1. Introducció
The JINBEI TR-RVII is a 2.4GHz wireless flash receiver designed to trigger compatible flashes equipped with a 3.5mm trigger jack. This device enables remote control of your flash units, offering enhanced flexibility and convenience in various photographic setups. It features a built-in lithium battery and supports USB-C charging.
2. Producte acabatview
Familiarize yourself with the components and features of your TR-RVII receiver.
Figura 2.1: Frontal view of the JINBEI TR-RVII Flash Receiver, showing the channel switches and power button.
Figure 2.2: Labeled components of the TR-RVII receiver, indicating the Status Indicator, Channel Adjustment Switch, and Power button.
Components clau:
- Indicador d'estat: Displays the operational status of the receiver.
- Channel Adjustment Switch: A set of four DIP switches used to set the communication channel.
- Botó d'encesa: Used to turn the receiver on or off.
- 3.5mm Sync Plug: Connects to the flash unit's trigger jack.
- Port de càrrega USB-C: Per carregar la bateria interna.
3. Configuració
Configuració de 3.1 canals
The TR-RVII receiver uses a 4-position DIP switch for channel selection. To ensure proper communication, the channel setting on the receiver must match the channel setting on your JINBEI flash inducer or transmitter.
Figure 3.1: Illustration of the channel switch and its settings. 'ON' indicates '0', and 'OFF' (not ON) indicates '1'.
Refer to the table below for channel configuration:
| Canal | Interruptor 1 | Interruptor 2 | Interruptor 3 | Interruptor 4 |
|---|---|---|---|---|
| 1 | ACTIVAT (0) | ACTIVAT (0) | ACTIVAT (0) | ACTIVAT (0) |
| 2 | DESACTIVAT (1) | ACTIVAT (0) | ACTIVAT (0) | ACTIVAT (0) |
| ... | ... | ... | ... | ... |
| 16 | DESACTIVAT (1) | DESACTIVAT (1) | DESACTIVAT (1) | DESACTIVAT (1) |
Nota: Ensure the channel settings on both the receiver and the transmitter are identical for successful communication.
3.2 Connecting to a Flash Unit
The TR-RVII receiver connects to your flash unit via its 3.5mm sync plug.
- Locate the 3.5mm trigger jack on your flash unit.
- Insert the 3.5mm sync plug of the TR-RVII receiver firmly into the flash unit's trigger jack.
Figure 3.2: The TR-RVII receiver connected to a flash unit via its 3.5mm sync plug.
4. Instruccions de funcionament
4.1 Engegada/apagada
- Per encendre: Press and hold the Power button until the Status Indicator illuminates.
- Per apagar: Press and hold the Power button until the Status Indicator turns off.
4.2 Pairing and Triggering
Once the receiver is connected to your flash and both the receiver and your JINBEI transmitter (e.g., TR-RV) are set to the same channel, they will automatically pair. The receiver is now ready to trigger the flash remotely.
Figure 4.1: The TR-RVII receiver being used in conjunction with a wireless transmitter for remote flash triggering.
Figure 4.2: The TR-RVII offers a remote control distance of up to 100 meters (39 inches), providing ample range for various shooting scenarios.
5. Càrrega
The TR-RVII receiver is equipped with a built-in 400mAh lithium battery, allowing for extended use. It supports USB-C charging.
- Connect a USB-C cable to the charging port on the receiver.
- Connect the other end of the USB-C cable to a compatible USB power source (e.g., power bank, wall adapter).
- The Status Indicator will show the charging status.
- The receiver can be used while charging.
Figure 5.1: The USB-C charging port on the TR-RVII receiver, supporting fast charging.
6. Compatibilitat
The JINBEI TR-RVII receiver is compatible with most hot shoe flashes and all ISO hot shoe flashes that feature a 3.5mm trigger jack. This includes specific JINBEI models such as the JINBEI Hi-5 and can be adapted to various JINBEI induced flashes like the TR-V6II.
7. Especificacions
Technical specifications for the JINBEI TR-RVII Flash Receiver:
| Característica | Detall |
|---|---|
| Número de model | TR-RVII |
| Freqüència sense fil | 2.4 GHz |
| Velocitat màxima de sincronització | 1/250 s |
| Interval | Up to 100m (39 inches) |
| Bateria | Built-in 3.7V 400mAh 1.48Wh Li-ion |
| Entrada de càrrega | DC 5V / 1A Max (USB-C) |
| Pes de l'article | 3.52 unces |
| Dimensions del paquet | 4.53 x 3.35 x 2.17 polzades |
8. Què hi ha a la caixa
Upon opening your JINBEI TR-RVII package, you should find the following items:
- TR-RVII Trigger *1
9. Solució De Problemes
If you encounter issues with your TR-RVII receiver, consider the following common solutions:
- El receptor no s'encén: Ensure the battery is charged. Connect the receiver to a USB-C power source.
- El flaix no s'activa:
- Verify that the receiver is powered on.
- Check that the 3.5mm sync plug is securely connected to the flash unit.
- Confirm that the channel settings on both the TR-RVII receiver and your JINBEI transmitter are identical.
- Ensure the flash unit itself is powered on and functioning correctly.
- Rang limitat: Ensure there are no significant obstructions between the transmitter and receiver. Avoid operating in environments with strong 2.4GHz interference.
10. Manteniment
To ensure the longevity and optimal performance of your JINBEI TR-RVII receiver, follow these maintenance guidelines:
- Neteja: Use a soft, dry cloth to clean the exterior of the receiver. Avoid using harsh chemicals or abrasive materials.
- Emmagatzematge: Guardeu el receptor en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.
- Cura de la bateria: If storing for an extended period, ensure the battery is partially charged (around 50%) to prolong its lifespan. Avoid fully discharging the battery for long periods.
- Protecció: Protect the 3.5mm sync plug and USB-C port from dust and moisture when not in use.
11. Garantia i Suport
For warranty information or technical support regarding your JINBEI TR-RVII Flash Receiver, please refer to the warranty card included with your product or contact JINBEI customer service directly. Contact details can typically be found on the official JINBEI weblloc web o a través del vostre punt de compra.
