1. Producte acabatview
The Jocca Foldable Pedestal Fan is a versatile and portable cooling solution designed for convenience and efficiency. It can be used as both a table fan and a pedestal fan, with an adjustable height ranging from 36 cm to 97.5 cm. Equipped with a 7200mAh rechargeable battery, it offers extended operation up to 24 hours. The fan features 3 speed settings and 4 wind modes, all controllable via an included remote control, ensuring a personalized cooling experience. Its compact, foldable design makes it easy to transport and store.
Image: The Jocca Foldable Pedestal Fan in its extended pedestal configuration, shown with its remote control. The fan is white with a circular head and a sturdy base.
2. Instruccions de seguretat
Please read all safety instructions carefully before using the fan. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- Seguretat general:
- No introduïu els dits ni cap objecte a la reixeta del ventilador quan estigui en funcionament.
- Keep the fan away from water and other liquids. Do not use it in wet or damp ambients.
- Ensure the power adapter and cable are not damaged. If damaged, contact customer support.
- No bloquegeu les entrades o sortides d'aire.
- Aquest aparell no està pensat per ser utilitzat per persones (inclosos nens) amb capacitats físiques, sensorials o mentals reduïdes, o amb manca d'experiència i coneixements, tret que hagin rebut la supervisió o instruccions sobre l'ús de l'aparell per una persona responsable de la seva seguretat.
- Els nens han de ser supervisats per assegurar-se que no juguin amb l'aparell.
- Seguretat de la bateria:
- Use only the charging cable provided or a compatible 5V/2A adapter.
- Do not expose the battery to extreme temperatures (above 60°C or below 0°C).
- No desmunteu, punxeu o curtcircuiteu la bateria.
- If the battery leaks, avoid contact with skin and eyes. Rinse thoroughly with water and seek medical attention.
- Eliminar la bateria d'acord amb la normativa local.
3. Contingut del paquet
Si us plau, comproveu el contingut del paquet en desempaquetar-lo:
- 1 x Jocca Foldable Pedestal Fan (Main Unit)
- 1 x comandament a distància
- 1 x cable de càrrega USB (tipus C)
- 1 x Manual d'usuari (aquest document)
Image: The white remote control for the Jocca fan, showing power, fan speed, and timer buttons.
4. Configuració
- Unfolding the Fan:
Gently pull the fan head upwards from the base. The telescopic rod will extend. Adjust the height to your desired level, from a compact 36 cm for table use to a maximum of 97.5 cm for pedestal use. Ensure the fan head is securely locked in place at the desired angle.
Image: A sequence showing the Jocca fan extending its telescopic rod to adjust height, illustrating its versatility from a compact unit to a full-size pedestal fan.
Image: The Jocca fan in its fully folded, compact state, ready for easy storage or transport.
- Càrrega inicial:
Before first use, fully charge the fan. Connect the USB charging cable to the charging port on the fan's base and plug the other end into a compatible USB power adapter (e.g., 5V/2A phone charger, not included). The charging indicator light will show the charging status. A full charge typically takes several hours.
5. Instruccions de funcionament
5.1 Encès/Apagat
- On Fan Base: Press the power button located on the fan base to turn the fan on or off.
- Ús del control remot: Premeu el botó Poder botó del comandament a distància per encendre o apagar el ventilador.
5.2 Adjusting Fan Speed and Mode
- On Fan Base: Press the fan speed button on the base to cycle through the 3 speed settings and 4 wind modes.
- Ús del control remot: Premeu el botó Velocitat del ventilador button (icon with fan blades) on the remote control to cycle through the available speeds and modes.
5.3 Funció de temporitzador
- Ús del control remot: Premeu el botó Temporitzador button (icon with clock) on the remote control to set a timer for automatic shutdown. Refer to the fan's display or indicator lights for timer settings.
5.4 Ajust de l'angle del capçal del ventilador
The fan head can be manually tilted up or down to direct airflow as desired. Gently adjust the head to the preferred angle.
Imatge: Un costat view of the Jocca fan, demonstrating its ability to tilt the fan head for adjustable airflow direction.
6. Manteniment
6.1 Neteja
- Desconnecteu sempre el ventilador abans de netejar-lo.
- Utilitzeu un suau, damp drap per netejar les superfícies exteriors del ventilador.
- No utilitzeu netejadors abrasius, dissolvents ni productes químics agressius.
- For the fan blades, carefully remove the front grille (if detachable) and wipe the blades with a dry or slightly damp cloth. Ensure all parts are completely dry before reassembling and using the fan.
6.2 Emmagatzematge
When not in use for an extended period, fold the fan into its compact form and store it in a cool, dry place, away from direct sunlight and extreme temperatures. It is recommended to fully charge the battery before storing to maintain battery health.
Image: The Jocca fan fully collapsed and folded, demonstrating its compact size for easy storage or portability.
7. Solució De Problemes
| Problema | Causa possible | Solució |
|---|---|---|
| El ventilador no s'encén. | La bateria està esgotada. Botó d'engegada no premut correctament. | Carregueu el ventilador completament. Premeu el botó d'encesa amb fermesa. |
| Flux d'aire feble. | La velocitat del ventilador és massa baixa. Les entrades/sortides d'aire estan bloquejades. Les aspes del ventilador estan brutes. | Augmenta la velocitat del ventilador. Ensure nothing is obstructing airflow. Netegeu les aspes i les reixes del ventilador. |
| El comandament a distància no funciona. | La pila del comandament a distància està morta. Obstrucció entre el comandament a distància i el ventilador. | Replace remote control battery (if applicable, usually CR2025 or similar). Assegureu-vos que hi hagi una línia de visió clara fins al receptor del ventilador. |
| El ventilador fa un soroll estrany. | Foreign object inside the fan. Fan not placed on a stable surface. | Turn off and unplug the fan. Carefully check for and remove any foreign objects. Col·loqueu el ventilador sobre una superfície plana i estable. |
If the problem persists after trying the above solutions, please contact Jocca customer support.
8. Especificacions
| Característica | Detall |
|---|---|
| Número de model | Jocca Standventilator |
| Dimensions (plegades) | Aproximadament 19.7 cm (diàmetre) x 9.3 cm (alçada) |
| Dimensions (ampliades) | 98P x 40l x 40H centimeters (Max Height: 97.5 cm) |
| Pes | 1 quilograms |
| Capacitat de la bateria | 7200 mAh |
| Temps de funcionament | Up to 24 hours (depending on speed/mode) |
| Poder | 4.8 watts |
| Mètode de control | Buttons on base, Remote Control |
| Configuració de velocitat | 3 velocitats |
| Modes de vent | 4 modes |
| Color | Blanc |
Image: A diagram illustrating the dimensions of the Jocca fan, showing its adjustable height up to 97.5 cm and base diameter of 19.7 cm.
9. Garantia i Suport
Jocca products are manufactured to high-quality standards. This product comes with a standard manufacturer's warranty, typically one year from the date of purchase, covering defects in materials and workmanship under normal use.
For warranty claims, technical support, or any questions regarding your Jocca Foldable Pedestal Fan, please contact Jocca customer service through the retailer where you purchased the product or visit the official Jocca weblloc per obtenir informació de contacte.
Si us plau, conserveu el comprovant de compra per motius de garantia.
