oraolo BS02 Portable Bluetooth Speaker with LED Light User Manual

Introducció

Gràcies per la compraasing the oraolo Portable Bluetooth Speaker with LED Light, Model BS02. This manual provides essential information for setting up, operating, and maintaining your speaker. Please read it carefully before use and retain it for future reference.

Image: The oraolo BS02 Portable Bluetooth Speaker, black with a mesh finish, featuring a circular LED light on one end and a linear LED light along its body, both displaying a gradient of red, orange, and yellow. Water splashes around the speaker, highlighting its waterproof design.

Contingut del paquet

Assegureu-vos que tots els elements siguin presents al paquet:

• 1 x oraolo Bluetooth Speaker with Lights
• 1 x Cable de càrrega (Tipus C)
• 1 x Manual d'usuari

Configuració

1. Carregant l’altaveu

Before first use, fully charge the speaker. Use the provided Type-C charging cable.

1. Connect the Type-C end of the charging cable to the speaker's charging port.
2. Connect the USB-A end to a compatible 5V USB power adapter (not included).
3. El llum indicador de càrrega s'il·luminarà. S'apagarà o canviarà de color un cop estigui completament carregat.

Note: The speaker contains a Lithium-ion battery. Do not expose to extreme temperatures.

2. Encès / apagat

• Per encendre: Press and hold the Power button for approximately 3 seconds. You will hear an audible prompt.
• Per apagar: Press and hold the Power button for approximately 3 seconds. You will hear an audible prompt.

3. Emparellament Bluetooth

The speaker uses Bluetooth 5.4 for stable connections.

1. Ensure the speaker is powered on and in pairing mode (usually indicated by a flashing LED light).
2. Al dispositiu (telèfon intel·ligent, tauleta, etc.), activeu el Bluetooth i cerqueu els dispositius disponibles.
3. Select "oraolo BS02" from the list of devices.
4. Once connected, you will hear a confirmation sound, and the LED light will stop flashing.

4. Emparellatge estèreo sense fil veritable (TWS)

Connect two oraolo BS02 speakers for a stereo sound experience.

1. Assegureu-vos que tots dos altaveus estiguin encesos i no connectats a cap dispositiu Bluetooth.
2. On one speaker (this will be the primary speaker), press and hold the TWS button (refer to speaker diagram for button location) for 2-3 seconds.
3. The speakers will automatically search and pair with each other. You will hear a confirmation sound when TWS pairing is successful.
4. Once TWS paired, connect your device to the primary speaker via Bluetooth as described in step 3.

Instruccions de funcionament

1. Controls bàsics

• Reproduir/pausa: Premeu el botó Reproduir/Pausa una vegada.
• Pujar el volum: Premeu el botó Volum +.
• Baixar el volum: Premeu el botó de volum -.
• Pista següent: Mantingueu premut el botó Volum +.
• Pista anterior: Mantingueu premut el botó de volum -.

2. Modes de llum LED

The speaker features elegant multi-color LED lights that synchronize with music.

• Canvia el mode de llum: Press the Light Mode button (refer to speaker diagram) to cycle through available light effects (e.g., strong pulse, gradient effect).
• Apagar els llums: Press and hold the Light Mode button for 2-3 seconds.

3. Multiple Input Modes

The speaker supports various audio input sources:

• Mode Bluetooth: Mode per defecte després de l'emparellament.
• Mode de targeta TF: Insert a TF (MicroSD) card into the designated slot. The speaker will automatically switch to TF card playback.
• Mode USB: Insert a USB drive into the USB port. The speaker will automatically switch to USB playback.
• Mode AUX: Connect an audio device using a 3.5mm AUX cable (not included) to the AUX port. The speaker will automatically switch to AUX input.

Note: Use the Mode button (if available, refer to speaker diagram) to manually switch between input modes if automatic switching does not occur.

4. IPX5 Waterproof Rating

The speaker is rated IPX5 waterproof, meaning it can resist sustained low-pressure water jet sprays. It is suitable for use in environments like beaches, poolside, or light rain.

Caution: Do not submerge the speaker in water. Ensure the charging port cover is securely closed before exposure to water.

Manteniment

• Neteja: Netegeu l'altaveu amb un suau, damp tela. No utilitzeu netejadors abrasius ni dissolvents.
• Emmagatzematge: Guardeu l'altaveu en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.
• Cura de la bateria: To prolong battery life, charge the speaker at least once every three months if not in regular use.

Resolució de problemes

Especificacions

Garantia i Suport

oraolo products are designed for reliability and performance. For warranty information or technical support, please refer to the contact details provided on the product packaging or the official oraolo weblloc.

Conserveu el vostre comprovant de compra per a reclamacions de garantia.
