Ergonomic Mid-Back Premium Faux Leather Adjustable Drafting Chair

Introducció

This user manual provides detailed instructions for the assembly, operation, and maintenance of your CHAIRMAN Ergonomic Mid-Back Premium Faux Leather Adjustable Drafting Chair. Designed for comfort and versatility, this chair is suitable for various environments including office, home, school, laboratory, or dental clinic, especially when paired with standing desks or drafting tables.

Informació important de seguretat

This chair has a maximum weight capacity of 295 pounds. To ensure safe use, assemble the chair according to the instructions provided. Do not exceed the maximum weight capacity, as it may lead to instability or damage to the chair. When adjusting the seat height or footrest ring, make sure the controls are properly engaged to avoid unexpected movement. Regularly inspect the chair for any signs of wear or damage and replace any worn or damaged parts immediately. This chair is for indoor use only. Keep it away from water and damp environments to prevent damage or injury.

Contingut del paquet

Before assembly, please verify that all components are present and undamaged. Refer to the diagram below for a visual representation of the parts.

Figura 1: All parts included for assembly. This includes the backrest, seat, footrest, armrests, gas lift, mechanism, casters, base, and a screw kit.

• Respatller (1)
• Seient (1)
• Reposapeus (1)
• Armrest (2)
• Ascensor de gas (1)
• Mechanism (1)
• Rodes (5)
• Base (1)
• Screw Kit (1)

Muntatge i muntatge

Assembly of the CHAIRMAN Drafting Chair is designed to be straightforward, typically taking about 25 minutes. A quality tool (Allen wrench) is included, and no additional tools are required.

Passos de muntatge:

1. Fixeu les rodes a la base: Introduïu les cinc rodes als forats de l'extrem de cada pota de la base de la cadira. Premeu fermament fins que encaixin al seu lloc.
2. Instal·lació de l'elevador de gas: Col·loqueu el cilindre d'elevació de gas al forat central de la base muntada.
3. Fixeu el mecanisme al seient: Secure the chair mechanism to the underside of the seat using the provided screws from the screw kit. Ensure the front of the mechanism aligns with the front of the seat.
4. Connecteu el seient a l'elevador de gas: Carefully place the assembled seat (with mechanism attached) onto the gas lift cylinder. Press down firmly to secure.
5. Col·loqueu els recolzabraços: Secure the armrests to the sides of the seat using the appropriate screws. Ensure they are oriented correctly for flip-up functionality.
6. Col·loca el respatller: Connect the backrest to the seat assembly using the remaining screws.
7. Instal·leu l'anell del reposapeus: Slide the footrest ring onto the gas lift cylinder above the base. Adjust its height and secure it with the control knob.

Figura 2: Fully assembled CHAIRMAN Drafting Chair, ready for use.

Instruccions de funcionament

Your CHAIRMAN Drafting Chair offers several adjustable features to customize your seating experience for optimal comfort and ergonomics.

Ajust de l'alçada del seient:

To adjust the seat height, locate the lever on the right side beneath the seat. While seated, pull the lever up to lower the seat. To raise the seat, stand up slightly and pull the lever up. Release the lever at your desired height.

Figura 3: Demonstrating seat height adjustment and other features.

Ajust del recolzabraços:

The chair is equipped with flip-up and height-adjustable armrests. To flip them up, simply lift them upwards until they lock into a vertical position. To lower them, pull them down. For height adjustment, locate the button or lever on the side of each armrest, press it, and slide the armrest up or down to your preferred height.

Figura 4: Armrest functionality and other chair movements.

Footrest Ring Adjustment:

The 20-inch chrome footrest ring can be adjusted to match your height and preference. Loosen the control knob on the side of the footrest ring, slide the ring up or down the gas lift, and then tighten the knob to secure it in place.

Tilt Function and Tension Control:

The chair features a tilt mechanism allowing for up to 15 degrees of seat tilt. To activate or lock the tilt, use the lever on the left side beneath the seat. To adjust the tilt tension, rotate the knob located at the front center beneath the seat. Turn clockwise to increase tension (making it harder to tilt) and counter-clockwise to decrease tension (making it easier to tilt).

Figura 5: The CHAIRMAN Drafting Chair in an upright position.

Giració de 360°:

The chair seat and footrest ring can swivel 360 degrees, providing flexibility and ease of movement around your workspace.

Manteniment

Regular maintenance will extend the life and performance of your CHAIRMAN Drafting Chair.

• Neteja: For the premium faux leather upholstery, wipe with a soft, damp cloth. For tougher spots, use a mild soap solution and wipe dry immediately. Avoid harsh chemicals or abrasive cleaners.
• Rodes: Periodically check the casters for hair, dust, or debris that may impede smooth rolling. Clean them as needed.
• Maquinari: Every few months, check all screws and bolts to ensure they are tight. Re-tighten if necessary to maintain stability and prevent squeaks.
• Ascensor de gas: Ensure the gas lift operates smoothly. If it becomes stiff or fails to hold height, it may need replacement.
• Inspecció general: Regularly inspect the chair for any signs of wear, cracks, or damage to any components. Address any issues promptly to prevent further damage or potential injury.

Resolució de problemes

Especificacions

Figura 6: Detailed dimensions and material specifications.

Garantia i Suport

The CHAIRMAN Drafting Chair comes with a 12 mesos de garantia for your peace of mind, covering manufacturing defects and material flaws under normal use.

For warranty claims, missing parts, or any product support inquiries, please contact the seller, Chairman Furniture, directly through the platform where you purchased the product. Please have your order number and product model (BL-5018D-BLK-New) ready when contacting support.

For additional information or common questions, you may also refer to the product listing page or the manufacturer's official weblloc.
