1. Configuració
1.1 Contingut del paquet
Ensure all components are present before assembly:
- PowerSmart 40V Cordless Pressure Washer Unit
- Bateria de 40 V, 4.0 Ah
- Carregador de bateria
- Spray Lance
- Multi-Spray Nozzle (5 pressure-adjust settings)
- Canó d'escuma
- Hose with Filter
- Quick Faucet Connect Adapter
1.2 Instal·lació i càrrega de la bateria
Insert the fully charged 40V battery into the designated slot on the pressure washer unit until it clicks securely into place. To charge the battery, connect the charger to a power outlet and then connect the battery to the charger. The indicator lights on the charger will show the charging status.
Image: The PowerSmart 40V battery system, showing the battery pack and various compatible tools.
1.3 Hose and Nozzle Connection
Attach the hose with the filter to the hose connector on the pressure washer unit. Ensure a tight connection to prevent leaks. Select the desired multi-spray nozzle or foam cannon and attach it to the spray lance. The nozzles are designed for quick connection.
Image: Diagram of the PowerSmart 40V Cordless Pressure Washer highlighting key components like the battery pack, on/off switch, multi-spray nozzle, spray lance, and hose connector.
1.4 Water Source Connection
The pressure washer can draw water from any fresh water source. For direct faucet connection, use the quick faucet connect adapter. For drawing water from a bucket or other container, ensure the hose with the filter is fully submerged in the water source.
Image: Illustrates various water supply methods, including drawing water from a river (bucket with filter) and a bucket, demonstrating the self-priming function.
2. Instruccions de funcionament
2.1 Encès i apagat
To power on the unit, press the ON/OFF switch located on the handle. The unit will begin to draw water and build pressure. To power off, release the trigger and press the ON/OFF switch again.
2.2 Adjusting Pressure and Spray Patterns
The multi-spray nozzle offers 5 adjustable settings: 0°, 15°, 25°, 45°, and Soap mode. Rotate the nozzle head to select the desired spray pattern. The 0° setting provides a concentrated stream for tough spots, while wider angles are suitable for general cleaning and rinsing.
Image: Demonstrates the four quick-connect nozzles (0°, 15°, 25°, 45°) and their respective spray patterns.
Image: Close-up of the multi-spray nozzle showing the icons for 0°, 15°, 25°, 45°, and Soap mode.
2.3 Ús del canó d'escuma
Fill the foam cannon with appropriate cleaning solution. Attach the foam cannon to the spray lance. Select the 'Soap mode' on the multi-spray nozzle (if applicable) or use the dedicated foam cannon attachment. Spray the desired surface, allowing the foam to penetrate dirt before rinsing.
Image: A person using the PowerSmart pressure washer with the foam cannon attachment to apply soap to a car.
2.4 General Cleaning Applications
The PowerSmart pressure washer is suitable for various cleaning tasks:
- Car Washing: Use the foam cannon for soap application and a wider spray angle (e.g., 25° or 45°) for rinsing.
- Deck and Patio Cleaning: Use a 25° or 45° spray angle to remove dirt and grime from wooden or concrete surfaces.
- Driveway Cleaning: For stubborn stains, start with a narrower angle (e.g., 15°) and adjust as needed.
- Neteja de finestres: Use a wide, gentle spray (e.g., 45°) to clean windows without damage.
- Garden Equipment: Effectively clean lawnmowers, tools, and other garden equipment.
Image: A person cleaning a wooden deck with the PowerSmart cordless pressure washer, demonstrating its effectiveness on outdoor surfaces.
Image: A person using the PowerSmart pressure washer to clean a window, illustrating its use for delicate surfaces with appropriate nozzle settings.
2.5 Vídeos oficials de productes
Vídeo: Un overview of the PowerSmart 40V Cordless Pressure Washer, demonstrating its features and portability.
Video: Demonstration of the 40V 1100 PSI Pressure Washer in action, showcasing its power and ease of use for various cleaning tasks.
Video: A detailed look at the 40V Cordless Pressure Washer, highlighting its design and functionality for efficient cleaning.
3. Manteniment
3.1 Neteja i emmagatzematge
After each use, disconnect the unit from the water source and remove the battery. Rinse the foam cannon and nozzles with clean water. Store the pressure washer in a dry, protected area, especially during cold weather to prevent freezing damage. Ensure all water is drained from the unit and hoses before storage.
3.2 Cura de la bateria
Always store the battery in a cool, dry place. Avoid fully discharging the battery for extended periods. Charge the battery regularly, even when not in use, to maintain its lifespan.
4. Solució De Problemes
- Sense pressió: Ensure the water source is connected and turned on, and the hose filter is not clogged. Check that the battery is fully charged and properly installed.
- La unitat no s'encén: Verify the battery is charged and correctly inserted. Check the ON/OFF switch for proper engagement.
- Fuites d'aigua: Ensure all hose and nozzle connections are tight. Check O-rings for damage and replace if necessary.
5. Especificacions
| Característica | Detall |
|---|---|
| Marca | PowerSmart |
| Número de model | DB2701 |
| Font d'alimentació | Alimentat per bateria (ió de liti de 40 V) |
| Pressió màxima | 1100 PSI |
| Caudal màxim | 1 Gallon Per Minute (GPM) |
| Capacitat de la bateria | 4.0 Ah |
| Pes de l'article | 15 lliures |
| Dimensions del producte | 16 cm de llargada x 9.4 cm d'amplada x 9.6 cm d'alçada |
| Longitud de la mànega | 16 polzades |
| Certificació | CE |
6. Garantia i assistència
For warranty information, product support, or to purchase replacement parts, please refer to the contact details provided in your product packaging or visit the official PowerSmart website. Keep your purchase receipt as proof of ownership for warranty claims.
