Krups Evidence Eco-Design Automatic Coffee Machine User Manual

1. Introducció i finalview

The KRUPS Evidence Eco-Design automatic espresso machine is engineered to deliver exceptional coffee while adhering to an eco-conscious design philosophy. This appliance offers a 100% automatic beverage preparation process, ensuring optimal percolation from bean to cup. It features a One-Touch Cappuccino function, allowing you to effortlessly prepare your favorite drinks. This high-performance machine can serve beverages in one or two cups and is constructed from 52% recycled plastic, with up to 90% recyclability (based on total plastic parts by weight).

Key features include an intuitive Backlight control panel for easy selection of drinks, a durable metal brewing group for superior heat conduction, and a fully automatic cleaning system for hassle-free maintenance.

Davant view of the Krups Evidence Eco-Design Automatic Coffee Machine.

2. Configuració

Follow these steps to set up your coffee machine for first use:

1. Desempaquetar la màquina: Carefully remove all packaging materials and place the machine on a stable, flat surface.
2. Components nets: Wash the water tank, drip tray, and coffee grounds collector with warm, soapy water. Rinse thoroughly and dry.
3. Omplir el dipòsit d'aigua: Fill the water tank with fresh, cold water up to the MAX level. Ensure it is properly seated in the machine.
4. Omplir la tolva de grans: Open the lid of the bean hopper and pour fresh coffee beans into it. Close the lid securely.
5. Connectar l'alimentació: Connecteu el cable d'alimentació a una presa elèctrica amb connexió a terra.
6. Cicle d'esbandida inicial: The machine will prompt you to perform an initial rinse cycle. Follow the on-screen instructions. Place a container under the coffee spouts to collect the water.

Filling the bean hopper with fresh coffee beans.

3. Instruccions de funcionament

Your Krups Evidence Eco-Design machine offers a variety of beverages with intuitive controls.

3.1 Tauler de control acabatview

The Backlight control panel allows for easy selection of your desired drink. Simply touch the icon corresponding to the beverage you wish to prepare.

The intuitive Backlight control panel for beverage selection.

3.2 Preparació de begudes de cafè

The machine can prepare Ristretto, Espresso, Long Coffee, and Americano.

1. Col·loqueu una o dues tasses sota els brocs del cafè.
2. Select your desired coffee beverage from the control panel.
3. La màquina moldrà els grans de cafè automàticament i prepararà el cafè.

Espresso being dispensed into a glass cup.

3.3 Preparació de begudes a base de llet

Enjoy Cappuccino, Latte Macchiato, and Caffè Latte with the integrated milk system.

1. Connect the milk tube to the machine's milk frother and insert the other end into a container of cold milk.
2. Place your cup(s) under the coffee and milk spouts.
3. Seleccioneu la beguda amb llet que desitgeu (per exemple, cappuccino, latte macchiato).
4. The machine will automatically froth the milk and brew the coffee in sequence.

Milk frothing process for a latte macchiato.

Two perfectly layered latte macchiatos.

3.4 Funció d'aigua calenta

For tea or other hot beverages, select the 'Hot Water' option from the control panel.

4. Manteniment

Regular maintenance ensures the longevity and optimal performance of your Krups coffee machine. The machine features a fully automatic cleaning system, certified for microbiological harmlessness by TÜV Rheinland.

4.1 Neteja diària

• Safata de degoteig i contenidor de cafè mòlt: Buideu i esbandiu la safata de degoteig i el contenidor de cafè mòlt diàriament.
• Sistema de llet: After preparing milk-based drinks, perform the automatic milk system cleaning cycle as prompted by the machine. This is crucial for hygiene and preventing blockages.

4.2 Deep Cleaning and Descaling

• Pastilles de neteja: The machine will indicate when a deep cleaning cycle is required. Use a Krups cleaning tablet as instructed by the machine's display. The closed percolation system makes this process effortless.
• Descalcificació: The machine will also prompt you when descaling is necessary. Use a suitable descaling solution and follow the on-screen instructions carefully.

Using a cleaning tablet for the automatic cleaning cycle.

5. Solució De Problemes

Si teniu problemes amb la vostra màquina, consulteu els següents problemes i solucions habituals:

• No es dispensa cafè:
  • Comproveu si el dipòsit d'aigua està ple i inserit correctament.
  • Ensure the bean hopper has enough coffee beans.
  • Verify that the coffee grounds container is not full.
• Cafè feble:
  • Adjust the coffee strength setting on the control panel.
  • Check the grind setting; a finer grind typically produces stronger coffee.
  • Ensure you are using fresh coffee beans.
• Sense escuma de llet o escuma de mala qualitat:
  • Ensure the milk tube is clean and not blocked. Perform a milk system cleaning cycle.
  • Utilitzeu llet fresca i freda.
  • Check that the milk tube is fully submerged in the milk.
• Fuita de la màquina:
  • Check if the water tank is properly seated and not damaged.
  • Ensure the drip tray is correctly positioned.
  • If the leak persists, contact customer support.
• Missatge d'error a la pantalla:
  • Refer to the machine's display for specific error codes and follow the recommended actions.
  • If the issue is not resolved, try restarting the machine.

6. Especificacions

7. Garantia i Suport

KRUPS is committed to product durability and repairability. This machine benefits from a Compromís de reparabilitat de 15 anys, ensuring that spare parts and repair services are available through a global network of authorized repairers.

For further assistance, technical support, or warranty claims, please refer to the contact information provided in your product packaging or visit the official KRUPS weblloc per a la vostra regió.
