1. Producte acabatview
The OSRAM LED Star Classic P40 LED Lamp is a professional LED lamp designed for mains voltage applications. It features innovative LED "filament" technology, providing a warm white light (2700K) with a brightness of 470 lumens, equivalent to a conventional 40W incandescent bulb. This lamp is non-dimmable and offers a long lifespan, making it an energy-efficient lighting solution.
- Pleasant Light: Delivers very good light quality with a warm white color, achieving 100% light output instantly without warm-up time.
- Disseny robust: Advanced LED technology ensures high resistance to bumps and vibrations.
- Llarga vida útil: Designed for a lifespan of up to 15,000 hours, contributing to energy efficiency.
- Eficient energètic: Consumes very little energy, suitable for extended use and electricity savings.
Figure 1: Packaging of the OSRAM LED Star Classic P40 LED Lamp, highlighting key features such as 40W equivalent, 470 lumens, warm white light, E14 base, and a 15-year lifespan.
2. Instal·lació
Aquest LED lamp is designed for easy installation into standard E14 lamp holders. Ensure the power supply is turned off before proceeding with installation.
- La seguretat primer: Abans de manipular la lamp, ensure the power to the light fixture is completely switched off at the main circuit breaker to prevent electrical shock.
- Traieu la bombeta antiga: If replacing an existing bulb, allow it to cool down completely before carefully unscrewing it counter-clockwise from the E14 lamp titular.
- Insereix una nova Lamp: Gently screw the OSRAM LED Star Classic P40 LED Lamp clockwise into the E14 lamp holder until it is snug. Do not overtighten.
- Restaura l'alimentació: Un cop lamp is securely installed, restore power to the light fixture at the main circuit breaker.
- Prova: Engegueu l'interruptor de la llum per confirmar la lamp està funcionant correctament.
Figure 2: A single OSRAM LED Star Classic P40 LED Lamp, illustrating its E14 base for easy screw-in installation.
3. Funcionament
The OSRAM LED Star Classic P40 LED Lamp is designed for straightforward operation. Simply turn on the power to the fixture, and the lamp will illuminate instantly.
- Brillantor total instantani: El lamp provides 100% light output immediately upon switching on, with no warm-up time required.
- No regulable: Aquesta lamp is specifically designed as non-dimmable. Attempting to use it with a dimmer switch may result in flickering, damage to the lamp, or premature failure.
- Angle del feix: Offers a wide beam opening of up to 300°, ensuring broad light distribution.
- Qualitat de la llum: Features a good light quality with a Color Rendering Index (CRI) of Ra ≥ 80, providing accurate color representation.
4. Manteniment i cura
The OSRAM LED Star Classic P40 LED Lamp requires minimal maintenance due to its robust design and long lifespan. Follow these guidelines for optimal performance:
- Neteja: Assegureu-vos que lamp està fred i l'aparell està apagat abans de netejar-lo. Netegeu la lamp gently with a soft, dry cloth. Do not use liquid cleaners or abrasive materials.
- Condicions ambientals: Aquesta lamp is intended for indoor use. If used outdoors, it must be installed in a suitable outdoor luminaire that provides adequate protection from elements.
- Gestió de la calor: El lamp produces lower thermal power compared to conventional incandescent lamps, but ensure adequate ventilation around the fixture.
- No UV or IR Emission: El lamp emits no harmful UV or IR radiation in the light beam, making it safe for various applications.
5. Solució De Problemes
If you encounter issues with your OSRAM LED Star Classic P40 LED Lamp, consider the following common troubleshooting steps:
- Lamp No s'encén:
- Comproveu si la lamp is securely screwed into the E14 holder.
- Verify that the power supply to the fixture is on and the circuit breaker has not tripped.
- Prova la lamp in another known working fixture to rule out a faulty lamp titular.
- Parpelleig:
- Assegureu-vos que lamp is not connected to a dimmer switch. This lamp no és regulable.
- Comproveu si hi ha connexions soltes a la fixació o al cablejat.
- Brillantor reduït:
- Assegureu-vos que lamp is clean and free from dust or debris.
- Comproveu la lamp is receiving the correct voltage (240 V).
If problems persist after following these steps, please contact OSRAM customer support.
6. Especificacions
Detailed technical specifications for the OSRAM LED Star Classic P40 LED Lamp:
| Característica | Especificació |
|---|---|
| Marca | OSRAM |
| Nom del model | LEDSCLP40 4W/827 230VGLFR E14 3X2 OSRAM |
| Número de model de l'article | 4058075604186 |
| Tipus de llum | LED |
| Wattage | 4 watts |
| Wat equivalent incandescenttage | 40 watts |
| Brillantor | 470 lúmens |
| Color clar | Blanc càlid (2700 Kelvin) |
| Voltage | 240 Volts |
| Base del bulb | E14 |
| Mida de la forma del bulb | B9 (Spherical) |
| Característica especial | No Dimmable |
| Vida Mitjana | 15,000 hores |
| Índex de reproducció del color (CRI) | ≥ 80 |
| Material | Vidre |
| Dimensions del producte | 1.81 x 3.74 x 5.12 polzades |
| Pes de l'article | 1.69 unces (0.05 quilograms) |
| Ús interior/exterior | Indoor (Outdoor only in suitable luminaires) |
Figure 3: Energy efficiency label for the LEDVANCE (OSRAM) lamp, indicating an energy class of E and energy consumption of 4 kWh per 1000 hours. More details can be found at eprel.ec.europa.eu/qr/1403381.
7. Garantia i Suport
OSRAM LED Star Classic P40 LED Lamps are manufactured to high quality standards and are designed for a long operational life of up to 15,000 hours.
For warranty claims, technical support, or further inquiries, please contact OSRAM customer service or visit the official OSRAM website. Keep your proof of purchase for any warranty-related matters.
You can find more information and products from OSRAM by visiting the Botiga OSRAM a Amazon.
