MASINGO Sonoro G5 Karaoke Machine User Manual

Introducció

This manual provides detailed instructions for the setup, operation, and maintenance of your MASINGO Sonoro G5 Karaoke Machine. Please read this manual thoroughly before using the product to ensure proper function and longevity.

Image: The MASINGO Sonoro G5 Karaoke Machine, featuring a black finish, two wireless microphones stored on top, and a vibrant LED light ring on its main speaker grille.

Què hi ha a la caixa

Verifiqueu que tots els elements estiguin presents a l'embalatge:

• Sonoro G5 Karaoke Machine
• 2 micròfons sense fils
• USB Charging Cable & Plug
• AUX Cable & TV Cable
• Manual d'usuari (aquest document)

Image: An illustration showing the MASINGO Sonoro G5 Karaoke Machine alongside its accessories: two wireless microphones, a 3.5mm AUX cable, a COAX TV cable, a USB-C to USB-A charging cable, and a power adapter.

Característiques del producte

• Powerful Tri-Speaker System: Features a central 5.25-inch speaker and dual 1.6-inch side speakers, delivering a combined 30 watts of clear audio output.
• Duet-Friendly Microphones: Includes two wireless microphones that auto-connect upon activation and store conveniently within the machine.
• Compact & Long-Lasting: Portable design with an integrated handle and a battery providing 3-4 hours of operation.
• Connexions sense fissures: Supports Bluetooth, Aux input, USB, MicroSD, and includes a COAX cable for TV connectivity.
• Llums LED dinàmiques: Equipped with 11 LED light patterns to enhance the karaoke experience, including a unique karaoke mode to remove original vocals.

Imatge: Una pancartaasing the MASINGO Sonoro G5, emphasizing its triple speaker clarity, integrated microphone convenience, compact and durable design, and sleek, functional aesthetics with built-in LED lights.

Configuració

1. Desembalatge: Traieu amb cura tots els components de l'embalatge. Conserveu l'embalatge per a futurs emmagatzematges o transports.
2. Càrrega de la unitat: Connect the provided USB charging cable to the Sonoro G5 and a power source. The unit requires approximately 4 hours for a full charge.
3. Configuració del micròfon: The two wireless microphones are stored in designated slots on top of the machine. Remove them and ensure they are charged. They will auto-connect to the main unit upon activation.
4. Col·locació: Place the Sonoro G5 on a stable, flat surface. Ensure adequate ventilation around the unit.

Image: A young child happily carrying the MASINGO Sonoro G5 karaoke machine by its integrated handle, illustrating its compact size and portability for on-the-go use.

Instruccions de funcionament

Tauler de control acabatview

Imatge: Una imatge detallada view of the MASINGO Sonoro G5's control panel, highlighting various buttons and knobs for mode selection, volume control, microphone adjustments, LED effects, and playback controls.

• Pom de volum: Adjusts the main machine volume.
• MIC+/- Buttons: Increases or decreases microphone volume.
• Botó de mode: Cycles through input modes (Bluetooth, AUX, USB, MicroSD).
• Botó LED: Changes LED light patterns.
• Vocal Cut Button: Attempts to remove vocals from a playing track.
• Botó d'eco: Ajusta l'efecte d'eco per als micròfons.

Connexió a fonts d'àudio

1. Mode Bluetooth:
   • Premeu el botó Mode button until "Bluetooth" is announced or displayed.
   • On your smartphone or other Bluetooth device, search for "MASINGO G5" and pair.
   • Once connected, you can stream audio wirelessly.
2. Entrada AUX:
   • Connect one end of the provided AUX cable to the AUX port on the Sonoro G5 and the other end to your audio device's headphone jack.
   • Premeu el botó Mode button until "AUX" is announced or displayed.
3. Reproducció USB/MicroSD:
   • Insert a USB drive or MicroSD card (with compatible audio files) al port respectiu.
   • Premeu el botó Mode button until "USB" or "MicroSD" is announced or displayed. The unit will automatically begin playing supported audio files.
4. TV Connection (COAX Cable):
   • Connect the provided COAX cable from the Sonoro G5 to the appropriate audio input on your television.
   • Select the corresponding audio input on your TV. This allows you to display lyrics on your TV while the Sonoro G5 handles the audio output.

Image: A family gathered around a television, with the MASINGO Sonoro G5 karaoke machine positioned on a coffee table. Lyrics are displayed on the TV screen, demonstrating the TV connectivity feature for an enhanced karaoke experience.

Ús dels micròfons

• Turn on the wireless microphones. They will automatically pair with the Sonoro G5.
• Ajusteu el volum del micròfon amb el botó MIC+/- botons de la unitat principal.
• Ajusteu l'efecte d'eco amb el botó Ressò knob for desired vocal enhancement.

Image: Two hands holding the MASINGO wireless microphones, illustrating their design and emphasizing features like quick sync activation and rechargeable batteries with a 3-hour battery life and Type-C charging.

Efectes de llum LED

• Premeu el botó LED button to cycle through the 11 available light patterns.
• The dynamic LED ring light on the front speaker enhances the ambiance of your performance.

Manteniment

• Neteja: Feu servir un drap suau i sec per netejar l'exterior de la unitat. No utilitzeu netejadors líquids ni materials abrasius.
• Emmagatzematge: When not in use, store the unit in a cool, dry place away from direct sunlight and extreme temperatures. Ensure microphones are securely stored in their slots.
• Cura de la bateria: For optimal battery life, fully charge the unit before long periods of storage and recharge every 3-6 months if not in regular use.
• Cura del micròfon: Keep microphones dry and clean. Avoid dropping them to prevent damage.

Resolució de problemes

Especificacions

Garantia i Suport

For warranty information or technical support, please refer to the official MASINGO website or contact their customer service directly. Details are typically provided on the product packaging or through the retailer where the product was purchased.

You can visit the MASINGO Store for more information: MASINGO Official Store
