LOFREE Edge Low Profile Manual d'usuari del teclat mecànic

Introducció

This manual provides detailed instructions for the LOFREE Edge Low Profile Mechanical Keyboard. It covers setup, operation, maintenance, and troubleshooting to ensure optimal performance and longevity of your device.

The LOFREE Edge keyboard is designed for portability and a premium typing experience, featuring an ultra-thin profile, carbon fiber and magnesium alloy construction, and advanced Kailh POM Switches 2.0.

Contingut del paquet

LOFREE Edge Low Profile Teclat mecànic
Cable USB
Lofree "Zero" Panel Mount (Carbon Fiber Keyboard Stand)

Video: See what's in the LOFREE Edge box. This video demonstrates the unboxing experience and shows all the items included in the LOFREE Edge keyboard package, including the keyboard itself, the USB cable, and the unique "Zero" Panel Mount.

Configuració

Càrrega inicial

Before first use, fully charge the keyboard using the provided USB-C cable. Connect the cable to the USB-C port on the keyboard and to a power source (e.g., computer USB port, USB wall adapter). A full charge takes approximately 3 hours and provides up to 130 hours of non-stop working time.

LOFREE Edge keyboard with USB-C cable connected, indicating charging. — **Figure 1: Charging the LOFREE Edge Keyboard.** The image shows the LOFREE Edge keyboard connected via its USB-C port to a charging cable, highlighting its rechargeable nature.

Connexió del teclat

The LOFREE Edge supports both wired USB-C and Bluetooth connections.

Connexió per cable

Connect the provided USB-C cable from the keyboard to your computer's USB port. The keyboard will automatically switch to wired mode and operate with a 1000Hz polling rate, ensuring minimal latency.

LOFREE Edge keyboard connected via USB-C cable to a laptop. — **Figure 2: Wired Connection.** This image illustrates the LOFREE Edge keyboard connected to a laptop using the USB-C cable for a stable, high-performance wired connection.

Connexió Bluetooth

Assegureu-vos que el teclat estigui carregat.
Toggle the switch on the side of the keyboard to the Bluetooth (BT) position.
On your device (Laptop, PC, Tablet), enable Bluetooth and search for new devices.
Select "LOFREE Edge" from the list of available devices to pair.
The keyboard can store up to 3 paired Bluetooth devices. Switch between them using Fn + 1/2/3.

lateral view of LOFREE Edge keyboard showing the Bluetooth/Wired switch. — **Figure 3: Bluetooth/Wired Mode Switch.** A close-up of the keyboard's side, showing the toggle switch for selecting between Bluetooth and wired modes.

Instruccions de funcionament

Funcions clau i disseny

The LOFREE Edge features an 84-key layout with low-profile keycaps and Kailh POM Switches 2.0 for a comfortable typing experience.

De dalt a baix view of the LOFREE Edge keyboard showing its 84-key layout and carbon fiber top case. — **Figure 4: LOFREE Edge Keyboard Layout.** Aquesta imatge proporciona una clara view of the keyboard's compact 84-key layout, highlighting the carbon fiber top case.

System Function Keys

Fn + N: Triggers corresponding system function keys for Windows/Android.
Fn + M: Triggers corresponding system function keys for Mac/iOS.

Il·luminació de fons

The keyboard features single-color backlighting. Adjust brightness or toggle effects (e.g., breathing light, steady) using the dedicated function keys (refer to keyboard legends for specific key combinations, typically Fn + arrow keys or dedicated light keys).

Close-up of the LOFREE Edge keyboard's keys with subtle backlighting visible. — **Figure 5: Keyboard Backlighting.** A close-up shot demonstrating the subtle backlighting of the LOFREE Edge keyboard's keys.

Suports de peu ajustables

The keyboard is equipped with adjustable kickstands on the bottom, allowing for two typing angles (3° and 6°) to enhance ergonomic comfort.

A baix view of the LOFREE Edge keyboard showing the adjustable kickstands. — **Figure 6: Adjustable Kickstands.** The bottom of the keyboard is shown with its integrated kickstands, which can be deployed to adjust the typing angle.

Manteniment

Neteja del teclat

To clean your LOFREE Edge keyboard, use a soft, lint-free cloth. For stubborn dirt, slightly dampen the cloth with water or a mild cleaning solution. Avoid excessive moisture and harsh chemicals.

Extracció i substitució de les tecles

The keyboard features ultra-thin OEM keycaps. While designed for durability, they can be carefully removed for cleaning or replacement using a keycap puller. Exercise caution to avoid damaging the switches.

Close-up of a keycap being removed from the LOFREE Edge keyboard, revealing the Kailh POM Switch 2.0. — **Figure 7: Keycap Removal.** This image demonstrates the process of removing a keycap, showcasing the underlying Kailh POM Switch 2.0.

Emmagatzematge

When not in use, store the keyboard in a dry, cool place. For travel, consider using a protective sleeve to prevent scratches and damage.

Resolució de problemes

Problema	Causa possible	Solució
El teclat no respon (amb cable)	Connexió del cable fluixa, port USB defectuós.	Assegureu-vos que el cable USB-C estigui connectat correctament. Proveu un altre port USB o cable.
El teclat no respon (Bluetooth)	Low battery, not paired, out of range, interference.	Charge the keyboard. Re-pair the device. Ensure keyboard is within Bluetooth range. Minimize interference from other wireless devices.
Les claus no es registren o s'escriuen dues vegades	Dust/debris under keycap, switch issue.	Carefully remove keycap and clean around the switch. If issue persists, contact support.
La retroiluminació no funciona	Backlight turned off, low battery.	Press Fn + relevant key to turn on/adjust brightness. Charge the keyboard.

Video: The Overview of LOFREE Edge Low Profile Teclat mecànic. Aquest vídeo ofereix una descripció completaview of the LOFREE Edge keyboard, demonstrating its features and functionality, which can be helpful for troubleshooting general usage issues.

Especificacions

Model: OE920
Dimensions: 12.25 x 6.06 x 0.59 polzades
Pes: 1.07 lliures (485 g)
Connectivitat: Bluetooth, USB-C
Tipus de teclat: Mecànica
Interruptors: Kailh POM Switch 2.0 (2.4mm total travel)
Tecles de tecles: Ultra-thin OEM PBT Keycaps
Construcció: Carbon Fiber Top Case, Magnesium Alloy Bottom Case
Bateria: 1 bateria de polímer de liti (inclosa)
Durada de la bateria: Up to 130 hours (non-stop working)
Temps de càrrega: Aproximadament 3 hores
Polling Rate (Wired): 1000 Hz
Il·luminació de fons: Single Color, adjustable brightness
Dispositius compatibles: Laptop, PC, Tablet (Windows, Mac OS, Android, iOS)

Figure 8: Ultra-Thin Profile. This image highlights the keyboard's slim profile, measuring 0.59 inches (15mm) at its thickest point, and its lightweight design at 1.07 lbs (485g).

Close-up of the LOFREE Edge keyboard's PBT keycaps compared to standard keycaps. — **Figure 9: PBT Keycaps.** A comparison showing the unique profile of the LOFREE Edge's PBT keycaps against other keycap types, emphasizing their thinner design.

Garantia i Suport

Informació de la garantia

LOFREE products typically come with a limited manufacturer's warranty. Please refer to the warranty card included in your product packaging or visit the official LOFREE weblloc web per obtenir informació detallada sobre els termes i condicions de la garantia. Conserveu el rebut de compra com a comprovant de compra per a reclamacions de garantia.

Atenció al client

For technical assistance, product inquiries, or warranty support, please contact LOFREE customer service through their official weblloc web o la informació de contacte que es proporciona a la documentació del producte. També podeu visitar el LOFREE Store on Amazon per obtenir recursos addicionals i informació sobre el producte.
