ChunHee Wireless Caregiver Pager System User Manual

1. Introducció

The ChunHee Wireless Caregiver Pager System is designed to provide a reliable and easy-to-use communication solution for caregivers and individuals requiring assistance. This system allows a person to alert their caregiver with a simple press of a button, ensuring timely support without the need for shouting or constant supervision. It is ideal for home use, assisting the elderly, patients, or individuals with limited mobility.

The system facilitates communication between a caregiver and an individual needing assistance.

2. Contingut del paquet

Verifiqueu que tots els elements siguin presents al vostre paquet:

• 1 x Portable Vibration Receiver
• 2 x Call Buttons (Transmitters)
• Manual d'usuari (aquest document)

3. Característiques del producte

• Funcionament sense fil: Enables communication over a distance, providing freedom for both caregiver and patient.
• Interval estès: Operates up to 800 feet (243 meters) in open areas, allowing for use across different rooms or floors.
• Volum ajustable: Features 5 volume levels (25dB-110dB) to suit various environments and user hearing needs.
• Múltiples modes d'alerta: Receiver offers vibration and audible alerts with 5 selectable melodies.
• Transmissor impermeable IP55: Call buttons are resistant to water splashes, making them suitable for use in bathrooms or near food.
• Portable Receiver: Can be carried in a pocket, clipped to a belt, or placed on a table.
• Fàcil d'utilitzar: Simple one-button press for assistance.

The system offers an 800ft range and 5 adjustable volume levels for versatile use.

The call button is IP55 waterproof, suitable for various environments, and product dimensions are provided.

4. Instruccions de configuració

4.1. Instal·lació de la bateria

The system includes one receiver and two call buttons (transmitters). Both units require battery installation before first use.

• Receptor: Open the back cover of the receiver. Insert 3 AAA alkaline batteries (not included) according to the polarity markings. Close the back cover securely.
• Call Buttons (Transmitters): Each call button comes with a pre-installed CR2032 button cell battery. If replacement is needed, carefully open the back cover using a small screwdriver, replace the battery, and ensure the cover is sealed properly to maintain water resistance.

4.2. Pairing Transmitters with Receiver

Follow these steps to pair your call buttons with the receiver. This process allows the receiver to recognize signals from specific call buttons.

This image illustrates the four steps for pairing the call buttons with the receiver unit.

1. Step 1: Turn on the receiver. Push down the back cover to open it. Ensure batteries are correctly installed.
2. Step 2: Enter pairing mode. Press and hold the set/volume button on the receiver until it makes a "di-di" sound and the receiver indicator flashes.
3. Step 3: Activate call button. Press the call button quickly. The receiver will make a "di-di" sound and its indicator will flash, confirming successful pairing.
4. Step 4: Confirm pairing. Press the call button again to confirm that the receiver sounds. If it does, pairing is complete for that button. Repeat for additional call buttons.

Nota: Each call button can be paired to multiple receivers, and each receiver can be paired with multiple call buttons. This allows for flexible system expansion.

5. Instruccions de funcionament

5.1. Using the Call Button

To request assistance, simply press the large SOS button on the call transmitter. The button is designed for easy activation by individuals of all ages and abilities.

The receiver can be easily carried, and the call button worn as a pendant for accessibility.

5.2. Recepció d'alertes

When a call button is pressed, the paired receiver will activate its alert. The receiver can be set to:

• Alerta audible: Play one of 5 selectable melodies at your chosen volume level.
• Alerta de vibració: Provide a silent vibration, useful for discreet notifications or for caregivers with hearing impairments.
• Combined Alert: Use both audible and vibration alerts simultaneously.

The indicator light on the receiver will also flash to provide a visual alert.

5.3. Adjusting Volume and Melody

Use the 'Set/Volume' button on the receiver to cycle through volume levels and melodies. Press briefly to change volume, press and hold to change melody.

5.4. Intended Users and Placement

The system is suitable for various individuals and can be placed strategically:

• Botó de trucada: Can be worn as a pendant around the neck, placed on a bedside table, or mounted on a wall in areas like the bathroom.
• Receptor: Can be carried in a pocket, clipped to a belt, or placed on a table in the caregiver's vicinity.

The system is designed for use by patients, pregnant women, children, the elderly, and disabled individuals.

Caregivers can use the system to provide assistance to individuals in various situations.

6. Manteniment

6.1. Neteja

Wipe the units with a soft, dry cloth. Do not use abrasive cleaners or solvents. For the call button, ensure the waterproof seal is intact after cleaning.

6.2. Substitució de la bateria

Replace batteries when the alert signal becomes weak or inconsistent. Refer to Section 4.1 for battery installation instructions.

• Receptor: Requires 3 AAA alkaline batteries.
• Botons de trucada: Each requires 1 CR2032 button cell battery.

7. Solució De Problemes

If you encounter issues with your ChunHee Wireless Caregiver Pager System, refer to the following common solutions:

8. Especificacions

9. Garantia i Suport

For any questions, technical assistance, or support regarding your ChunHee Wireless Caregiver Pager System, please refer to the retailer's return and support policies. Keep your purchase receipt for warranty claims, if applicable.
