Kratos 69K-916 Ice Bin User Manual

1. Introducció

This manual provides essential instructions for the safe and efficient installation, operation, and maintenance of your Kratos 69K-916 Ice Bin. This commercial ice storage solution is designed for foodservice environments, offering a 310 lb. storage capacity within a 22-inch wide unit. It features a sleek stainless steel body with black trim, 6-inch adjustable legs, and a polyethylene storage bin liner for enhanced sanitation. The unit is NSF and UL certified, ensuring compliance with health and safety standards.

The Kratos 69K-916 Ice Bin is compatible with Kratos 69K-914, 69K-915, and other branded 22-inch wide modular ice machines. An ice scoop and holder are included for convenient access.

Figure 1: Kratos 69K-916 Ice Bin. This image illustrates the key features of the Kratos 69K-916 Ice Bin, including the sleek stainless steel body, adjustable legs, and the integrated ice scoop and holder. The polyethylene storage bin liner, designed for improved sanitation, is also a core component.

2. Instruccions de configuració

2.1 Desembalatge

• Carefully remove the ice bin from its packaging.
• Inspect the unit for any shipping damage. Report any damage to your supplier immediately.
• Remove all packing materials, tape, and protective films from the unit.

2.2 Col·locació

• Place the ice bin on a level, stable surface capable of supporting its weight when full of ice.
• Assegureu-vos que hi hagi prou espai lliure al voltant de la unitat per a la ventilació i el manteniment.
• The total dimensions of the unit are approximately 22"W x 34"D x 41-2/5"H. Consider these dimensions when selecting a location.

2.3 Leg Installation and Adjustment

• Attach the four 6-inch adjustable legs to the bottom of the ice bin.
• Adjust the leg height to ensure the unit is level. Use a spirit level for accuracy.
• Proper leveling is crucial for efficient drainage.

2.4 Connexió de desguàs

• Connect the 3/4" drain hookup to an appropriate floor drain or waste receptacle.
• Ensure the drain line has a continuous downward slope to prevent water accumulation.
• Verify all connections are secure to prevent leaks.

2.5 Neteja inicial

• Before first use, thoroughly clean the interior of the polyethylene storage bin liner with a mild, food-safe detergent and warm water.
• Esbandiu bé amb aigua neta i deixeu-ho assecar completament a l'aire.
• Clean the included ice scoop and holder in the same manner.

3. Instruccions de funcionament

3.1 Ice Machine Compatibility

This ice bin is designed to work with Kratos 69K-914, 69K-915, and other branded 22-inch wide modular ice machines. Ensure proper alignment and sealing between the ice machine and the bin to prevent ice melt and maintain sanitation.

3.2 Emmagatzematge de gel

• Once the ice machine is producing ice, it will automatically drop into the bin.
• The bin has a maximum storage capacity of 310 lbs. Do not overfill the bin, as this can impede ice machine operation and damage the bin.

3.3 Ice Dispensing

• Use the provided ice scoop for dispensing ice.
• Always store the ice scoop in its designated holder above the ice line to maintain hygiene and prevent contamination.
• Do not use hands or other non-sanitized utensils to retrieve ice.

4. Manteniment

4.1 Neteja diària

• Wipe down the exterior stainless steel surfaces with a clean, damp cloth. For stubborn spots, use a mild stainless steel cleaner.
• Ensure the ice scoop and its holder are cleaned daily with a food-safe sanitizer.

4.2 Weekly Cleaning (or as needed)

• Empty the ice bin completely.
• Clean the interior polyethylene liner with a food-safe detergent and warm water. Pay attention to corners and crevices.
• Esbandiu bé per eliminar tots els residus de detergent.
• Sanitize the interior with a food-safe sanitizer solution according to manufacturer instructions.
• Allow the bin to air dry completely before refilling with ice.
• Check the drain line for any obstructions and ensure it is flowing freely.

4.3 Atenció general

• Avoid using abrasive cleaners or scouring pads on any surface, especially the stainless steel, as this can scratch and damage the finish.
• Do not store anything other than ice in the bin.
• Regularly check the adjustable legs to ensure the unit remains level.

5. Solució De Problemes

This section addresses common issues you might encounter with your Kratos 69K-916 Ice Bin. For problems related to the ice machine itself, refer to the ice machine's specific manual.

5.1 Water Accumulation in Bin

• Check Drain Line: Ensure the 3/4" drain line is not kinked, clogged, or obstructed. Verify it has a continuous downward slope to the floor drain.
• Comprovació de l'anivellament: Confirm the ice bin is level using a spirit level. Uneven positioning can hinder proper drainage.
• Ice Machine Seal: If connected to an ice machine, ensure the seal between the ice machine and the bin is intact and properly seated to prevent excessive meltwater from entering the bin or leaking.

5.2 Unpleasant Odor in Bin

• Neteja a fons: Perform a complete cleaning and sanitization of the bin interior as described in the Maintenance section (Section 4.2).
• Ventilació: Ensure the area around the bin is well-ventilated.
• Ice Source: If the odor persists, check the ice machine itself, as the odor might be originating from the ice production.

5.3 Ice Melting Too Quickly

• Temperatura ambient: Ensure the ice bin is not located in an excessively warm environment or near heat-generating equipment.
• Lid/Door Seal: Verify that the bin's lid or access door closes securely and that its gasket (if present) is intact to maintain insulation.
• Ice Machine Connection: If connected to an ice machine, ensure the connection is sealed to prevent warm air ingress.

6. Especificacions del producte

Nota: Les especificacions estan subjectes a canvis sense previ avís per tal de millorar el producte.

7. Informació de la garantia

The Kratos 69K-916 Ice Bin comes with the following warranty:

• One-year limited warranty: This warranty applies to units used in commercial settings.
• Warranty Void in Residential Settings: The warranty is void if the product is used in a residential environment.
• 90-day limited warranty: This applies to units used in food trucks or mobile applications.

Please retain your proof of purchase for warranty claims. For detailed terms and conditions, please contact Kratos customer support.

8. Atenció al client

For technical assistance, parts, or warranty inquiries regarding your Kratos 69K-916 Ice Bin, please contact Kratos customer support.

• Weblloc: Visit the official Kratos weblloc web per a recursos de suport i informació de contacte.
• Telèfon: Refer to your purchase documentation or the Kratos weblloc web per obtenir el número de telèfon d'atenció al client més actualitzat.
• Correu electrònic: General inquiries can often be sent via email, details available on the Kratos weblloc.

When contacting support, please have your model number (69K-916) and purchase date available.
