HYPER GO H16BM & 14301 Brushless RC Cars Instruction Manual

1. Introducció

Thank you for choosing the HYPER GO H16BM or 14301 Brushless RC Car. These high-performance remote control vehicles are designed for enthusiasts seeking speed, durability, and dynamic handling. The H16BM is a fast RC truck, while the 14301 is a 4x4 all-road street bash drift RC car with an independent gyro. Both models feature brushless power systems, robust construction, and advanced electronics for an exhilarating experience.

This manual provides essential information for the safe and effective operation, maintenance, and troubleshooting of your new RC car. Please read it thoroughly before first use.

Imatge 1.1: acabatview of the HYPER GO H16BM RC Truck, 14301 Drift RC Car, and their respective remote controllers, along with rechargeable batteries.

2. Precaucions de seguretat

Operating remote control vehicles requires attention to safety. Failure to follow these guidelines may result in injury or damage to the product or property.

• Feu servir sempre el cotxe RC en zones obertes, allunyats de persones, mascotes i obstacles.
• Do not operate near public roads, water bodies, or in adverse weather conditions.
• Mantingueu les mans, els cabells i la roba solta lluny de les peces mòbils.
• Ensure batteries are fully charged and securely installed before operation.
• Never leave charging batteries unattended. Use only the provided charger or a compatible LiPo charger.
• If the vehicle becomes stuck or entangled, immediately turn off the power on both the vehicle and the transmitter.
• Es recomana la supervisió d'un adult per als operadors més joves.

3. Configuració

3.1 Càrrega i instal·lació de la bateria

1. Connecteu el carregador subministrat a una presa de corrent.
2. Connect the LiPo battery to the charger. Ensure correct polarity.
3. Charge the battery until the charger indicates a full charge. Charging times may vary.
4. Un cop carregada, desconnecteu la bateria del carregador.
5. Obriu el compartiment de la bateria del cotxe RC.
6. Insert the charged battery into the compartment and secure it. Ensure the battery is properly seated to prevent movement during operation.

3.2 Configuració del transmissor

• Install 4x AA batteries (not included) into the transmitter, observing correct polarity.
• Turn on the transmitter. The indicator light should illuminate.
• Turn on the RC car. The car and transmitter should automatically bind. If not, refer to the binding instructions in the separate quick start guide.

3.3 Gyro Adjustment (Model 14301)

The 14301 model features an independent GYRO system to assist with dynamic handling and precise straight-line driving, especially during drifts. It helps correct the car's tail flick. It is recommended to adjust the gyro sensitivity to approximately 75% for optimal performance.

Image 3.1: The independent Gyro unit (left) and adjustable oil-filled shocks (right) on the HYPER GO 14301 RC Car, crucial for stability and handling.

4. Instruccions de funcionament

4.1 Controls bàsics

• Activador de l'accelerador: Estireu per accelerar endavant, empenyeu per frenar/retrocedir.
• Volant: Gireu a l'esquerra o a la dreta per dirigir el vehicle.
• Ajustos de retall: Use the trim dials on the transmitter to fine-tune steering and throttle for straight-line tracking.

4.2 Performance Capabilities

Both models are equipped with powerful brushless motors and ESCs, offering impressive speed.

• H16BM: With a 2S 7.4V 1050 mAh LiPo battery, it can reach speeds of 27+ mph (45 kph). When upgraded to a 3S LiPo battery (not included), furious speeds of 42+ mph (68 kph) are achievable under optimum conditions.
• 14301: With a 2S 7.4V 2000 mAh battery, it bursts out at 26+ mph (42 kph). The E45A ESC is perfectly matched for 3S battery power, allowing it to reach an amazing 34 mph high speed.

Image 4.1: The HYPER GO H16BM RC Truck in action, highlighting its speed capabilities with 2S and 3S LiPo batteries.

Image 4.2: The HYPER GO 14301 RC Car showcasing its speed potential with 2S and 3S batteries, along with its internal brushless motor and ESC.

4.3 Lighting System (Model 14301)

The 14301 model features simulated lights, including turn signals, brake lights, and police lights, which are linked with the vehicle's control. These lights add to the realism and fun of operation.

Imatge 4.3: posterior view of the HYPER GO 14301 RC Car demonstrating its functional brake lights, which are linked to the vehicle's control inputs.

5. Manteniment

Regular maintenance is crucial for extending the lifespan and performance of your RC car.

5.1 Neteja

• After each use, especially in dusty or dirty conditions, clean the vehicle thoroughly.
• Use a soft brush or compressed air to remove dirt and debris from the chassis, suspension, and drivetrain.
• Netegeu el cos amb anunciamp tela. Eviteu utilitzar productes químics aggressivs.

5.2 Cura de la bateria

• Always store LiPo batteries in a cool, dry place, away from direct sunlight and extreme temperatures.
• Do not overcharge or over-discharge batteries. Follow manufacturer guidelines for charging and discharging.
• If storing for extended periods, charge batteries to a storage voltage (typically 3.8V per cell).

5.3 Inspecció de components

Periodically inspect the following components for wear or damage:

• Xassís i suspensió: Check for cracks, bends, or loose screws. The H16BM features a honeycomb chassis, and the 14301 has a 6061 aluminum alloy chassis with an 8MM central support bar. Both models include F/R zinc metal reinforced sheets for impact resistance.
• Transmissió: Inspect metal gears, metal differentials, and 16 metal bearings for smooth operation. Ensure the 5.5MM diameter axle and M4 nuts are secure.
• Xocs: Comproveu si els amortidors plens d'oli tenen fuites i que estiguin ben drenats.amping. The package includes extra high rebound shock springs for replacement.
• Pneumàtics: Examine tires for wear and tear. The product includes extra drift tires, two more sets of on-road rubber tires, and rally tires for various terrains.
• Para-xocs: Ensure the large front foam bumper is intact for maximum protection.
• Pull Rods: Verify adjustable pull rod linkages are secure and undamaged.

Imatge 5.1: Detallada view of the ultra-durable metal driving system, including pre-mounted soft sponge inserted tires, rechargeable LiPo battery, and adjustable pull rods.

Image 5.2: Illustration of the large front foam bumper integrated with the body for maximum protection, alongside the F/R zinc metal reinforced sheets.

Image 5.3: A display of extra accessories provided, including a protective shell to prevent entry of stones and weeds, 4 high rebound shock springs, 8 clips, drift tires, two more sets of on-road rubber tires, and rally tires.

Image 5.4: Additional components provided, including extra CVD (Constant Velocity Drive) shafts and an extra body shell, for maintenance and customization.

6. Solució De Problemes

This section addresses common issues you might encounter with your HYPER GO RC car.

If you encounter issues not listed here, or if solutions do not resolve the problem, please contact HYPER GO customer support.

7. Especificacions

8. Garantia i Suport

HYPER GO is committed to providing high-quality products. For specific warranty information, please refer to the documentation included with your purchase or visit the official HYPER GO store on Amazon.

Replacement parts for your HYPER GO RC car are available directly from the HYPER GO store on Amazon. This ensures you can easily maintain and repair your vehicle, extending its enjoyment.

For technical support, troubleshooting assistance beyond this manual, or inquiries about parts, please contact HYPER GO customer service through the Amazon platform or the official brand weblloc.

Visit the HYPER GO Store: HYPER GO Official Store
