EJEAS V7 Motorcycle Helmet Bluetooth Intercom User Manual

1. Introducció

Thank you for choosing the EJEAS V7 Motorcycle Helmet Bluetooth Intercom. This device is designed to provide clear and reliable wireless communication for motorcyclists, enhancing safety and convenience during rides. It features Bluetooth 5.1 technology, CVC noise reduction, and supports multi-rider intercom functionality. Please read this manual thoroughly before use to ensure proper installation and operation.

Figure 1: EJEAS V7 Intercom Unit

2. Producte acabatview i Característiques

The EJEAS V7 intercom offers a range of features for an improved riding experience:

• Bluetooth 5.1: For stable and fast wireless connections.
• 1200m Intercom Distance: Supports communication between two riders up to 1200 meters.
• Multi-Rider Support: Connects up to 7 devices, with 2 riders talking simultaneously.
• Reducció de soroll CVC: Automatically reduces ambient noise for clear audio.
• Connectivitat telefònica dual: Connect two mobile phones simultaneously.
• Auto-Answering: Automatically answers incoming calls after 5 seconds.
• Assistent de veu: Accedeix a l'assistent de veu del teu telèfon.
• Impermeable IP65: Designed for use in various outdoor weather conditions.
• Llarga vida útil de la bateria: 850mAh battery provides extended talk and music playback time.

Figure 2: EJEAS V7 Key Features Overview

2.1. Components del dispositiu

Figure 3: EJEAS V7 Button Layout and Functions

• Botó d'encesa (A): Power on/off, Intercom activation.
• Volume Up Button (B): Augmenta el volum.
• Phone Button (C): Answer/end calls, activate voice assistant.
• Volume Down Button (D): Disminuir el volum.
• Function Button (E): Music control, FM radio.
• Headphone/Charging Port: Type-C port for charging and connecting headphones.

3. Contingut del paquet

Verifiqueu que tots els elements siguin presents al vostre paquet:

• EJEAS V7 Intercom Unit
• Auriculars amb micròfon
• Cable de càrrega USB tipus C
• Helmet Mounting Clips (Adhesive and Clamp)
• Speaker Velcro Pads
• Manual d'usuari

Figure 4: EJEAS V7 Package Contents

4. Especificacions

Figure 5: EJEAS V7 Detailed Specifications

5. Instal·lació

5.1. Càrrega del dispositiu

Before first use, fully charge the EJEAS V7 intercom. Connect the provided USB Type-C cable to the charging port on the unit and a suitable USB power adapter (DC5V/1A recommended). The indicator light will show charging status and turn off when fully charged.

Figure 6: Type-C Charging Interface and Battery Life

5.2. Mounting the Intercom Unit

The EJEAS V7 can be mounted to your helmet using either the adhesive mount or the clamp mount. Choose the method most suitable for your helmet type.

1. Muntatge adhesiu: Clean the desired area on the side of your helmet. Peel off the protective film from the adhesive mount and firmly press it onto the helmet surface. Allow sufficient time for the adhesive to cure before attaching the intercom unit.
2. Clamp Muntatge: Afluixeu els cargols del clamp mount. Slide the clamp between the helmet shell and the inner padding. Tighten the screws to secure the clamp.
3. Slide the EJEAS V7 intercom unit onto the chosen mount until it clicks securely into place.

5.3. Headphone and Microphone Installation

Install the speakers and microphone inside your helmet for optimal audio quality and comfort.

1. Attach the speaker Velcro pads to the inside of your helmet, positioning them directly over your ears.
2. Secure the speakers to the Velcro pads. Ensure they are flat against the helmet lining and centered over your ears.
3. Route the microphone cable and position the microphone in front of your mouth, ensuring it is close enough for clear voice pickup but not obstructing your vision or comfort.
4. Connect the headphone/microphone cable to the Type-C port on the EJEAS V7 intercom unit.

Figure 7: Headphone Installation Steps

6. Funcionament

6.1. Encendre/apagar

• Encès: Long press the Power Button (A) for 3 seconds until the indicator light flashes.
• Apagar: Long press the Power Button (A) for 3 seconds until the indicator light turns off.

6.2. Emparellament amb el telèfon mòbil

1. Ensure the EJEAS V7 is powered off.
2. Press and hold the Phone Button (C) and Function Button (E) simultaneously for 5 seconds until the red and blue lights flash alternately, indicating pairing mode.
3. On your mobile phone, enable Bluetooth and search for "EJEAS V7".
4. Select "EJEAS V7" to connect. Once connected, the blue light will flash slowly.

6.3. Intercom Pairing (Multi-Rider)

The EJEAS V7 supports pairing with up to 7 devices, allowing 2 riders to talk simultaneously. The host unit can switch between the other 6 sub-devices.

1. Ensure both intercom units are powered on.
2. On the first unit (Host), press and hold the Power Button (A) for 5 seconds until the red and blue lights flash alternately.
3. On the second unit (Client), press and hold the Power Button (A) for 5 seconds until the red and blue lights flash alternately.
4. Once both units are in pairing mode, short press the Power Button (A) on either unit. The units will automatically search and connect. A successful connection is indicated by a slow blue light flash on both units.
5. Repeat the process for additional units, pairing each new unit with the Host unit.

Figure 8: 1200m Intercom Range

6.4. Reproducció de música

• After pairing with your phone, open your music player.
• Short press the Function Button (E) to play/pause music.
• Short press Volume Up (B) for next track, Volume Down (D) for previous track.

6.5. Gestió de trucades

• Respon a la trucada: Short press the Phone Button (C) when an incoming call rings.
• Resposta automàtica: The device will automatically answer calls after 5 seconds if enabled.
• Finalitzar la trucada: Short press the Phone Button (C) during a call.
• Rebutja la trucada: Long press the Phone Button (C) for 2 seconds when an incoming call rings.

6.6. Assistent de veu

• Long press the Phone Button (C) for 2 seconds to activate your phone's voice assistant (e.g., Siri, Google Assistant).

6.7. EUC Handle Pairing and Control (Optional)

The EJEAS V7 can be paired with an optional EJEAS EUC handle for convenient control without removing your hands from the handlebars.

1. Clear EUC Pairing: On the EUC handle, long press the FM key and Volume - key simultaneously to clear previous pairings.
2. Enter V7 Pairing Mode: Power on the V7 unit. Press and hold the Phone Button (C) and Function Button (E) for 5 seconds until the red and blue lights flash alternately.
3. Pair EUC: On the EUC handle, press any key to enter pairing mode.
4. Once paired, the blue light on the EUC will blink slowly, indicating a successful connection.

Figure 9: EJEAS V7 with Optional EUC Handle Control

7. Manteniment

• Clean the device regularly with a soft, dry cloth. Do not use harsh chemicals or abrasive cleaners.
• Ensure the Type-C port cover is securely closed when not charging to maintain its IP65 waterproof rating.
• Guardeu el dispositiu en un lloc fresc i sec quan no l'utilitzeu.
• Eviteu exposar el dispositiu a temperatures extremes o a la llum solar directa durant períodes prolongats.

8. Solució De Problemes

9. Garantia i Suport

For warranty information, technical support, or further assistance, please refer to the official EJEAS weblloc web o contacteu directament amb el servei d'atenció al client. Conserveu el rebut de compra com a comprovant de compra per a reclamacions de garantia.

You can visit the EJEAS store for more products and support: EJEAS Store
