Introducció
This manual provides essential information for the assembly, operation, and maintenance of your MOTIONGREY Electric Motor Height Adjustable Standing Desk. Please read this manual thoroughly before use to ensure proper function and safety.
Figure 1: MOTIONGREY Electric Motor Height Adjustable Standing Desk setup with dual monitors.
Informació de seguretat
Per garantir un funcionament segur i evitar danys, si us plau, seguiu les següents pautes de seguretat:
- Límit de pes: Do not exceed the maximum weight capacity of 80 kg (176.4 lbs) on the desk surface. Overloading can cause instability and damage to the motor or frame.
- Mantingueu els nens i les mascotes allunyats de l'escriptori durant el funcionament.
- Assegureu-vos que no hi hagi obstacles en el camí del moviment de l'escriptori (pujant o baixant).
- No us asseieu ni us poseu drets a l'escriptori.
- Only use the desk indoors in a dry environment.
- Desconnecteu l'alimentació abans de la neteja o el manteniment.
Muntatge i muntatge
The MOTIONGREY Electric Motor Height Adjustable Standing Desk requires assembly. It is recommended that two people assemble the desk for ease and safety.
Abans de començar:
- Desembaleu tots els components i verifiqueu-los amb la llista de peces (no inclosa en aquest manual, consulteu l'embalatge).
- Assegureu-vos de tenir prou espai per al muntatge.
- All necessary assembly tools are included with the product.
Passos de muntatge (generals):
- Attach the desk legs to the tabletop.
- Connect the motor and control box according to the wiring diagram (refer to separate assembly instructions if provided).
- Install the control panel/keypad on the underside of the desk.
- Secure all connections and ensure the desk is stable before plugging it in.
Figure 2: Desk dimensions and construction details. The desk features a robust steel frame.
Instruccions de funcionament
Your MOTIONGREY standing desk features an electric motor for smooth height adjustments and a digital memory keypad for convenience.
Funcionament bàsic:
- Ajust de l'alçada: Utilitza el Up i Avall arrows on the control panel to raise or lower the desk to your desired height. The current height will be displayed on the digital keypad.
- Interval d'alçada: The desk can be adjusted from a minimum height of 73 cm (28 inches) to a maximum height of 118 cm (46 inches).
Preajustos de memòria:
The MG digital memory keypad allows you to store two predefined heights for quick adjustments.
- Setting a Preset:
- Adjust the desk to your desired sitting or standing height using the Up/Down arrows.
- Premeu el botó "M" botó (botó de memòria). La pantalla mostrarà "S-".
- Premeu immediatament qualsevol dels dos "1" or "2" to save the current height to that memory position. The display will show "S-1" or "S-2" to confirm.
- Recuperació d'una configuració predefinida:
- Simplement premeu el "1" or "2" botó. L'escriptori es mourà automàticament a l'alçada desada.
The single motor design allows for a movement speed of 20mm/s with quiet operation.
Manteniment
Regular maintenance helps prolong the life and performance of your standing desk.
- Neteja: Netegeu la superfície i el marc de l'escriptori amb un drap suau iamp drap. Eviteu productes de neteja abrasius o productes químics agressius.
- Gestió de cables: Periodically check and organize cables to prevent tangling or damage during height adjustments.
- Elements de fixació: De tant en tant, comproveu tots els cargols i perns per assegurar-vos que estiguin ben ajustats. Torneu-los a apretar si cal.
- Cura del motor: The electric motor is designed for long-term use. Avoid continuous operation for extended periods without rest to prevent overheating.
Resolució de problemes
If you encounter issues with your MOTIONGREY standing desk, refer to the following common problems and solutions:
| Problema | Causa possible | Solució |
|---|---|---|
| L'escriptori no es mou. | Cable d'alimentació desconnectat; Sobrecàrrega; Escalfament del motor. | Comproveu la connexió elèctrica. Reduïu el pes sobre l'escriptori. Deixeu que el motor es refredi durant 20 minuts. |
| L'escriptori es mou de manera irregular o fa un soroll inusual. | Loose connections; Obstruction; Damaged component. | Check all assembly connections. Remove any obstructions. Contact customer support if noise persists. |
| La pantalla digital mostra un codi d'error. | Error específic (per exemple, E01, E02). | Refer to the specific error code in the full assembly manual (if available) or contact customer support. Often, unplugging and replugging the desk can reset minor errors. |
| Desk reaches maximum/minimum height but doesn't stop. | Limit switch issue; Calibration needed. | Perform a reset/calibration procedure (often involves holding down the down button until it reaches lowest point and slightly rises). Consult full manual or support. |
If the problem persists after attempting these solutions, please contact MOTIONGREY customer support.
Especificacions
| Característica | Detall |
|---|---|
| Marca | MOTIONGREY |
| Número de model | SD-WT-TT-WT-160CM |
| Tabletop Dimensions (L x W x Thickness) | 160 cm x 60 cm x 1.5 cm (62.99" x 23.62" x 0.6") |
| Interval d'alçada | 73 cm - 118 cm (28.74" - 46.46") |
| Mecanisme d'elevació | Motor elèctric únic |
| Velocitat d'elevació | 20 mm/s |
| Capacitat màxima de pes | 80 kg (176.4 lliures) |
| Material del marc | Acer d'aliatge |
| Material de taula | Laminated Wood Pattern |
| Color | Negre |
| Muntatge obligatori | Sí (es recomana 2 persones) |
Garantia i Suport
MOTIONGREY is committed to providing quality products. For information regarding product warranty, returns, or technical support, please refer to the warranty card included with your purchase or visit the official MOTIONGREY weblloc.
Protection plans are available for extended coverage. Please check with your retailer for details on 2-Year or 3-Year Protection Plans.
For direct assistance, you may contact MOTIONGREY customer service through their official channels.
