Introducció
This manual provides essential information for the safe assembly, operation, and maintenance of your Physionics Multifunction Home Gym. Please read this manual thoroughly before using the equipment. Proper assembly and usage are crucial for your safety and to ensure the longevity of the product. This versatile home gym is designed to provide a comprehensive full-body workout, featuring a chest press, butterfly module, lat pulldown, low row, and leg extension, complemented by a 40 kg adjustable weight stack.
Muntatge i muntatge
The Physionics Multifunction Home Gym is delivered as a self-assembly kit. Follow the included multilingual assembly instructions (English, German, French, Spanish, Italian) carefully. Ensure all components are present before beginning assembly.
Components inclosos:
- 1 x Multifunction Home Gym (FTNST001A0000000)
- 9 x Weight Plates (approx. 40 kg total)
- 1 x Multilingual Assembly Manual
- Spare parts (upper/lower/main cables and pulley)
Passos de muntatge:
- Desembaleu tots els components i verifiqueu-los amb la llista de peces del manual de muntatge.
- Follow the step-by-step diagrams and instructions provided in the dedicated assembly manual.
- Ensure all bolts, nuts, and fasteners are securely tightened after each step. Do not overtighten to avoid damaging components.
- Once assembled, perform a thorough safety check. Ensure all cables are correctly routed through the pulleys and all moving parts operate smoothly.
- Place the gym on a stable, level surface.
Imatge: Completa view of the assembled Physionics Multifunction Home Gym, showing its various stations and weight stack.
Instruccions de funcionament
Before each workout, inspect the equipment for any loose parts, damaged cables, or worn padding. Always start with a warm-up and consult a healthcare professional before beginning any new exercise program.
Ajust de pes:
The gym features a 40 kg weight stack. Adjust the resistance by inserting the selector pin into the desired weight plate. Ensure the pin is fully inserted before starting an exercise.
Estacions d'exercici:
- Chest Press / Butterfly Module:
This module allows for both chest press and butterfly exercises. The horizontal handles can be adjusted and mounted either above or below the padding to suit your preference and exercise type. Sit on the seat with your back firmly against the backrest. For chest press, push the handles forward. For butterfly, bring the handles together in front of your chest.
Image: A user demonstrating the chest press exercise on the multifunction home gym.
- Lat Pulldown / Low Row:
Utilize the upper pulley for lat pulldowns and the lower pulley for low rows or bicep curls. Attach the appropriate bar (latissimus bar or cable bar) to the cable. For lat pulldowns, sit facing the machine, grasp the latissimus bar, and pull it down towards your upper chest. For low rows, sit on the floor or bench, place your feet against the footplate, grasp the cable bar, and pull it towards your abdomen.
Image: A user demonstrating the lat pulldown exercise using the upper cable station.
Image: A user demonstrating a cable bicep curl using the lower cable station.
Image: A female user demonstrating the lat pulldown exercise.
- Extensió de cames:
This station targets your quadriceps. Sit on the seat with your back supported and your knees bent, placing your shins behind the padded roller. Extend your legs upwards, pushing against the roller, then slowly return to the starting position.
Image: A user demonstrating the leg extension exercise on the home gym.
Manteniment
Regular maintenance ensures the safety and extends the lifespan of your home gym.
- Neteja: Wipe down the frame and padding with a damp drap després de cada ús per eliminar la suor i la brutícia. Eviteu productes de neteja abrasius.
- Lubricació: Periodically apply a silicone-based lubricant to the guide rods of the weight stack and any moving pivot points to ensure smooth operation and prevent squeaking.
- Inspecció: Regularly check all bolts, nuts, and connections for tightness. Inspect cables and pulleys for any signs of wear, fraying, or damage. Replace any worn or damaged parts immediately. Spare cables and pulleys are included with your purchase.
- Emmagatzematge: Store the equipment in a dry, temperate environment away from direct sunlight and moisture.
Resolució de problemes
Aquí teniu solucions a problemes comuns que podeu trobar:
| Problema | Causa possible | Solució |
|---|---|---|
| Sorolls de grinyol durant l'ús | Loose bolts, dry pivot points, or friction between parts. | Tighten all visible bolts. Apply lubricant to guide rods and pivot points. |
| La pila de pesos no es mou suaument | Guide rods are dry or dirty, or the selector pin is bent. | Clean and lubricate guide rods. Ensure the selector pin is straight and fully inserted. |
| Cables appear loose or frayed | Normal wear and tear, or improper installation. | Inspect cables for damage. If frayed, replace immediately using the provided spare parts. Ensure cables are correctly routed through pulleys. |
| L'equip sembla inestable | Loose assembly bolts or uneven floor surface. | Re-tighten all assembly bolts. Ensure the gym is placed on a flat, stable surface. |
Especificacions tècniques
| Característica | Detall |
|---|---|
| Product Dimensions (L/W/H) | 153 x 118.4 x 203 cm |
| Backrest Dimensions (L/W) | 67 x 23 cm, Thickness: 5 cm |
| Seat Dimensions (L/W) | 30 x 29 cm, Thickness: 5 cm, Height from floor: 56.8 cm |
| Butterfly Width | 89.7 cm |
| Chest Press Handle Width | 86 cm (horizontal handles adjustable) |
| Latissimus Bar Length | 102.5 cm |
| Cable Bar Length | 36.3 cm, Cable Length: 29 cm |
| Weight Plate Dimensions | 37 x 18 x 4.2 cm |
| Pila de pes | 8 x 4.5 kg, 1 x 3.6 kg (approx. 40 kg total) |
| Pes màxim de l'usuari | Aprox. 120 kg |
| Pes total del producte | 58 kg |
| Materials | Q195 Steel, Plastic, Foam Padding (100% Polyurethane) |
| Color | Negre |
| Número de model | FTNST001A0000000 |
| ASIN | B0CPSS1ZYH |
Garantia i Suport
Your Physionics Multifunction Home Gym is designed for durability and comes with included spare parts (upper/lower/main cables and pulley) to assist with long-term maintenance.
For any questions regarding assembly, operation, or if you require further assistance, please refer to the contact information provided with your purchase documentation or visit the official Physionics weblloc per obtenir els detalls d'atenció al client.
