Portronics Breeze 6 Portable Wireless Bluetooth Speaker User Manual

Introducció

The Portronics Breeze 6 is a versatile portable wireless Bluetooth speaker designed to deliver high-quality audio with convenient features. This manual provides detailed instructions for setting up, operating, and maintaining your speaker to ensure optimal performance and longevity.

Característiques del producte

• 35W HD Stereo Sound: Experience rich and clear audio output.
• Llums LED RGB: Dynamic visual effects with 3-mode RGB lighting.
• Trucades mans lliures: Micròfon integrat per a una gestió còmoda de trucades.
• Múltiples opcions de connectivitat: Bluetooth 5.3v, Micro SD Card, AUX, USB, and FM Radio.
• Emparellament TWS: Wirelessly connect two Breeze 6 speakers for a combined 70W stereo experience.
• 6-Hour Playback: Extended battery life for continuous music enjoyment.
• Resistent a l'aigua IPX5: Durable design for splash resistance, suitable for outdoor use.
• Dual Radiators: Enhanced bass performance.

Què hi ha a la caixa

• 1N Portable Speaker
• 1N Charging Cable (Type-C)
• Manual d'usuari 1N

Guia de configuració

Càrrega inicial

Before first use, fully charge the speaker. Connect the provided Type-C charging cable to the speaker's charging port and the other end to a USB power adapter (not included).

Encès/Apagat

1. Per encendre: Manteniu premut el botó d'encesa (G) for a few seconds until the LED lights illuminate.
2. Per apagar: Manteniu premut el botó d'encesa (G) again for a few seconds until the LED lights turn off.

Emparellament Bluetooth

1. Ensure the speaker is powered on and in Bluetooth pairing mode (indicated by a flashing blue LED).
2. Al dispositiu (telèfon intel·ligent, tauleta, ordinador portàtil), activeu el Bluetooth i cerqueu els dispositius disponibles.
3. Select "Portronics Breeze 6" from the list of devices.
4. Un cop connectat, l'indicador LED s'il·luminarà de color blau fix i sentireu una confirmació audible.

Instruccions de funcionament

Control de volum

• Augmenta el volum: Premeu el botó '+'.
• Disminueix el volum: Premeu el botó '-'.

Reproducció de música

• Reproduir/pausa: Premeu el botó Reprodueix / Pausa (▷).
• Pista següent: Premeu i manteniu premut el botó '+'.
• Pista anterior: Premeu i manteniu premut el botó '-'.

Emparellament TWS (True Wireless Stereo)

To achieve a 70W stereo sound experience, you can pair two Portronics Breeze 6 speakers together.

1. Ensure both Breeze 6 speakers are powered on and not connected to any Bluetooth device.
2. On one speaker, press the TWS button (S). It will emit a sound indicating it's searching for another speaker.
3. The two speakers will automatically pair with each other. Once paired, you will hear a confirmation sound.
4. Connect your device to one of the paired speakers via Bluetooth. Both speakers will now play audio in stereo.

RGB LED Lighting Control

The speaker features dynamic RGB LED lights. Use the dedicated LED light control button to cycle through different lighting modes or turn them off.

Trucades mans lliures

Quan es connecta mitjançant Bluetooth, el micròfon integrat permet fer trucades amb mans lliures.

• Respon a la trucada: Premeu el botó Reprodueix / Pausa (▷) una vegada.
• Finalitzar la trucada: Premeu el botó Reprodueix / Pausa (▷) una vegada durant una trucada.
• Rebutja la trucada: Premeu i manteniu premut el botó Reproduir/Pausa (▷) durant 2 segons.

Ràdio FM

1. Premeu el botó Mode (M) to switch to FM Radio mode.
2. Premeu el botó Reprodueix / Pausa (▷) to auto-scan and save available FM stations.
3. Use the '+' and '-' buttons to navigate between saved stations.

USB Drive / SD Card Playback

Insert a USB drive or Micro SD card into the respective port. The speaker will automatically switch to USB/SD mode and begin playing audio files.

Carregant

The Portronics Breeze 6 speaker is equipped with a Lithium Polymer battery, offering approximately 6 hours of playback time on a single charge. Use the provided Type-C cable for charging.

• Connect the Type-C cable to the speaker's charging port.
• Connecteu l'altre extrem del cable a una font d'alimentació USB compatible (per exemple, un adaptador de paret, un port USB de l'ordinador).
• L'indicador LED mostrarà l'estat de càrrega i s'apagarà o canviarà de color quan estigui completament carregat.

Manteniment

• Neteja: Feu servir un drap suau i sec per netejar l'altaveu. No utilitzeu productes químics agressius ni netejadors abrasius.
• Resistència a l'aigua: The speaker is IPX5 water resistant, meaning it can withstand splashes and light rain. Do not submerge the speaker in water. Ensure the port cover is securely closed when exposed to water.
• Emmagatzematge: Guardeu l'altaveu en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.
• Cordó: The speaker includes a lanyard for secure carrying. Ensure it is properly attached before use.

Resolució de problemes

• Sense energia: Assegureu-vos que l'altaveu estigui carregat. Connecteu-lo a una font d'alimentació amb el cable tipus C.
• Cannot Connect Bluetooth: Make sure the speaker is in pairing mode. Turn off and on your device's Bluetooth. If issues persist, try forgetting the device on your phone and re-pairing.
• Sense so: Check the volume levels on both the speaker and your connected device. Ensure the speaker is correctly paired.
• Error d'emparellament TWS: Ensure both speakers are fully charged and not connected to any other Bluetooth device before initiating TWS pairing.
• Recepció de ràdio FM deficient: Try moving the speaker to a different location or adjusting its orientation for better signal.

Especificacions

Garantia i Suport

The Portronics Breeze 6 speaker comes with a 1 any de garantia des de la data de compra.

For any support, queries, or warranty claims, please contact Portronics customer service:

• Correu electrònic: help@portronics.com
• Telèfon: +91 9555-245-245
• Adreça: Portronics Digital Pvt ltd, First Floor Property No D 8 Upper Basement Sector 8 Noida Uttar Pradesh 201301
