NutriBullet Triple Prep System 1500W

1. Salvaguardes importants

Please read all instructions carefully before operating your NutriBullet Triple Prep System. Failure to follow these instructions may result in injury or damage to the appliance.

• Assegureu-vos sempre que l'aparell estigui desendollat ​​abans de muntar-lo, desmuntar-lo o netejar-lo.
• No submergiu la base del motor en aigua ni en cap altre líquid. Netegeu-la amb un adhesiu.amp només tela.
• Avoid contact with moving parts. Keep hands and utensils out of the container while blending to prevent severe personal injury and/or damage to the blender.
• Do not blend hot liquids in sealed cups. The vented lid on the 1.8L pitcher is designed for hot liquids.
• Never operate the appliance with damaged blades or if the appliance malfunctions or is dropped. Contact customer service for assistance.
• Aquest aparell no està pensat per a persones amb capacitats físiques, sensorials o mentals reduïdes, o amb manca d'experiència i coneixements, llevat que hagin rebut supervisió o instruccions sobre l'ús de l'aparell per part d'una persona responsable de la seva seguretat.
• Mantenir els nens allunyats de l'aparell durant el funcionament.

2. Què s'inclou

Your NutriBullet Triple Prep System comes with the following components:

• Base del motor de 1500 W
• 1.8L Blending Pitcher with Vented Lid
• 1.6L Food Processor Work Bowl
• 2 x To-Go Cups (710ml and 946ml)
• 2 x To-Go Cup Lids
• Stainless Steel Extraction Blade
• Disc de tallar / ratllar
• Ganxo de pastar
• Tallar la fulla
• Pusher for Food Processor

Figure 2.1: Blender Components

Figure 2.2: Food Processor Components

3. Muntatge i instal·lació

3.1 Muntatge de la batedora

1. Col·loqueu la base del motor sobre una superfície neta, seca i anivellada.
2. Attach the 1.8L blending pitcher or a To-Go cup to the motor base. Ensure it is securely twisted into place.
3. For the 1.8L pitcher, ensure the vented lid is properly sealed. For To-Go cups, securely twist the extraction blade onto the cup.
4. Connecteu el cable d'alimentació a una presa de corrent de 220 V.

3.2 Muntatge del processador d'aliments

1. Col·loqueu la base del motor sobre una superfície neta, seca i anivellada.
2. Place the 1.6L food processor work bowl onto the motor base and twist clockwise until it locks into place.
3. Insert the desired blade (chopping blade, kneading hook, or slicing/grating disc) onto the central spindle inside the work bowl.
4. Secure the food processor lid onto the work bowl, ensuring it clicks into place. Use the pusher for adding ingredients through the feed chute.
5. Connecteu el cable d'alimentació a una presa de corrent de 220 V.

Figure 3.1: Food Processor Assembly

4. Instruccions de funcionament

The NutriBullet Triple Prep System features an intuitive touchscreen control panel that adapts to the attached accessory.

Figure 4.1: Control Panel and Accessories

4.1 Using the Touchscreen Control Panel

• The touchscreen activates when an accessory is properly attached to the motor base.
• Available functions (e.g., Low, Medium, High, Pulse) will illuminate based on the accessory.
• Press the desired program or speed setting to begin operation.
• Press the power button or the active program button again to stop.

4.2 Blending with the 1.8L Pitcher

1. Add ingredients to the 1.8L pitcher. Do not exceed the MAX fill line.
2. Secure the vented lid.
3. Place the pitcher onto the motor base and twist to lock.
4. Select a speed (Low, Medium, High) or a pre-programmed setting on the touchscreen.
5. For hot liquids, ensure the vented lid is used to allow steam to escape.
6. Once blending is complete, turn off the appliance, unplug, and carefully remove the pitcher. Use the pouring spout for easy serving.

Figure 4.2: Blending with the Pitcher

4.3 Making Smoothies with To-Go Cups

1. Add ingredients to a To-Go cup. Do not exceed the MAX fill line.
2. Twist the stainless steel extraction blade securely onto the cup.
3. Invert the cup and place it onto the motor base, twisting to lock it into place.
4. Select a speed or a pre-programmed setting. The system is designed for quick smoothie preparation.
5. After blending, unlock the cup from the base, remove the blade, and attach a To-Go lid for convenience.

Figure 4.3: Preparing Smoothies

4.4 Ús del robot de cuina

1. Assemble the food processor with the desired blade (chopping, kneading, slicing/grating).
2. Add ingredients to the work bowl or through the feed chute using the pusher.
3. Assegureu-vos la tapa.
4. Place the assembled food processor onto the motor base and twist to lock.
5. Select a speed (Low, Medium, High) or the Pulse function for controlled processing.
6. After processing, turn off the appliance, unplug, and carefully remove the lid and work bowl.

5. Cura i manteniment

Proper cleaning and maintenance will ensure the longevity and optimal performance of your NutriBullet Triple Prep System.

5.1 Neteja de la base del motor

• Desendolleu sempre la base del motor abans de netejar-la.
• Netegeu la base del motor amb un netejador damp tela. No submergir en aigua.
• Ensure the motor base is completely dry before storing or next use.

5.2 Accessoris de neteja

• All blending pitchers, To-Go cups, lids, and food processor components (work bowl, lid, blades, disc, hook, pusher) are top-rack dishwasher safe.
• Alternatively, wash with warm, soapy water, rinse thoroughly, and air dry.
• Handle blades with extreme care as they are sharp.

Figure 5.1: Easy Cleaning of Pitcher

6. Solució De Problemes

If you encounter any issues with your NutriBullet Triple Prep System, refer to the following common problems and solutions:

• L'aparell no s'encén: Ensure the power cord is securely plugged into a working outlet. Verify that the blending pitcher or food processor bowl is correctly assembled and locked onto the motor base.
• El motor s'atura durant el funcionament: The appliance may have overheated. Unplug the unit and allow it to cool down for at least 15 minutes before attempting to use it again. Reduce the load or liquid amount for future use.
• Leaking from the base: Check that the blade assembly is tightly screwed onto the To-Go cup or that the pitcher lid is properly sealed. Ensure the MAX fill line is not exceeded.
• Ingredients not blending smoothly: Add more liquid to the mixture. Use the Pulse function to break down larger pieces before continuous blending. Ensure blades are clean and free of debris.
• Food processor not processing: Ensure the lid is securely locked onto the work bowl. Check that the blade or disc is correctly seated on the central spindle. Do not overload the bowl.

If the problem persists, contact NutriBullet customer support.

7. Especificacions

Figura 7.1: Dimensions del producte

8. Garantia i assistència

Your NutriBullet Triple Prep System is covered by a manufacturer's warranty. Please refer to the warranty card included in your product packaging for specific terms and conditions.

For technical support, replacement parts, or any inquiries regarding your appliance, please visit the official NutriBullet weblloc web o poseu-vos en contacte amb el seu departament d'atenció al client. La informació de contacte normalment es pot trobar a l'embalatge del producte o a la fitxa oficial de la marca. weblloc.

Conserveu el rebut de compra com a comprovant de compra per a reclamacions de garantia.
