Manual d'usuari de l'assecadora amb bomba de calor Midea MDG09EH80/1

1. Introducció

Thank you for choosing the Midea MDG09EH80/1 Heat Pump Tumble Dryer. This manual provides essential information for the safe and efficient operation, installation, and maintenance of your appliance. Please read it thoroughly before use and keep it for future reference.

This heat pump tumble dryer is designed for domestic use to dry laundry after it has been washed and spun. It features an 8 kg capacity, 16 drying programs, automatic drying, anti-crease function, and a delayed start option.

2. Informació de seguretat

Per a la vostra seguretat i per garantir un ús correcte, observeu les precaucions següents:

• Assegureu-vos que l'aparell estigui ben connectat a terra.
• No instal·leu l'assecadora en llocs publicitarisamp l'entorn o on pugui estar exposat a l'aigua.
• Mantingueu els nens i les mascotes lluny de l'aparell durant el funcionament.
• No assequeu articles sense rentar a l'assecadora.
• Items soiled with oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes, or wax removers should be washed thoroughly in hot water with an extra amount of detergent before being dried in the tumble dryer.
• Always clean the lint filter after each use.
• No obstruïu les obertures de ventilació.
• Desendolleu l'aparell abans de netejar-lo o fer-ne el manteniment.

3. Producte acabatview

Familiarize yourself with the main components of your Midea tumble dryer.

Imatge 3.1: Davant view of the Midea MDG09EH80/1 Heat Pump Tumble Dryer, showing the control panel, drum door, and Midea branding.

Imatge 3.2: Close-up of the control panel, featuring the program selection dial, digital display, and touch buttons for various functions like Delay, Time, Anti-Crease, Intensity, and Start/Pause.

Característiques del tauler de control:

• Marcació del programa: Selects the desired drying program.
• Visualització: Shows remaining time, error codes, and selected options.
• Botó de retard: Estableix una hora d'inici retardada.
• Botó d'hora: Adjusts drying time for certain programs.
• Anti-Crease Button: Activates or deactivates the anti-crease function.
• Botó d'intensitat: Adjusts drying intensity (e.g., standard, extra dry).
• Botó d'inici/pausa: Starts or pauses the drying cycle.

4. Configuració i instal·lació

Una instal·lació correcta és crucial per al rendiment i la longevitat de la vostra assecadora.

4.1 Desembalatge

Traieu amb cura tots els materials d'embalatge. Comproveu si hi ha hagut danys durant el transport. Informeu immediatament al vostre distribuïdor de qualsevol dany.

4.2 Col·locació

• Col·loqueu l'assecadora sobre un terra ferm i anivellat.
• Ensure adequate ventilation around the appliance. Do not block the air intake at the front or the exhaust at the rear.
• Avoid placing the dryer near heat sources or in direct sunlight.
• The dimensions of the dryer are approximately 59.5 cm (width) x 60 cm (depth) x 84.5 cm (height). Ensure sufficient space for installation and door opening.

Imatge 4.1: lateral view of the Midea MDG09EH80/1 dryer, illustrating its dimensions (845mm height, 600mm depth, 595mm width).

4.3 Anivellació

Adjust the feet at the bottom of the dryer to ensure it is perfectly level. A level appliance reduces vibration and noise during operation.

4.4 Connexió elèctrica

Connect the power cord to a properly earthed electrical outlet. Ensure the voltage i la freqüència coincideixen amb les especificacions de la placa de dades de l'aparell.

4.5 Drain Hose Installation (Optional)

The dryer collects condensed water in a tank. For continuous drainage, you can connect a drain hose to an external drain. Refer to the detailed instructions in the full user manual for this procedure.

5. Instruccions de funcionament

Segueix aquests passos per a un assecat eficaç i segur.

5.1 Preparació de la bugada

• Ordena la roba per tipus de teixit i requisits d'assecat.
• Close zippers, hooks, and fastenings.
• Butxaques buides.
• Ensure laundry is thoroughly spun to reduce drying time and energy consumption.

5.2 Càrrega de l'assecadora

Open the dryer door and load the laundry into the drum. Do not overload the dryer; ensure there is enough space for clothes to tumble freely. The maximum load capacity is 8 kg.

5.3 Selecció d'un programa

Turn the program dial to select one of the 16 available drying programs. The display will show the default settings for the chosen program. Examples of programs include:

• Cotó: For cotton items like towels, sheets, and underwear.
• Sintètics: For synthetic fabrics like shirts, blouses, and sportswear.
• Delicat: Per a peces delicades que requereixen un assecat suau.
• Llana: Specific program for wool items (check garment care labels).
• Actualitzar: To air out clothes and remove odors without heat.
• Texans: For denim items.
• Roba de llit: For larger items like duvet covers and sheets.

5.4 Adjusting Drying Levels and Options

The dryer features an automatic drying system that detects the drying state of your clothes, preventing over-drying and protecting fabrics.

Imatge 5.1: Visual representation of the three drying levels: Low (lightly damp for easy ironing), Medium (fully dry for immediate wear), and High (moisture-proof storage).

You can select from 3 drying levels:

• Standard Dry: For general drying, suitable for most items.
• Planxa en sec: Deixa la roba lleugerament damp per planxar més fàcilment.
• Extra sec: For items requiring complete dryness, such as towels or thick fabrics.

Additional functions can be selected using the touch buttons:

• Antiarrugues: This function periodically rotates the drum after the drying cycle to prevent wrinkles from setting in, especially if you cannot remove clothes immediately.
• Inici retardat: Set a time for the drying cycle to begin, up to 24 hours.
• Llum del tambor: The interior light illuminates when the door is opened, ensuring no items are left behind.

Imatge 5.2: Depiction of the Smart Continuous Rotation feature, which rotates the drum periodically after drying to prevent wrinkles.

Imatge 5.3: Visual showing the Refresh function, which uses low-temperature air wash to remove musty odors and refresh fabrics.

5.5 Inici del cicle

Premeu el botó Inici/Pausa button to begin the drying cycle. The display will show the estimated remaining time.

5.6 Fi de cicle

Once the cycle is complete, the dryer will beep, and the display will indicate 'End'. Open the door and remove your laundry. Remember to clean the lint filter and empty the water tank after each use.

6. Manteniment

Un manteniment regular garanteix un rendiment òptim i allarga la vida útil de l'assecadora.

6.1 Neteja del filtre de borrissol

The lint filter is located inside the door opening. It must be cleaned after every drying cycle to maintain drying efficiency and prevent fire hazards.

1. Obriu la porta de l’assecadora.
2. Estireu el filtre de pelussa cap amunt per treure'l.
3. Open the filter and remove all accumulated lint by hand or with a soft brush.
4. Si cal, esbandiu el filtre amb aigua corrent i assegureu-vos que estigui completament sec abans de tornar-lo a inserir.
5. Place the clean filter back into its housing until it clicks into place.

6.2 Buidatge del dipòsit d'aigua

The condensed water is collected in a tank, usually located at the top left of the control panel. This tank must be emptied after each drying cycle.

1. Traieu suaument el dipòsit d'aigua.
2. Pour the collected water into a sink.
3. Push the water tank back into its position until it is securely seated.

6.3 Cleaning the Heat Exchanger/Condenser

The heat exchanger (condenser) should be cleaned periodically (e.g., every few months or as indicated by the appliance) to ensure efficient operation. Refer to the full manual for detailed instructions on accessing and cleaning this component, typically located behind a lower access panel.

6.4 Neteja general

• Netegeu l'exterior de l'assecadora amb un damp tela. No utilitzeu netejadors abrasius ni dissolvents.
• Clean the interior of the drum with a damp tela si cal.

7. Solució De Problemes

Abans de contactar amb el servei d'atenció al client, comproveu els següents problemes i solucions habituals:

If the problem persists after checking these points, please refer to the complete troubleshooting guide in the full user manual or contact Midea customer support.

8. Especificacions

Technical data for the Midea MDG09EH80/1 Heat Pump Tumble Dryer.

Imatge 8.1: Energy label for the Midea MDG09EH80/1, showing A++ energy efficiency, 235 kWh/annum consumption, 8.0 kg capacity, and 65 dB noise level.

9. Garantia i Suport

Your Midea MDG09EH80/1 Heat Pump Tumble Dryer comes with a standard manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions, including the duration and coverage.

For technical assistance, spare parts, or warranty claims, please contact Midea customer support. You can find contact information on the Midea official weblloc web o a la documentació que s'inclou amb l'aparell.

Please have your model number (MDG09EH80/1) and purchase date ready when contacting support.
