Introducció
This manual provides detailed instructions for the safe and effective use of your VASTFIRE USB-C Rechargeable Green Flashlight. Please read this manual thoroughly before operating the device to ensure optimal performance and longevity.
Image: The VASTFIRE USB-C Rechargeable Green Flashlight in use, demonstrating its green light beam and USB-C charging capability with a smartphone.
Característiques del producte
- Green Light Illumination: Specifically designed for hunting and tactical applications, providing a green light beam that is less disruptive to certain animal species.
- Feix ajustable: Features a zoomable and focusable beam, allowing transition between a wide floodlight for close-range illumination (up to 500 feet) and a tight spotlight for long-range identification (up to 1000 yards).
- Múltiples modes de funcionament: Offers a single brightest mode when connected with the pressure switch for tactical use, and five modes (High, Mid, Low brightness, Strobe, and SOS) when using the tail cap switch.
- USB-C Rechargeable with Power Bank Function: Equipped with a USB-C charging port for convenient recharging and a standard USB Type-A output port to function as a power bank for charging other devices.
- Indicador de bateria baixa: A red indicator light illuminates to warn when the battery power is low.
- Construcció duradora: Made from lightweight aluminum casing, water and dust-proof with an IP65 rating, ensuring reliability in various conditions.
- Opcions de muntatge versàtils: Features a 48mm bezel diameter and 1-inch body, compatible with most standard mounts, including universal scope and rail mounts.
Contingut del paquet
En obrir el paquet, comproveu que hi hagi tots els components següents:
- USB-C Green Light Rechargeable Flashlight
- Rechargeable Battery (1 D battery included)
- Cable de càrrega (USB-C)
- Pressure Switch (Coiled tactical click switch tailcap)
- Push Button On/Off Tailcap
- Muntatge del carril
- Muntatge d'abast
Imatge: Una completa view of the VASTFIRE Green Flashlight kit, showing the flashlight, pressure switch, charging cable, battery, and various mounting accessories.
Configuració
1. Instal·lació de la bateria
- Desenrosqueu la tapa posterior de la llanterna girant-la en sentit antihorari.
- Insert the included D battery with the positive (+) end facing towards the flashlight head.
- Torneu a enroscar la tapa de la cua en sentit horari fins que estigui ben ajustada.
2. Càrrega de la llanterna
The flashlight features a USB-C charging port. Ensure the battery is installed before charging.
- Locate the USB-C input port on the flashlight body.
- Connect the provided USB-C charging cable to the flashlight's USB-C port.
- Connecteu l'altre extrem del cable a una font d'alimentació USB compatible (per exemple, un adaptador de paret, un port USB de l'ordinador).
- The power indicator light on the flashlight will turn red during charging and green when fully charged.
Image: Close-up of the VASTFIRE flashlight demonstrating its USB-C charging capability and its function as a power bank to charge a smartphone.
3. Mounting the Flashlight
The flashlight comes with both a rail mount and a scope mount for versatile attachment to firearms or other equipment.
- Muntatge de ferrocarril: Attach the rail mount to your firearm's Picatinny or Weaver rail. Secure the flashlight into the mount and tighten the screws until firm.
- Muntura de l'abast: Use the scope mount to attach the flashlight directly to your scope tube. Ensure the mount is securely fastened to both the scope and the flashlight.
- For optimal stability, ensure all mounting screws are tightened appropriately, but do not overtighten.
Instruccions de funcionament
1. Engegada/Apagada i Selecció de Mode
The flashlight offers two primary methods for operation: using the standard push-button tail cap or the coiled tactical pressure switch.
- Using the Push-Button Tail Cap:
- Press the button firmly to turn the flashlight ON or OFF.
- With the flashlight ON, lightly press the button (without clicking) to cycle through the five modes: High, Mid, Low, Strobe, and SOS. A full click will turn the flashlight off.
- Using the Coiled Tactical Pressure Switch:
- Replace the standard tail cap with the pressure switch tail cap.
- When the pressure switch is connected, the flashlight operates in a single, brightest mode.
- Press and hold the pressure pad for momentary on. Release to turn off.
- Some pressure switches may have a constant on/off button in addition to the momentary pad. Refer to your specific pressure switch for details.
Image: Illustration of the VASTFIRE flashlight's operating modes, including the single brightest setting with the remote pressure switch and the five modes (High, Mid, Low, Strobe, SOS) available with the standard tail cap switch.
2. Adjusting the Beam (Zoom Function)
The flashlight features an adjustable head to change the beam from a wide floodlight to a focused spotlight.
- To adjust the beam, gently slide the head of the flashlight forward or backward.
- Sliding the head forward will narrow the beam into a focused spotlight for long-range illumination.
- Sliding the head backward will widen the beam into a floodlight for broader area illumination.
Image: The VASTFIRE flashlight showcasing its adjustable beam capability, transitioning from a narrow 1000-yard spotlight to a wide 500-foot floodlight.
3. Ús com a bateria externa
Your VASTFIRE flashlight can also serve as an emergency power bank to charge small electronic devices.
- Locate the standard USB Type-A output port on the flashlight body (next to the USB-C input).
- Connect your device's charging cable to this USB output port.
- La llanterna començarà a carregar el dispositiu. Superviseu l'indicador de càrrega del dispositiu.
Manteniment
- Neteja: Netegeu el cos de la llanterna amb un drap net i suau. Per a la brutícia persistent, netegeu lleugeramentamp es pot fer servir un drap. No utilitzeu productes de neteja abrasius ni dissolvents.
- Lubricació: Periodically apply a thin layer of silicone grease to the O-rings and screw threads to maintain water resistance and smooth operation.
- Cura de la bateria: If the flashlight will not be used for an extended period, remove the battery to prevent leakage and damage. Store batteries in a cool, dry place.
- Emmagatzematge: Store the flashlight in a cool, dry environment away from direct sunlight and extreme temperatures.
Image: The VASTFIRE flashlight partially submerged in water, illustrating its IP68 standard for total protection against water and dust, including submersion up to 25 meters for 5 hours.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| La llanterna no s'encén. | Low or dead battery; Incorrect battery insertion; Loose tail cap; Faulty switch. | Charge the battery or replace it. Ensure battery is inserted correctly (positive end towards head). Tighten the tail cap. If using pressure switch, ensure it is fully connected. |
| La llum és tènue o parpelleja. | Low battery; Loose connections; Dirty contacts. | Recharge the battery. Ensure tail cap and head are tightly screwed. Clean battery contacts and flashlight threads with a clean cloth. |
| Beam adjustment is stiff. | Dirt or debris in the zoom mechanism. | Clean the exterior of the flashlight head. Avoid forcing the mechanism. |
| La funció del banc d'energia no funciona. | Flashlight battery too low; Incorrect cable; Device incompatibility. | Ensure flashlight battery is sufficiently charged. Use a known good charging cable. Verify device compatibility with standard USB charging. |
Especificacions
| Nom del model: | VA-F04 |
| Tipus de font de llum: | LED (verd) |
| Brillantor: | Fins a 2000 lúmens |
| Distància màxima del feix: | 1000 Yards (Spotlight), 500 Feet (Floodlight) |
| Font d'alimentació: | Battery Powered (1 D battery included) |
| Càrrega: | USB-C recarregable |
| Material: | Alumini |
| Nivell de resistència a l'aigua: | IP65 (Resistent a l'aigua) |
| Dimensions del producte: | Approx. 3"D x 3"W x 13"H (Length: 8 1/2 inches, Diameter: 2 1/4 inches) |
| Pes: | 1.2 lliures (aprox. 0.54 kg) |
Image: A hand holding the VASTFIRE flashlight, illustrating its compact size with indicated weight (2.31 oz) and length (4.39 inches). Note: The image text for weight/length seems to contradict the product specifications, so the specifications table uses the provided product data.
Garantia i Suport
Your VASTFIRE USB-C Rechargeable Green Flashlight comes with the following warranty:
- Interruptor de pressió: Free lifetime warranty.
- Flashlight Kit: 2 any de garantia del fabricant.
- Devolucions: Política de devolució de 60 dies.
For any issues, missing parts, or defective items, please contact the manufacturer directly. There is no need to return the item through the retailer; a new, workable item will be provided.
