Gazzyt S-24

Manual d'instruccions de la cabina del simulador de curses Gazzyt S-24

Brand: Gazzyt | Model: S-24

1. Introducció

This manual provides detailed instructions for the assembly, operation, and maintenance of your Gazzyt Racing Simulator Cockpit S-24. Please read this manual thoroughly before assembly and use to ensure proper setup and safe operation. The Gazzyt Racing Simulator Cockpit S-24 is designed to provide a stable and adjustable platform for various racing simulation peripherals, enhancing your gaming experience.

Gazzyt Racing Simulator Cockpit S-24 assembled with steering wheel, pedals, and shifter.

Figure 1: Gazzyt Racing Simulator Cockpit S-24 assembled with steering wheel, pedals, and shifter. Note: Steering wheel, pedals, and shifter are not included.

2. Informació de seguretat

3. Contingut del paquet

Si us plau, verifiqueu que tots els components siguin presents abans de començar el muntatge. Si falta alguna peça o hi ha alguna peça danyada, poseu-vos en contacte amb el servei d'atenció al client.

Assembly video preview showing various parts of the Gazzyt Racing Simulator Cockpit S-24.

Figura 2: Un excésview of the components included with the Gazzyt Racing Simulator Cockpit S-24.

4. Instruccions de muntatge

Follow these steps carefully to assemble your racing simulator cockpit. An assembly video is provided for visual guidance.

Video 1: This video provides a step-by-step guide for assembling the Gazzyt Racing Simulator Cockpit S-24, demonstrating how to connect the main frame components.

  1. Pas 1: Muntar el marc base. Connect the main base sections using the provided bolts and tools. Ensure all connections are firm.
  2. Step 2: Attach the Pedal Platform. Secure the pedal platform to the front section of the base frame. The platform is designed to accommodate various pedal sets.
  3. Step 3: Install the Steering Wheel Support. Mount the steering wheel support column to the main frame. This column is height-adjustable.
  4. Step 4: Mount the Shifter Platform. Attach the shifter platform to either the left or right side of the cockpit, according to your preference. This platform is also height-adjustable.
  5. Step 5: Secure the Seat Brackets. Install the seat mounting brackets onto the rear section of the base frame. These brackets are adjustable to fit various racing seats.
Gazzyt Racing Simulator Cockpit S-24 frame.

Figure 3: The bare frame of the Gazzyt Racing Simulator Cockpit S-24, showcasing its robust carbon steel construction.

5. Adjustments and Compatibility

The Gazzyt Racing Simulator Cockpit S-24 offers extensive adjustability to suit different user heights and preferences, as well as broad compatibility with popular racing peripherals.

5.1. Adjusting the Cockpit

Video 2: This video illustrates the rotation and adjustment mechanisms for the various brackets on the Gazzyt Racing Simulator Cockpit S-24, including the steering wheel and shifter mounts.

Flexible adjustment points on the Gazzyt Racing Simulator Cockpit S-24.

Figure 4: Flexible adjustment points on the Gazzyt Racing Simulator Cockpit S-24, including height-adjustable bracket, movable shifter mount, and adaptable pedal platform.

Multi-way adjustment features of the Gazzyt Racing Simulator Cockpit S-24.

Figure 5: Multi-way adjustment features detailing the adjustable steering wheel platform, height-adjustable shift lever platform, and height-adjustable seat bracket.

5.2. Compatibilitat

The cockpit is designed for wide compatibility with various racing peripherals:

Video 3: This video demonstrates the installation and adjustment of a steering wheel onto the Gazzyt Racing Simulator Cockpit S-24, showcasing the secure mounting and positioning options.

Compatibility of Gazzyt Racing Simulator Cockpit S-24 with various steering wheels.

Figure 6: The cockpit is compatible with major brands such as Logitech G29/G920/G923, Thrustmaster T128 T248PS T248XBox T300 T300RS GT, Moza R5 R9 R12, and Fanatec.

6. Manteniment

7. Solució De Problemes

8. Especificacions

CaracterísticaDetall
MarcaGazzyt
Número de modelS-24
MaterialAcer al carboni
Dimensions del producte23.6 x 20 x 6.7 inches (approximate, adjustable)
Pes de l'article33 lliures
Capacitat de càrregaFins a 400 lliures
CompatibilitatLogitech, Thrustmaster, Moza, Fanatec, and other major steering wheel brands
Dimensions of the Gazzyt Racing Simulator Cockpit S-24.

Figure 7: This image illustrates the overall dimensions of the cockpit frame, highlighting its adjustable length from 46.4 to 53.5 inches and height of 34.5 inches. It is designed to support up to 400 lbs.

9. Garantia i Suport

For warranty information or technical support, please refer to the contact details provided with your purchase or visit the official Gazzyt weblloc web. Conserveu el comprovant de compra per a reclamacions de garantia.
