Introducció
Thank you for choosing the Saker Rechargeable Camping Fan. This manual provides comprehensive instructions for the safe and efficient operation, maintenance, and troubleshooting of your new fan. Please read this manual thoroughly before first use and retain it for future reference.
Producte acabatview
Components
- Unitat de ventilador: Features double-blades for powerful airflow and a protective grille.
- Unitat base: Houses the control panel, battery, and charging ports.
- LED Lanterns: Integrated lights around the fan grille.
- Ganxo per penjar: Located on the top handle for suspending the fan.
- Comandament a distància: For convenient operation from a distance. Includes a storage slot on the base.
- Ports de càrrega: Type-C and USB-A ports for charging the fan and external devices.
Característiques clau
- Bateria recarregable de 20000 mAh: Provides 8.5-200 hours of operation and functions as a power bank.
- 3-Level Brightness LED Lights: Aids navigation in low-light conditions.
- 4 Adjustable Fan Speeds: Offers personalized cooling from natural wind to high speed.
- Remote and Button Control: Flexible operation options.
- Double-Blade Design: Enhances airflow.
- 270° Rotation & 45°/90° Auto-Oscillation: Directs airflow efficiently.
- Mode de repòs: Turns off indicator lights for undisturbed sleep.
- Funció de temporitzador: Customizable working times (1, 2, 4, or 8 hours).
- Portàtil i lleuger: Weighs 3.08 lbs, designed for easy carrying.
- Col·locació versàtil: Es pot penjar o col·locar sobre una superfície plana.

Image: The Saker Rechargeable Camping Fan, showing its main unit, remote control, and a smartphone connected for charging, highlighting its power bank capability.
Configuració
Càrrega inicial
Before first use, fully charge the fan. Connect the provided Type-C cable to the fan's Type-C input port and the other end to a compatible USB power adapter (not included). The battery indicator lights on the control panel will show charging progress. A full charge typically takes 9-10 hours.

Image: A person using the Saker Camping Fan outdoors while working on a laptop, demonstrating its portability and battery life for extended use.
Opcions d'ubicació
- Dempeus: Place the fan on any flat, stable surface. Ensure the base is secure to prevent tipping.
- Penjant: Utilize the built-in hook on the top handle to hang the fan inside a tent, from a branch, or other suitable overhead support. Ensure the hook is securely fastened.

Image: The Saker Camping Fan displayed in two scenarios: hanging inside a tent providing light and airflow, and standing on a table for outdoor dining, illustrating its versatile placement options.
Instruccions de funcionament
Mètodes de control
The Saker Camping Fan can be operated using either the control buttons on the base unit or the included remote control.
- Control de botons: Press the corresponding buttons on the fan's base to adjust settings.
- Comandament a distància: The remote allows control from up to 16.4 feet away. Store the remote in the designated slot on the side of the base when not in use to prevent misplacement.

Image: A close-up of the Saker Camping Fan's control panel on the base and the remote control, demonstrating both methods of operation and the fan's rotation and oscillation capabilities.
Funcionament del ventilador
- Encès/apagat: Premeu el botó d'engegada del tauler de control o del comandament a distància per encendre o apagar el ventilador.
- Ajustar la velocitat del ventilador: Press the fan speed button (usually indicated by fan icons or +/-) to cycle through the 4 available speeds: Natural Wind, Low, Medium, and High.
- Rotation and Oscillation:
- The fan head can be manually rotated 270° vertically to direct airflow.
- Press the oscillation button to activate automatic horizontal oscillation (45° to 90°). Press again to stop.

Image: A visual representation of the Saker Camping Fan's three LED light brightness levels and four adjustable fan speeds, illustrating the different airflow patterns.
LED Lantern Operation
Press the light button (indicated by a light bulb icon) on the control panel or remote to cycle through the 3 brightness levels of the integrated LED lanterns. Press again to turn the lights off.
Funcions avançades
- Mode de repòs: Press the sleep mode button (indicated by a crescent moon icon) to activate sleep mode. This will turn off all indicator lights on the fan for undisturbed sleep. The fan will continue to operate at its current settings. Press again to exit sleep mode.
- Funció de temporitzador: Press the timer button (indicated by a clock icon) to set the fan to automatically turn off after a specified duration. Available timer settings are 1, 2, 4, or 8 hours. Cycle through the options by pressing the button repeatedly.

Image: A child sleeping peacefully with the Saker Camping Fan operating in sleep mode, demonstrating the low noise level and timer function for power conservation.
Ús com a Power Bank
The Saker Camping Fan can be used to charge external devices. Connect your device's charging cable to the USB-A output port on the side of the fan's base. The fan's battery will then supply power to your device.
Manteniment
- Neteja: Ensure the fan is turned off and unplugged before cleaning. Use a soft, dry cloth to wipe down the exterior surfaces. For stubborn dirt, a slightly damp cloth can be used, followed by a dry cloth. Do not use abrasive cleaners or allow water to enter the fan motor or electrical components.
- Neteja de reixes: Periodically clean the fan grille to remove dust and debris that may accumulate and affect airflow. Use a soft brush or a vacuum cleaner with a brush attachment.
- Cura de la bateria: To prolong battery life, avoid fully discharging the battery frequently. Recharge the fan regularly, especially if it will be stored for an extended period. Store the fan in a cool, dry place.
- Emmagatzematge: When not in use, store the fan in its original packaging or a protective cover to prevent dust accumulation.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| El ventilador no s'encén. | La bateria està esgotada. | Carregueu el ventilador completament. |
| El ventilador no s'encén. | Botó d'engegada no premut correctament. | Ensure the power button is pressed firmly. If using remote, check remote battery. |
| LED lights are dim or not working. | La bateria és baixa. | Charge the fan. |
| Fan is not oscillating. | Funció d'oscil·lació no activada. | Press the oscillation button to activate. |
| External device not charging from fan. | Fan battery is low or cable is faulty. | Assegureu-vos que el ventilador estigui carregat. Proveu un altre cable USB. |
Especificacions
- Marca: Saker
- Nom del model: SAK
- Color: Taronja
- Disseny de ventilador elèctric: Ventilador de taula
- Font d'alimentació: Funciona amb bateria
- Estil: Modern
- Dimensions del producte: 4.05 "P x 8.58" W x 10.66" H
- Característiques especials: Lightweight, Oscillating, Portable
- Usos recomanats: Refrigeració
- Tipus d'acabat: Recobert de pols
- Capacitat de flux d'aire: 213 CMPH
- Velocitat: 4 RPM (refers to number of speeds, not actual RPM)
- Voltage: 3.7 Volts
- Components inclosos: Remot
- Ús interior/exterior: A l'aire lliure
- Mètode de control: Remot
- Tipus de connector: USB tipus C, USB tipus A
- Material de la fulla: Plàstic
- És sense fil?: Sí
- Nombre de nivells de potència: 4
- Mida: 20000 mAh
- Pes de l'article: 3.45 lliures
- Bateries: Necessites 1 piles de ions de liti (incloses)
Vídeo oficial del producte
Video: An official product video demonstrating the features and usage of the Saker Rechargeable Camping Fan, including its portability, adjustable settings, and power bank functionality.
Garantia i Suport
Saker products are designed for durability and performance. For any questions, technical assistance, or warranty claims, please refer to the contact information provided with your purchase or visit the official Saker weblloc web. Si us plau, conserveu el comprovant de compra per a finalitats de garantia.
Per a més informació, visiteu el Saker Store on Amazon.
