Manual d'usuari de la càmera de seguretat mòbil Ebitcam RBX-S60 4G LTE

1. Introducció i finalview

This manual provides detailed instructions for the installation, operation, and maintenance of your Ebitcam RBX-S60 4G LTE Cellular Security Camera. This camera is designed for locations without traditional WiFi or electrical power, utilizing 4G LTE cellular networks and solar power for continuous operation.

Les característiques clau inclouen:

• Enregistrament continu 24/7: Powered by a 20W solar panel and a 15000mAh battery.
• Connectivitat 4G LTE: Operates in areas with cellular signal, supporting AT&T, T-Mobile, and Verizon networks via an included ELOTCLUB SIM card.
• 2K High-Definition Video: Captures clear footage with 2K resolution.
• 360° View: Offers 355° horizontal pan and 100° vertical tilt for comprehensive coverage.
• Visió nocturna en color: Provides accurate color representation in low-light conditions when the spotlight is activated via the app.
• Sensor de moviment PIR: Detects motion based on heat signatures, reducing false alarms and sending instant alerts to your phone.
• Xerrada bidireccional: Permet la comunicació en temps real a través de la càmera.

Image 1.1: The Ebitcam RBX-S60 cellular security camera with its integrated solar panel and SIM card slot.

2. Contingut del paquet

Si us plau, verifiqueu que tots els elements siguin presents al vostre paquet:

• Ebitcam RBX-S60 Cellular Security Camera
• 20W Solar Panel (pre-attached or separate)
• Suport de muntatge i cargols
• ELOTCLUB SIM Card (with 300MB data)
• SD Card (if included in your specific model variant)
• Manual d'usuari (aquest document)

3. Guia de configuració

3.1 Instal·lació de la targeta SIM i la targeta SD

1. Locate the SIM card slot on the camera body. This is typically protected by a rubber cover.
2. Obriu la coberta amb cura.
3. Insert the provided ELOTCLUB Nano SIM card into the SIM card slot with the gold contacts facing down and the notched corner aligned correctly. Ensure it clicks into place.
4. If using an SD card for local storage, insert it into the designated SD card slot.
5. Close the rubber cover firmly to ensure water resistance.

Imatge 3.1: Primer pla view of the SIM card being inserted into the camera's slot.

Image 3.2: Details of the included ELOTCLUB SIM card and its compatibility with major carriers.

3.2 Muntatge de la càmera i del panell solar

Trieu una ubicació que rebi ampllum solar directa per al panell solar i proporciona la càmera desitjada view. The camera is rated IP65 for outdoor use.

1. Attach the mounting bracket to the camera and solar panel assembly.
2. Mark the drilling points on the wall or mounting surface using the bracket as a template.
3. Perforeu forats pilot i inseriu ancoratges de paret si cal.
4. Fixeu el suport de muntatge a la superfície amb els cargols proporcionats.
5. Adjust the angle of the solar panel to maximize sun exposure.
6. Ajusteu l'angle de la càmera per obtenir una cobertura de vigilància òptima.

Image 3.3: The camera and solar panel mounted on a wall, illustrating its pan and tilt range.

3.3 Initial Power-Up and App Connection

1. Ensure the camera has sufficient charge from the solar panel or an initial USB charge if needed.
2. Descarrega't el UBox aplicació des de la botiga d'aplicacions del teu telèfon intel·ligent (disponible per a Android i iOS).
3. Open the UBox app and follow the on-screen instructions to create an account and add your camera. This typically involves scanning a QR code on the camera or manually entering its ID.
4. Un cop connectat, pots view live video, adjust settings, and receive alerts.

4. Instruccions de funcionament

4.1 Continuous Recording and Power Management

The Ebitcam RBX-S60 is designed for 24/7 continuous recording, powered by its 20W solar panel and 15000mAh battery. However, to conserve power, if the battery level drops below 30%, the camera will automatically switch from continuous recording to event-based recording (triggered by motion).

Image 4.1: The camera's 24/7 continuous recording capability.

Image 4.2: Comparison highlighting the 20W solar panel and 15000mAh battery for uninterrupted recording.

4.2 Control de panoràmica i inclinació

Utilize the UBox app to remotely control the camera's viewing angle. The camera supports 355° horizontal rotation (pan) and 100° vertical rotation (tilt), allowing you to monitor a wide area.

Image 4.3: Visual representation of the camera's 360-degree viewrang d'ing.

Visió nocturna en color 4.3

The camera provides 2K resolution color night vision. To enable color night vision, you must manually activate the spotlight feature within the UBox application. Without the spotlight, the camera will operate in standard infrared black and white night vision.

Imatge 4.4: Ex.ample of the camera's color night vision capability in low light.

4.4 PIR Motion Sensor and Alerts

The integrated Passive Infrared (PIR) motion sensor detects movement by sensing changes in heat signatures, minimizing false alerts from non-human objects. When motion is detected, the camera can:

• Send instant notifications to your smartphone via the UBox app.
• Activate a siren (if enabled).
• Turn on a spotlight (if enabled, for color night vision or deterrence).

Image 4.5: A squirrel triggering a PIR motion detection alert on a smartphone.

4.5 Conversa bidireccional

Use the two-way talk feature in the UBox app to communicate through the camera. This allows you to speak to visitors, delivery personnel, or deter unwanted individuals.

4.6 Escenaris d'ús

The camera's 4G LTE and solar power capabilities make it ideal for various locations without traditional infrastructure:

• Farms and Ranches
• Barns and Outbuildings
• Llocs de construcció
• Vacation Homes and RVs
• Magatzems
• Camping Sites

Imatge 4.6: Ex.amples of suitable environments for the 4G LTE cellular camera.

5. Manteniment

Regular maintenance ensures optimal performance and longevity of your Ebitcam RBX-S60 camera.

• Neteja de panells solars: Netegeu periòdicament la superfície del panell solar amb un drap suau iamp drap per eliminar la pols, la brutícia o les restes que puguin obstruir la llum solar i reduir l'eficiència de la càrrega.
• Neteja de la lent de la càmera: Netegeu suaument la lent de la càmera amb un drap de microfibra per garantir una qualitat d'imatge nítida. Eviteu materials abrasius.
• Monitorització de la bateria: Monitor the battery level via the UBox app. Ensure the solar panel receives adequate sunlight to keep the battery charged, especially for continuous recording.
• Actualitzacions de firmware: Check the UBox app regularly for any available firmware updates. Keeping the firmware updated can improve performance and add new features.
• Inspecció física: Periodically check the mounting hardware for tightness and inspect cables for any signs of wear or damage.

6. Solució De Problemes

If you encounter issues with your Ebitcam RBX-S60 camera, refer to the following common problems and solutions:

6.1 Camera Not Connecting to App / Offline

• Check 4G LTE Signal: Ensure the camera is in an area with sufficient 4G LTE cellular coverage. Signal strength can vary.
• Estat de la targeta SIM: Verify the ELOTCLUB SIM card is correctly inserted and has active data. Check data balance via the ELOTCLUB service if possible.
• Nivell de bateria: A low battery can affect connectivity. Ensure the solar panel is clean and receiving direct sunlight.
• Restart Camera: Power cycle the camera by turning it off and on, or by pressing the reset button if accessible.
• Problemes amb l'aplicació: Ensure your UBox app is updated to the latest version. Try restarting the app or your smartphone.

6.2 Recording Issues (No Recording or Event-Only Recording)

• Nivell de bateria: If the battery is below 30%, the camera automatically switches to event-based recording. Ensure adequate solar charging.
• Targeta SD: If using an SD card, ensure it is correctly inserted, not full, and not corrupted. Format the SD card via the app if necessary (this will erase all data).
• Emmagatzematge al núvol: If relying on cloud storage, verify your subscription status and internet connectivity.

6.3 False Motion Alerts or Missed Detections

• Sensibilitat PIR: Adjust the PIR motion sensor sensitivity settings within the UBox app. High sensitivity can lead to false alerts from environmental factors.
• Col·locació de la càmera: Ensure the camera is not pointed directly at moving foliage, reflective surfaces, or areas with frequent temperature changes that could trigger the PIR sensor.
• Obstruccions: Clear any physical obstructions in the camera's field of view.

6.4 Mala qualitat d'imatge

• Neteja la lent: Netegeu la lent de la càmera tal com es descriu a la secció Manteniment.
• Configuració de resolució: Ensure the video resolution is set to 2K in the UBox app.
• Visió nocturna: For color night vision, ensure the spotlight is activated in the app.

7. Especificacions

8. Garantia i Suport

For warranty information, technical support, or further assistance, please contact Ebitcam customer service. You can typically find contact details on the official Ebitcam website or through the UBox application.
