Superlux HD 660PRO Studio Recording Headphones User Manual

1. Producte acabatview

The Superlux HD 660PRO are professional closed-back studio recording headphones designed for superior audio monitoring. Equipped with precision-tuned 40mm Neodymium drivers, they deliver deep, punchy bass, clear highs, and well-defined vocals, ensuring a natural and well-balanced sound with minimal distortion.

Figure 1.1: Superlux HD 660PRO headphones with included 3.5mm to 6.3mm adapter.

Característiques principals:

• Qualitat de so superior: Precision-tuned 40mm Neodymium drivers for deep bass, clear highs, and well-defined vocals with minimal distortion.
• Everyday Versatility: 32Ω impedance suitable for smartphones, laptops, tablets, and professional audio equipment.
• Extended Wearing Comfort: Upgraded leather headband and ultra-soft velvet ear pads ensure minimal fatigue during long sessions.
• Durable and Flexible Design: Adjustable headband and swivel ear cups crafted from rugged materials for professional and casual settings.
• Connectivitat perfecta: Includes a 3.5mm plug and a 6.3mm adapter for wide compatibility with various audio devices.

Figure 1.2: Illustration of the headphones' ultra-wide frequency response and powerful 40mm neodymium drivers.

Figure 1.3: The upgraded leather cushion headband and ultra-soft velvet earpads provide extended wearing comfort.

2. Configuració i connexions

2.1 Què hi ha a la caixa

Upon opening your Superlux HD 660PRO package, you will find the following items:

• Superlux HD 660PRO Headphones
• 3.5mm to 6.3mm (1/4 inch) Conversion Plug
• Bossa d'emmagatzematge

Figure 2.1: The complete contents of the Superlux HD 660PRO package.

2.2 Connexió dels auriculars

The HD 660PRO headphones are designed for seamless connectivity across a wide range of audio devices. The durable 8.2 ft straight cable terminates in a standard 3.5mm jack, and a 6.3mm adapter is included for broader compatibility.

1. For Devices with 3.5mm Jack: Directly plug the 3.5mm connector of the headphone cable into the audio output port of your smartphone, laptop, tablet, or computer.
2. For Devices with 6.3mm Jack: Screw the included 6.3mm adapter onto the 3.5mm connector. Then, plug the assembled connector into the 6.3mm audio output port of your mixer, audio interface, guitar amplifier, or other professional audio equipment.

Figure 2.2: The 3.5mm plug and 6.3mm adapter allow connection to various devices.

Ensure the connection is secure to prevent audio interruptions or poor sound quality.

3. Ús dels auriculars

The Superlux HD 660PRO headphones are designed for a variety of listening environments, from casual music enjoyment to professional studio work.

3.1 Com posar-se els auriculars

• Gently extend the headband and place the earcups over your ears.
• Adjust the headband length on both sides until the earcups sit comfortably and securely, fully enclosing your ears. The over-ear, closed-back design provides excellent sound isolation.
• The swivel ear cups allow for a customizable fit and can be adjusted for single-ear monitoring if needed.

Figure 3.1: The closed-back circumaural design provides natural and well-balanced sound with low distortion, ideal for podcasting and studio work.

3.2 Optimal Usage Environments

The HD 660PRO headphones come in two impedance variants: 32Ω and 150Ω. The 32Ω model (this product) is highly versatile, while the 150Ω model is typically preferred for more demanding professional setups.

Figure 3.2: The 32Ω model is ideal for everyday use, while the 150Ω model is suited for professional audio environments.

Figure 3.3: The HD 660PRO headphones are versatile for recording, audio mixing, podcasting, and gaming.

4. Cura i Manteniment

Proper care and maintenance will extend the lifespan and preserve the performance of your Superlux HD 660PRO headphones.

• Neteja de les coixinetes de les orelles: The velvet ear pads can accumulate dust and oils. Gently wipe them with a soft, dry, lint-free cloth. For deeper cleaning, lightly dampen the cloth with a small amount of mild soap and water, then wipe and allow to air dry completely before use. Avoid excessive moisture.
• Neteja de la diadema: The leather headband can be wiped with a soft, slightly damp tela. No utilitzeu productes químics aggressivs ni netejadors abrasius.
• Cura del cable: Avoid sharp bends, kinks, or excessive pulling on the cable. Store the cable neatly to prevent tangling. The cable is durable but not designed to be detachable from the headphones themselves.
• Emmagatzematge: When not in use, store your headphones in the included storage pouch to protect them from dust and scratches. Avoid storing them in extreme temperatures or high humidity.
• Eviteu les gotes: While built from rugged materials, dropping the headphones can damage internal components or the housing. Handle with care.

5. Solució De Problemes

If you encounter any issues with your Superlux HD 660PRO headphones, refer to the following common troubleshooting steps:

If the problem persists after trying these steps, please refer to the "Warranty and Support" section for further assistance.

6. Especificacions

Detailed technical specifications for the Superlux HD 660PRO (32 Ohm model):

7. Garantia i Suport

Superlux is committed to providing high-quality products and excellent customer service. While specific warranty details may vary by region and retailer, Superlux stands behind its products.

7.1 Informació de la garantia

Please refer to the warranty card included with your product packaging for specific terms and conditions, including the warranty period and coverage details. Retain your proof of purchase for any warranty claims.

7.2 Atenció al client

For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Superlux customer support. You can typically find contact information on the official Superlux weblloc web o a través del vostre punt de compra.

Superlux is dedicated to "Creating the Value of Sound" and ensuring customer satisfaction worldwide.
