Luceco Solar Powered LED Outdoor Floodlight User Manual

1. Introducció

Thank you for choosing the Luceco Solar Powered LED Outdoor Floodlight. This product is designed to provide efficient and reliable outdoor lighting with integrated motion sensing capabilities, utilizing solar energy for cost-effective and environmentally friendly operation. This manual provides essential information for the safe installation, operation, and maintenance of your floodlight.

Figure 1: Luceco Solar Powered LED Outdoor Floodlight (Model LEXSF15B40-01)

2. Informació de seguretat

Llegiu atentament totes les instruccions de seguretat abans de la instal·lació i l'ús. Si no seguiu aquestes instruccions, podeu patir descàrregues elèctriques, incendis o lesions greus.

• Ensure the product is installed in a location where it will receive adequate sunlight for optimal charging.
• Do not attempt to disassemble or modify the product. There are no user-serviceable parts inside.
• Keep the solar panel and light unit clean to ensure efficient operation.
• This product is rated IP65 for weather resistance, meaning it is protected against dust ingress and low-pressure water jets from any direction. However, proper installation is crucial to prevent water accumulation or ingress, especially around cable connections.
• Avoid looking directly into the LED light source when illuminated, as it may cause eye strain.
• Dispose of the product and its battery responsibly at the end of its life cycle, following local regulations.

Figure 2: Durable and Weatherproof Design (Rated IP65)

3. Producte acabatview

The Luceco Solar Floodlight combines an efficient LED light source with a high-performance solar panel and a sensitive PIR motion sensor. Key features include:

• 11W Solar-Powered LED: High-efficiency LED chips output 1500 lumens of 4000K neutral white light.
• PIR Photocell Motion Sensor: Detects movement up to 10 meters with a 120° detection angle.
• Dos modes de funcionament: Full brightness then dims, or full brightness then turns off after 20 seconds of no motion. Sensors can be disabled for continual light.
• Panell solar desmuntable: Comes with a 5-meter extension cable, allowing flexible placement for optimal solar charging.
• Construcció duradora: Polycarbonate body with IP65 weatherproof rating for year-round outdoor use.

Figure 3: 4000K Neutral White Light Output

4. Configuració i instal·lació

The floodlight is designed for effortless installation with no wiring required.

4.1. Triar una ubicació

• Select a location for the floodlight that provides the desired illumination coverage for your garden, porch, or driveway.
• For the solar panel, choose a spot that receives direct sunlight for 8-10 hours daily, especially during peak daylight hours. The 5-meter extension cable allows flexibility in positioning the solar panel away from the light unit if needed.

4.2. Muntatge de la unitat

1. Using the included fixings, screw the detachable bracket securely to your chosen wall or surface. The bracket offers both wall and table mount options.
2. Attach the floodlight unit to the mounted bracket. Ensure it is firmly secured.
3. Connect the solar panel cable to the floodlight unit. Ensure the connection is tight and secure to maintain the IP65 rating.
4. Adjust the angle of both the solar panel and the light unit to optimize solar exposure and direct light where needed.

Figure 4: Effortless Installation Example

Figure 5: Detachable Solar Panel with Extension Cable

5. Instruccions de funcionament

The floodlight operates automatically based on light levels and motion detection.

5.1. Càrrec inicial

Before first use, allow the solar panel to charge the internal Li-ion 3.7V (4000mAh) battery for 8-10 hours in direct sunlight. The light will not operate during daylight hours.

5.2. Motion Sensor Modes

The PIR photocell motion sensor offers two primary operating modes, which can be selected via controls on the unit:

• Mode 1 (Full Brightness then Dims): When motion is detected, the light illuminates at full brightness (1500lm). After 20 seconds of no motion, it will dim to a lower brightness level to conserve power while still providing ambient light.
• Mode 2 (Full Brightness then Off): When motion is detected, the light illuminates at full brightness (1500lm). After 20 seconds of no motion, it will turn off completely.
• Continual Light Mode: Both the PIR and photocell sensors can be disabled to allow the light to operate continually at a set brightness level during darkness, until the battery depletes or daylight returns.

The motion sensor has a detection range of up to 10 meters and a 120° angle. Ensure the sensor is not obstructed for optimal performance.

Figure 6: Integrated PIR Motion Sensor

6. Manteniment

Regular maintenance will ensure the longevity and optimal performance of your floodlight.

• Neteja: Periodically wipe the solar panel and the light's surface with a soft, damp drap per eliminar la pols, la brutícia i les restes. Un panell solar net garanteix la màxima eficiència de càrrega.
• Inspecció: Regularly check the mounting screws and connections to ensure they remain secure. Verify that the cable connection between the solar panel and the light unit is tight and free from damage to maintain its weather resistance.
• Obstruccions: Ensure no new obstructions (e.g., growing foliage) are blocking direct sunlight to the solar panel or interfering with the motion sensor's field of view.

7. Solució De Problemes

If you experience issues with your Luceco Solar Floodlight, refer to the following common problems and solutions:

8. Especificacions

Figura 7: Dimensions del producte

9. Garantia i Suport

For warranty information or technical support, please refer to the product packaging or contact Luceco UK Ltd directly. Keep your purchase receipt as proof of purchase.

For further assistance, you may visit the official Luceco weblloc o poseu-vos en contacte amb el seu departament d'atenció al client.
