Ventilador de sostre encastat BLITZWILL de 52 polzades amb llums i control remot/APP Manual d'usuari

Introducció

This manual provides detailed instructions for the installation, operation, and maintenance of your BLITZWILL 52-inch Flush Mount Ceiling Fan. Please read this manual thoroughly before installation and use to ensure proper function and safety. Keep this manual for future reference.

Informació de seguretat

Always follow basic safety precautions when installing and operating electrical appliances. Failure to do so may result in fire, electric shock, or personal injury.

• Assegureu-vos que l'alimentació estigui apagada a l'interruptor automàtic abans de la instal·lació o el manteniment.
• Tot el cablejat ha de complir amb els codis elèctrics nacionals i locals.
• Consulteu un electricista qualificat si no teniu clar quins són els procediments de cablejat.
• Mount the fan to a ceiling joist or a suitable support structure capable of holding the fan's weight.
• No introduïu objectes a les aspes del ventilador mentre el ventilador estigui en funcionament.
• This fan is designed for indoor use and covered outdoor spaces. Avoid direct exposure to rain.

Contingut del paquet

Verifiqueu que tots els components siguin presents i no estiguin danyats abans de començar la instal·lació.

Image: Diagram illustrating the components included in the package, such as the main body, ABS blades, lamp base, lamp shade, remote control, receiver, and various screws and mounting hardware.

• Main Fan Body
• Pales de ventilador (3)
• LED Light Kit / Lamp Ombra
• Control remot
• Mounting Hardware (screws, expansion screws, wire caps, balance pack)
• Manual d'instruccions

Configuració i instal·lació

This section outlines the steps for installing your ceiling fan. For detailed visual guidance, refer to the provided installation videos and diagrams.

Consideracions prèvies a la instal·lació

• Mida de l'habitació: Recommended for rooms 12 ft. x 12 ft. to 18 ft. x 18 ft.
• Alçada del sostre: Recommended ceiling height is 8-10 ft.
• Ensure the mounting location can support the fan's weight and is free from obstructions.

Image: A BLITZWILL 52-inch ceiling fan installed in a room, illustrating its dimensions (52 inches wide, 8.7 inches high) and recommended room sizes (12x12 ft to 18x18 ft) and ceiling height (8-10 ft).

Passos d'instal·lació

1. Apagueu l'alimentació: Before starting, ensure the power supply to the installation area is completely off at the circuit breaker.
2. Suport de muntatge: Secure the mounting bracket to the ceiling junction box. Ensure it is firmly attached to a structural support.
3. Cablejat: Connect the fan's electrical wires to the household wiring according to local electrical codes. Use the provided wire caps.
4. Fixeu el cos del ventilador: Carefully lift and attach the main fan body to the mounting bracket.
5. Instal·leu les fulles: Attach the three fan blades to the motor housing using the provided screws.
6. Instal·lació del kit de llums: Connect the light kit wiring and secure the lamp shade to the fan body.
7. Restaura l'alimentació: Un cop finalitzada la instal·lació, restableu l'alimentació a l'interruptor.

For any installation or post-purchase inquiries, contact our professional support team.

Instruccions de funcionament

Your BLITZWILL ceiling fan offers versatile control options via remote control and a dedicated mobile application.

Operació de control remot

Image: A BLITZWILL ceiling fan shown with its remote control and a smartphone displaying the control app interface, highlighting dual control options.

The included remote control allows for convenient adjustment of fan and light settings.

• Ventilador activat / desactivat: Press the fan switch button.
• Velocitat del ventilador: Select from 6 wind speed gears (1-6).
• Direcció del fan: Use the forward (F) or reverse (R) buttons to change airflow direction.
• Llum encès/apagat: Press the light switch button.
• Ajust de brillantor: Use the brightness +/- buttons for stepless dimming.
• Temperatura de color: Adjust between 3000K (warm), 4000K (natural), and 6500K (cool) using the color temperature +/- buttons.
• Temporització: Set a timer for 1 or 2 hours.

The remote control has a range of approximately 26-65 feet. It requires 2 AAA batteries (not included). A wall mounting bracket for the remote is included.

Control d'aplicacions mòbils

For enhanced control and additional features, download the "Blitzhome" app from your smartphone's app store (Google Play or App Store).

Image: A series of smartphone screenshots demonstrating the Blitzhome app's interface for controlling the ceiling fan's lighting functions, lighting scenes, fan functions, timing, night light/sound switch, default light settings, and device sharing.

App Setup Steps:

1. Scan the QR code in the manual or product packaging to install the "Blitzhome" app.
2. Open the app, enable Bluetooth and 2.4G WiFi on your device.
3. Turn on the fan lights via the wall switch or remote.
4. Press and hold the "Fan switch" button on the remote for 5+ seconds until you hear a beep/light flash, indicating successful network configuration.
5. Add the device on the app and enter your WiFi password to complete settings.

Característiques de l'aplicació:

• Control de la il·luminació: Adjust 3-color temperature (3000K/4000K/6500K) and stepless dimming (1%-100%).
• Lighting Scenes: Access preset lighting scenes (e.g., Night, Reading, Work, Casual).
• Control del ventilador: Select from 6 wind speed gears, normal or natural wind modes, and change fan direction (forward/reverse).
• Funció de cronometratge: Set timers from 1 to 8 hours.
• Funció de memòria: The fan remembers your last light color and brightness settings.
• Compartició de dispositius: Share control of the fan with other users.
• Night Mode/Sound Switch: Additional customizable settings.

Funció motora reversible

The fan features a reversible DC motor for year-round comfort.

Image: Illustration demonstrating the fan's reversible motor function, showing downward airflow for cooling in summer (forward rotation) and upward airflow for circulating warm air in winter (reverse rotation).

• Summer Mode (Forward Rotation): Air flows downward, creating a cooling effect.
• Winter Mode (Reverse Rotation): Air flows upward, circulating warm air evenly throughout the room.

Switch between modes using the remote control or the mobile application.

Manteniment

Un manteniment regular garanteix un rendiment òptim i una llarga vida útil del ventilador de sostre.

• Neteja: Netegeu les aspes del ventilador i la carcassa del motor amb un drap suau iamp tela. No utilitzeu netejadors abrasius ni dissolvents.
• Equilibri de la fulla: If the fan wobbles, check that all blade screws are tight and the blades are balanced. A balance kit is included if needed.
• Font de llum: The integrated LED light source is designed for long life. If issues occur, contact customer support. Do not attempt to replace individual LEDs.
• Motor: The DC motor is maintenance-free. No lubrication is required.

Resolució de problemes

Consulteu aquesta secció per conèixer els problemes comuns i les seves solucions.

Especificacions

Garantia i Suport

BLITZWILL offers customer support and warranty services for its products.

• Atenció al client: For any installation, operation, or product-related inquiries, please contact BLITZWILL customer service.
• Garantia: Refer to the product packaging or official BLITZWILL weblloc per obtenir detalls específics de la garantia.
