1. Producte acabatview
The Xiaomi S20 Smart Robot Vacuum Cleaner is an intelligent 3-in-1 device designed for efficient vacuuming, sweeping, and mopping. Equipped with advanced LDS laser navigation and powerful 5000Pa suction, it provides comprehensive cleaning for various floor types. It supports smart home integration with Google Assistant and Amazon Alexa for convenient control.
Característiques principals:
- 3-in-1 Cleaning: Vacuum, Sweep, and Mop simultaneously.
- LDS Laser Navigation: Precise mapping and efficient path planning.
- 5000Pa Suction Power: Strong suction for deep cleaning.
- Smart Home Integration: Compatible with Google Assistant and Amazon Alexa.
- App Control: Customize cleaning modes, virtual walls, and no-go zones via the Xiaomi Home app.
Aquesta imatge mostra la part superior view of the black Xiaomi S20 Smart Robot Vacuum Cleaner alongside a smartphone screen showing the Xiaomi Home app interface with a detailed map of a cleaned area, indicating the robot's intelligent navigation capabilities.
2. Contingut del paquet
Ensure all items are present in the package before initial use:
- Manual d'instruccions
- Adaptador de càrrega
- Estació d'acoblament
- Pinzell lateral
- Coixinet de neteja
3. Components del producte
3.1 Amunt View
A detailed front-side perspective of the Xiaomi S20 Smart Robot Vacuum Cleaner, highlighting its sleek black design and the front bumper sensor.
3.2 lateral View
Aquesta imatge ofereix un costat view of the Xiaomi S20 Smart Robot Vacuum Cleaner, showcasing its compact profile and the side brush.
3.3 Enrere View
L'esquena view of the Xiaomi S20 Smart Robot Vacuum Cleaner, revealing the charging contacts and exhaust vents.
4. Configuració
4.1 Col·locació de la base de càrrega
Col·loca la base de càrrega contra una paret en una zona oberta, assegurant-te que no hi hagi obstacles a menys de 0.5 metres a banda i banda i 1.5 metres al davant. Connecta l'adaptador de corrent a la base i endolla'l a una presa de corrent.
The robot vacuum cleaner is shown charging at its docking station, positioned neatly against a wall in a modern living room setting, demonstrating ideal placement for the charging base.
4.2 Càrrec inicial
Place the robot vacuum cleaner on the charging dock. Ensure the charging contacts align. The robot will automatically power on and begin charging. Fully charge the robot before its first use, which may take several hours.
4.3 Instal·lació i connexió de l'aplicació
Descarrega't el Aplicació Xiaomi Home from your app store. Follow the in-app instructions to add your Xiaomi S20 robot vacuum cleaner. This will enable advanced features like mapping, scheduling, and remote control.
The Xiaomi Home app interface, displaying a detailed map of a room, allows users to manage cleaning zones and monitor the robot's progress.
5. Instruccions de funcionament
5.1 Encès/Apagat
- Encès: Manteniu premut el botó d'engegada fins que s'encén la llum indicadora.
- Apagar: Premeu i manteniu premut el botó d'engegada fins que l'indicador lluminós s'apagui.
5.2 modes de neteja
The robot offers various cleaning modes accessible via the app:
- Neteja automàtica: The robot intelligently plans a path to clean the entire area.
- Neteja de la zona: Defineix zones específiques al mapa perquè el robot les netegi.
- Neteja de punts: Direct the robot to clean a small, concentrated area.
This image shows two robot vacuum cleaners on a floor, with white lines illustrating their cleaning patterns: one following a systematic zigzag path and another a Y-shaped path, simulating manual cleaning for enhanced efficiency.
5.3 Potència de succió
The Xiaomi S20 features a powerful 5000Pa suction, ensuring effective removal of dust, debris, and pet hair from various surfaces. Suction levels can be adjusted via the Xiaomi Home app.
An illustrative image highlighting the robot vacuum cleaner's strong suction power, with '5000Pa' prominently displayed and visual effects indicating powerful airflow, demonstrating its capability for thorough cleaning.
5.4 Cartografia i navegació
The robot uses an advanced LDS (Laser Distance Sensor) navigation system to accurately map your home, allowing for efficient and systematic cleaning paths. The app allows you to view and manage these maps, set virtual walls, and define no-go zones.
The robot vacuum cleaner is depicted with blue laser beams extending from its top, symbolizing its LDS (Laser Distance Sensor) navigation system actively mapping the surrounding environment for precise and efficient cleaning.
This image illustrates the robot vacuum cleaner's advanced multi-sensor system, depicting blue light rays emanating from the device as it navigates around common household obstacles such as a cat and slippers, ensuring collision avoidance.
6. Manteniment
6.1 Neteja de papereres i dipòsits d'aigua
Regularly empty the dustbin and clean the water tank to maintain optimal performance. The dustbin has a capacity of 400ml and the water tank 270ml.
Un primer pla view of the robot vacuum cleaner's transparent dustbin and water tank, indicating their respective capacities (400ml dustbin, 270ml water tank) and ease of access for maintenance.
6.2 Neteja amb raspalls
Periodically remove and clean the main brush and side brush to prevent hair entanglement and ensure effective sweeping.
6.3 Neteja del sensor
Wipe the cliff sensors, wall sensors, and charging contacts with a soft, dry cloth to ensure proper navigation and charging.
7. Solució De Problemes
If you encounter issues with your Xiaomi S20, refer to the table below for common problems and solutions:
| Problema | Causa possible | Solució |
|---|---|---|
| El robot no s'encén | Bateria baixa; el botó d'engegada no s'ha premut prou estona | Charge the robot; Press and hold power button for 3 seconds |
| El robot no pot trobar la base de càrrega | Dock is obstructed; Dock is unplugged | Ensure clear path to dock; Plug in the charging dock |
| Cleaning performance is poor | Cubell de les escombraries ple; raspalls enredats; filtre obstruït | Empty dustbin; Clean brushes; Clean or replace filter |
| El robot s'enganxa sovint | Obstacles al terra; Sensors bruts | Clear floor of small objects; Clean all sensors |
For further assistance, please refer to the official Xiaomi support weblloc o contacteu amb el servei d'atenció al client.
8. Especificacions
| Característica | Especificació |
|---|---|
| Nom del model | Xiaomi Robot Vacuum S20 |
| Color | Negre |
| Pes del producte | 3.5 quilos |
| Dimensions | 47.2 x 38.6 x 15.2 cm |
| Voltage | 14.4 Volts |
| Tipus de bateria | Ió de liti (1 inclosa) |
| Capacitat de la paperera | 400 ml |
| Capacitat del dipòsit d'aigua | 270 ml |
| Característiques especials | Programmable, Scheduling, Simultaneous Vacuuming & Mopping, Precision Laser Mapping & Navigation, LiDAR Navigation |
| Recomanació de superfície | Multisuperfície |
9. Garantia i Suport
The Xiaomi S20 Smart Robot Vacuum Cleaner comes with a standard manufacturer's warranty. Please refer to your purchase documentation for specific warranty terms and conditions. For technical support, troubleshooting assistance, or to inquire about replacement parts, please visit the official Xiaomi support weblloc o poseu-vos en contacte amb el seu departament d'atenció al client.
Conserveu el vostre comprovant de compra per a reclamacions de garantia.
