Producte acabatview
The Hansgrohe ShowerSelect Comfort S flush-mounted thermostat is designed to enhance your bathroom experience with its sleek design and intuitive functionality. This thermostat controls two water outlets, providing precise temperature and flow management for your shower or bath. Its ultra-flat construction offers more space and a modern aesthetic.
Instruccions d'instal·lació
The ShowerSelect Comfort S thermostat requires flush-mounted installation. A basic body, specifically the Hansgrohe iBox universal 2 (#01500180), is necessary for proper installation. Ensure all plumbing connections are secure and watertight before final assembly. Professional installation is recommended to ensure correct functionality and compliance with local building codes.
Figure 1: Fast Concealed Installation. This image illustrates the process of installing the basic body for the flush-mounted thermostat.
Figure 2: Product Dimensions. Refer to this diagram for precise measurements required for installation planning.
Funcionament del termòstat
Water On/Off (Select Function)
The thermostat features large, intuitive buttons for turning water on and off. Press the upper or lower button to activate the corresponding water outlet (e.g., head shower or hand shower). Both functions can be used simultaneously if desired.
Figure 3: Easy On and Off. Simply press the designated buttons to control water flow to your desired outlet.
Control de temperatura
The thermostat maintains a constant desired water temperature. To adjust the temperature, rotate the central handle. The SeguretatStop feature prevents accidental scalding by requiring a deliberate action (usually a button press on the handle) to increase the temperature above 40°C.
Figure 4: Increase Temperature Safely. The SafetyStop feature ensures water temperature is controlled to prevent scalding.
Control de cabal d'aigua
The slim lower handle allows for individual adjustment of the water flow rate, enabling water conservation if desired. This feature provides flexibility in your showering experience.
Figure 5: Convenient Water Control. Adjust the water flow precisely using the dedicated handle.
Manteniment i cura
To ensure the longevity and appearance of your Hansgrohe thermostat, regular cleaning is recommended. The 'Quick Clean' feature simplifies maintenance. Use mild cleaning agents and a soft cloth. Avoid abrasive cleaners, scouring pads, or harsh chemicals, as these can damage the chrome finish. The thermostat also supports thermal disinfection for hygiene purposes.
Figure 6: Easy to Clean. The smooth chrome surface allows for quick and effective cleaning.
Resolució de problemes
If you experience issues with your thermostat, first check the water supply to your home. Ensure the iBox universal 2 basic body is correctly installed and accessible. Verify that the temperature and flow controls are set appropriately. For persistent problems such as inconsistent temperature, low flow, or leaks, it is recommended to consult a qualified plumber or contact Hansgrohe customer support for assistance.
Especificacions tècniques
| Característica | Especificació |
|---|---|
| Fabricant | Hansgrohe |
| Número de part | 15554000 |
| Dimensions del producte | 4.2 x 15.5 x 15.5 cm |
| Pes de l'article | 2.31 kg |
| Color | Chrome |
| Estil | Contemporània |
| Acabar | Chrome |
| Material | Metall |
| Mètode d'instal·lació | Single Hole, Flush-Mounted |
| Nombre de nanses | 2 |
| Tipus de muntatge | Muntatge de paret |
| Característiques especials | Ultra-Flat Construction, Thermostat Function, Touch-On/Touch-Off Operation (Select), Water Flow Control, SafetyStop (40°C) |
| Components inclosos | Functional block, mounting material, thermostat, assembly instructions |
| Usos recomanats del producte | Dutxa |
Garantia i assistència al client
Hansgrohe provides a 5-year voluntary manufacturer's warranty on this product, reflecting its high quality standards. Additionally, replacement parts are guaranteed to be available for up to 15 years after the product line expires, ensuring long-term usability. For technical assistance, warranty claims, or to purchase replacement parts, please refer to the contact information provided with your purchase or visit the official Hansgrohe weblloc per a la vostra regió.
