LIGE Military Smart Watch EF2-G-XY-US-JQ User Manual

1. Introducció

This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your LIGE Military Smart Watch EF2-G-XY-US-JQ. Please read this manual thoroughly to ensure proper use and to maximize the functionality of your device.

Figure 1: LIGE Military Smart Watch EF2-G-XY-US-JQ

2. Què hi ha a la caixa

Upon unboxing, verify that all the following items are included:

• Rellotge intel·ligent
• Cable carregador
• Smartwatch Manuals
• 3 Different Watch Straps
• Watch Setting Tools & Warranty Card

3. Guia de configuració

3.1 Càrrega inicial

Before first use, fully charge your smartwatch. Connect the provided charger cable to the watch and a compatible USB power source. A full charge typically takes approximately 2.5 hours.

Figure 2: Smartwatch charging indicator

3.2 Instal·lació i emparellament de l'aplicació

To unlock the full features of your LIGE Smart Watch, you need to connect it to your smartphone via the "GloryFit" application.

1. Descarrega l'aplicació: Scan the QR code provided in the watch's manual or search for "GloryFit" in your smartphone's app store (Google Play for Android, App Store for iOS). You can also visit https://app.help-document.com/gloryfit/download/index.html.
2. Activa el Bluetooth: Ensure Bluetooth is turned on in your phone's settings.
3. Open GloryFit App: Launch the "GloryFit" application and follow the on-screen prompts to set up your profile.
4. Lliga el rellotge: Within the GloryFit app, navigate to the device section and select "Add Device" or "Bind Device". The app will search for nearby smartwatches.
5. Selecciona el teu rellotge: From the list of found devices, select "EF2" or the corresponding model number.
6. Confirmeu l'aparellament: A pairing request will appear on your phone and possibly on the watch. Confirm the pairing on both devices.
7. Concedir permisos: Allow necessary permissions for the app to function correctly (e.g., notifications, location).

Figure 3: App installation and pairing process

4. Instruccions de funcionament

4.1 Navegació bàsica

• Pantalla tàctil: The 1.96-inch HD color full touchscreen allows for intuitive navigation. Swipe left, right, up, or down to access different features and menus.
• Botons laterals: Use the physical buttons on the side of the watch for quick access to specific functions or to return to the home screen.
• Activa la pantalla: Lift your wrist or press a side button to wake the screen.

4.2 Característiques de comunicació

Once connected via Bluetooth, your smartwatch supports various communication functions:

• Trucades per Bluetooth: Answer, reject, or dial calls directly from your watch using the built-in speaker and microphone. You can also store contacts and view registres de trucades.
• Notificacions de missatges: Receive alerts for incoming messages and app notifications (e.g., Facebook, WhatsApp, YouTube, Gmail). The watch will vibrate to inform you.
• Assistent de veu AI: Control your phone's voice assistant (e.g., Siri) through the watch to make calls, send messages, or ask questions.

Figure 4: Bluetooth call and message notification features

4.3 Vigilància de la salut

The smartwatch provides comprehensive health tracking features. Data can be viewed on the watch or in the GloryFit app.

• Monitorització de la freqüència cardíaca: 24/7 real-time heart rate tracking with alerts for high and low rates.
• Blood Pressure Testing: In-depth blood pressure monitoring.
• Monitorització del son: Fa un seguiment del sontages (REM, light, deep sleep) to help analyze and improve sleep quality. Automatic measurement occurs between 10 PM and 8 AM.
• Nota: The health monitoring data is for reference only and should not be used for medical diagnosis, treatment, or prevention.

Figure 5: Health tracking features

4.4 Sports Modes and Activity Tracking

The watch supports over 70 indoor and outdoor sports modes to track your fitness activities.

• Més de 70 modes esportius: Includes walking, running, cycling, basketball, badminton, football, yoga, and more.
• Seguiment de l'activitat: Records steps, distance, calories burned, and heart rate during exercise.
• All-Day Tracking: Automatically monitors daily steps, distance, and calories.

Figure 6: Sports modes and activity tracking

4.5 Customization and Other Features

• Cares de visualització: Choose from over 200 online watch faces via the GloryFit app or customize with your own photos.
• Utility Functions: Includes weather forecast, stopwatch, timer, music control, brightness adjustment, phone/watch search, alarm clock, calculator, drinking water reminder, sedentary reminder, and do not disturb mode.
• Control remot de la càmera: Fes servir el rellotge per activar la càmera del telèfon de forma remota.

Figure 7: Customizable watch faces

5. Manteniment

5.1 Resistència a l'aigua

The LIGE Military Smart Watch is 5ATM waterproof, making it suitable for everyday water sports. Avoid prolonged submersion in hot water or exposure to high-pressure water jets.

Figure 8: Military-grade durability and water resistance

5.2 Neteja i cura

• Netegeu la pantalla i la carcassa del rellotge amb un drap suau iamp tela.
• Assegureu-vos que els contactes de càrrega estiguin nets i secs abans de carregar.
• Eviteu utilitzar productes químics o materials abrasius per netejar.

5.3 Durada de la bateria

The watch is equipped with a 360 mAh battery. A full charge provides up to 5-7 days of daily use and up to 30 days of ultra-long standby time. Actual battery life may vary based on usage patterns and settings.

6. Solució De Problemes

7. Especificacions

8. Garantia i Suport

Your LIGE Military Smart Watch comes with a 12-month service warranty. Additionally, a 60-day worry-free refund policy is available. For any questions or support needs, please contact customer service through your purchase platform. Support is available 24 hours a day.
