.
3. Components i característiques del producte
The ARG Arogya Leg & Thigh Massager is equipped with various components designed for a comprehensive massage experience.
Image 3.1: Key components including the handle for portability, the control panel for settings, the fabric cover for comfort, and the support stand for stability.
Imatge 3.2: posterior view of the massager, highlighting the power switch and electric cord connection point.
Disseny ajustable
Image 3.3: The massager features a multi-angle adjustable design, allowing it to adapt to various leg and thigh positions for optimal comfort and coverage.
4. Configuració i funcionament
Configuració
- Place the massager on a stable, flat surface.
- Ensure the power switch (located at the rear) is in the OFF position.
- Connect the electric cord to a suitable power outlet (DC 12V 2A).
- Adjust the massager to your desired angle using its multi-angle adjustable feature.
Funcionament
To use the massager, follow these steps:
Image 4.1: Proper posture for using the massager, ensuring legs and thighs are comfortably positioned.
- Posicionament: Place your legs and feet comfortably into the massager, ensuring the 28 airbags are aligned with your calves, thighs, and feet for optimal coverage.
- Encès: Enceneu el massatge amb l'interruptor d'alimentació.
- Tauler de control: Utilitzeu el tauler de control per seleccionar la configuració desitjada.
Image 4.2: The control panel allows for precise adjustment of massage settings.
Image 4.3: The Far Infra Red Heat function provides soothing warmth.
- Air Pressure Intensity: The massager offers 3 levels of air compression intensity using 28 airbags. Adjust to your comfort level.
- Modes de massatge: Choose between Kneading or Shiatsu massage modes.
- Kneading Massage: Helps relieve muscle knots and stiffness.
- Shiatsu Massage: Uses rhythmic, circular motions to target pressure points and improve overall muscle relaxation.
- Funció de calefacció: Activate the heat therapy function to help relieve pain, relax sore muscles, and reduce stiffness. Temperature settings are 45/55 degree Celsius (Low-High).
- Configuració de l'hora: The massager has an automatic shut-off feature after 20 minutes for safety and convenience.
Sit back and relax while the massager provides its therapeutic benefits.
5. Benefits of Use
Regular use of the ARG Arogya Leg & Thigh Massager can provide numerous health benefits:
Image 5.1: Visual representation of the key benefits provided by the massager.
- Relieves Muscle Tension and Pain: Effectively alleviates discomfort in legs, calves, and feet.
- Improves Blood Circulation: Enhances blood flow, which can help reduce swelling and fluid retention.
- Reduces Stiffness and Fatigue: The combination of heat, kneading, and shiatsu techniques targets muscle soreness.
- Afavoreix la relaxació: Provides a soothing, spa-like experience that helps relieve stress and promote overall well-being.
- Enhances Muscle Flexibility: Regular massage can contribute to improved muscle suppleness.
- Aids Post-Exercise Recovery: Helps ease pain and fatigue after physical activity.
- Millora la qualitat del son: Relaxation induced by massage can lead to better sleep.
6. Especificacions
Detailed technical specifications for the ARG Arogya Leg & Thigh Massager:
| Característica | Especificació |
|---|---|
| Marca | ARG Arogya |
| Número de model | AROGYA 360 |
| Entrada de potència | DC 12V 2A |
| Consum d'energia | 24W |
| Configuració de la temperatura | 45/55 degree Celsius (Low-High) |
| bosses d'aire | 28 Air Bags |
| Air Pressure Levels | 3 nivells |
| Tècniques de massatge | Kneading, Shiatsu, Air Compression, Roller Therapy |
| Foot Size Range | 26 cm - 36 cm |
| Calf Circumference Range | 42 cm - 55 cm |
| Thigh Circumference Range | 53 cm - 75.5 cm |
| Configuració de l'hora | 20 minutes auto shut-off |
| Dimensions del producte (LxWxH) | 45 x 40 x 40 cm |
| Pes de l'article | 20 kg |
| Material | Plastic + Rexine |
| País d'origen | Xina |
Image 6.1: A comparison chart illustrating features across different ARG Arogya leg massager models.
7. Manteniment
Proper maintenance ensures the longevity and optimal performance of your massager:
- Neteja: Always unplug the massager before cleaning. Wipe the exterior surfaces with a soft, damp cloth. Do not use abrasive cleaners, solvents, or harsh detergents.
- Emmagatzematge: Guardeu el massatjador en un lloc fresc i sec quan no l'utilitzeu. Eviteu la llum solar directa i les temperatures extremes.
- Cura del cordó: Do not wrap the power cord around the appliance. Avoid sharp bends or kinks in the cord.
- Inspecció periòdica: Periodically check the power cord and plug for any signs of damage. If any damage is found, discontinue use and contact customer support.
8. Solució De Problemes
If you encounter any issues with your massager, please refer to the following common troubleshooting tips:
| Problema | Causa possible | Solució |
|---|---|---|
| El massatjador no s'encén | Not plugged in; Power switch off; Power outlet issue | Ensure power cord is securely plugged in; Turn power switch ON; Test outlet with another device. |
| Air compression is weak | Low intensity setting; Airbags not properly aligned | Increase air intensity level on the control panel; Adjust positioning of legs to ensure proper airbag coverage. |
| La funció de calor no funciona | Heat function not activated; Overheating protection | Ensure heat button is pressed; Allow unit to cool down if it has been running for an extended period. |
| Sorolls inusuals durant el funcionament | Normal operation sounds; Internal component issue | Some operational sounds (e.g., air pump) are normal. If noise is excessive or unusual, discontinue use and contact support. |
Si el problema persisteix després d'intentar aquestes solucions, poseu-vos en contacte amb l'atenció al client.
9. Garantia i atenció al client
Informació de la garantia
The ARG Arogya Leg & Thigh Massager comes with a 1 Year Brand Warranty. Aquesta garantia cobreix:
- Defectes de fabricant
- Mechanical or electrical failure
- Danys accidentals
Exclusions de garantia:
- Physical damage / liquid spillage
- Rat bite damage
Terms and conditions are applicable all over India. Warranty terms may differ for commercial and personal use.
To claim warranty service, the customer will send the product to the company's service center. Both sides' courier charges will be paid by the company during the warranty period. After the warranty period, services will be offered on a chargeable basis, depending on the product.
Atenció al client
For any further assistance or queries, please feel free to reach us at:
- Correu electrònic: customersupport@arghealthcare.info
- Telèfon: +91 97185 60729
